Susceptibility to electromagnetic fields conforming to EN/IEC 61000-4-3 - test level 10 V/m (f =
80...1000 MHz)
Electrical fast transient/burst immunity test conforming to EN/IEC 61000-4-4 - test level 2 kV
1.2/50 µs shock waves immunity test conforming to EN/IEC 61000-4-5 - test level 500 V 12 Ohm, 1
kV 42 Ohm
Radiated RF fields conforming to EN/IEC 61000-4-6 - test level 10 V (f = 0.15...80 MHz)
Immunity to magnetic fields conforming to EN/IEC 61000-4-8 - test level 30 A/m (f = 50 Hz)
[Uimp] rated impulse withstand voltage 0.5 kV
Response time on output < 5 ms
Measurement accuracy +/- 1 % of the measuring range
Resolution 0.1 % of the measuring range
Drift of the sensitivity +/- 0.04 % of measuring range/°K
Drift of the zero point +/- 0.03 % of measuring range/°K
Long term stability +/- 1 % of the measuring range
Mechanical durability >= 10000000 cycles
Product weight 0.24 lb(US) (0.11 kg)
Diameter 1.42 in (36 mm)
Length 2.58 in (65.5 mm)
Scale type Fixed differential
Environment
Standards CE
Product certifications UL 508
Protective treatment TC
Ambient air temperature for operation 32...176 °F (0...80 °C)
Ambient air temperature for storage -13...176 °F (-25...80 °C)
Vibration resistance 20 gn (f = 9...2000 Hz) conforming to EN/IEC 60068-2-6
Shock resistance 25 gn 11 ms conforming to EN/IEC 60068-2-27
IP degree of protection IP65 conforming to EN/IEC 60529
NEMA degree of protection NEMA 4
EN/IEC 61326-2-3
RCM
CSA C22.2 No 14
EAC
Ordering and shipping details
Category 21561 - XMLK,XMLP PRESSURE TRANSMITTERS
Discount Schedule DS2
GTIN 00785901698449
Nbr. of units in pkg. 1
Package weight(Lbs) 0.28000000000000003
Returnability Y
Country of origin CH
Offer Sustainability
RoHS (date code: YYWW) Compliant - since 1001 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
California proposition 65 WARNING: This product can expose you to chemicals including:
- - - - - - - Substance 1 Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
- - - - - - - Substance 2 Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
- - - - - - - More information For more information go to www.p65warnings.ca.gov
reproductive harm.
