Product data sheet
Characteristics
XCRF57
limit switch XCR - metal stay put T rods lever
square rod 6 mm - 2X(1NC+NO)
Main
Range of product OsiSense XC
Series name Special format
Product or component type Limit switch
Product specific application For hoisting and mechanical handling applications
Device short name XCR
Sensor design -
Body type Fixed
Head type Rotary head
Material Metal
Fixing mode By the body
Movement of operating head Rotary
Type of operator Metal stay put crossed rods lever (square rod 6 mm)
Type of approach 2 directions lateral approach
Electrical connection Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²
Number of poles 4
Contacts type and composition 2 x (1 NC + 1 NO)
Contact operation Slow-break, break before make
Contact block per direction [control
circuit]
Positive opening With
1 per direction
Complementary
Body material Zinc alloy
Switch actuation By any moving part
Cable entry 1 entry tapped for Pg 13.5 cable gland, cable outer diameter: 9...12 mm conforming to NF C 68-300
Contacts insulation form Zb
Number of steps 1
Mar 22, 2018
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Positive opening minimum torque 0.7 N.m
Minimum torque for tripping 0.6 N.m
Minimum actuation speed 6 m/min
Maximum actuation speed 1.5 m/s
Maximum displacement angle 90 °
Contact code designation A300, AC-15 240 V, Ie = 3 A) conforming to EN/IEC 60947-5-1 appendix A
[Ui] rated insulation voltage 300 V conforming to CSA C22.2 No 14
Resistance across terminals <= 25 MOhm conforming to IEC 60255-7 category 3
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60664
Short-circuit protection 10 A by gG cartridge fuse
Electrical durability 5000000 cycles, DC-13 inductive load type, 120 V, 4 W, load factor: 0.5, operating rate: <= 60 cyc/
Mechanical durability 10000000 cycles
Width 85 mm
Height 95 mm
Depth 75 mm
Product weight 1.135 kg
Terminals description ISO n°1 (13-14)NO
Compatibility code XCR
-90 °
Q300, DC-13 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1 appendix A
500 V degree of pollution 3 conforming to IEC 60947-1
500 V degree of pollution 3 conforming to VDE 0110
300 V conforming to UL 508
6 kV conforming to IEC 60947-1
mn IEC 60947-5-1 appendix C
5000000 cycles, DC-13 inductive load type, 24 V, 7 W, load factor: 0.5, operating rate: <= 60 cyc/mn
IEC 60947-5-1 appendix C
5000000 cycles, DC-13 inductive load type, 48 V, 10 W, load factor: 0.5, operating rate: <= 60 cyc/
mn IEC 60947-5-1 appendix C
(21-22)NC
Environment
Shock resistance 68 gn conforming to IEC 60068-2-27
Vibration resistance 9 gn (f = 10...500 Hz) conforming to IEC 60068-2-6
IP degree of protection IP54 conforming to IEC 60529
Overvoltage category Class I conforming to NF C 20-030
Ambient air temperature for operation -25...70 °C
Ambient air temperature for storage -40...70 °C
Protective treatment TC
Product certifications CCC
Standards EN 60204-1
Class I conforming to IEC 61140
CSA
EN 60947-5-1
IEC 60204-1
IEC 60947-5-1
NF C 79-130
CSA C22.2 No 14
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 1402 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product end of life instructions Need no specific recycling operations
