Product data sheet
Characteristics
XCKJ10541
limit switch XCKJ - th.plastic roller lever var.
length - 1NC+1NO - snap - Pg13
Main
Range of product OsiSense XC
Series name Standard format
Product or component type Limit switch
Device short name XCKJ
Sensor design -
Body type Fixed
Head type Rotary head
Material Metal
Body material Zamak
Head material Zamak
Fixing mode By the body
Movement of operating head Rotary
Type of operator Spring return roller lever thermoplastic (variable length)
Type of approach Lateral approach 1 or 2 programmable direction
Cable entry 1 entry tapped for Pg 13.5 cable gland, cable outer diameter: 9...12 mm
Number of poles 2
Contacts type and composition 1 NC + 1 NO
Contact operation Snap action
Complementary
Switch actuation By 30° cam
Electrical connection Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mm²
Contacts insulation form Zb
Number of steps 1
Positive opening Without
Minimum torque for tripping 0.25 N.m
Maximum actuation speed 1.5 m/s
Jul 12, 2018
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
[Ie] rated operational current 3 A at 240 V, AC-15, A300 conforming to EN/IEC 60947-5-1 appendix A
[Ithe] conventional enclosed thermal
current
[Ui] rated insulation voltage 300 V conforming to CSA C22.2 No 14
Resistance across terminals <= 25 MOhm conforming to IEC 60255-7 category 3
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60664
Short-circuit protection 10 A by gG cartridge fuse
Electrical durability 5000000 cycles, DC-13, inductive load type, 24 V, 10 W, operating rate: <= 60 cyc/mn, load factor:
Mechanical durability 30000000 cycles
Width 40 mm
Height 77 mm
Depth 44 mm
Product weight 0.485 kg
Terminals description ISO n°1 (13-14)NO
0.27 A at 250 V, DC-13, Q300 conforming to EN/IEC 60947-5-1 appendix A
10 A
500 V degree of pollution 3 conforming to IEC 60947-1
300 V conforming to UL 508
6 kV conforming to IEC 60947-1
0.5 conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13, inductive load type, 48 V, 7 W, operating rate: <= 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13, inductive load type, 120 V, 4 W, operating rate: <= 60 cyc/mn, load factor:
0.5 conforming to IEC 60947-5-1 appendix C
(21-22)NC
Environment
Shock resistance 50 gn (duration = 11 ms) conforming to IEC 60068-2-27
Vibration resistance 25 gn (f = 10...500 Hz) conforming to IEC 60068-2-6
IP degree of protection IP66 conforming to IEC 60529
IK degree of protection IK07 conforming to EN 50102
Overvoltage category Class I conforming to NF C 20-030
Ambient air temperature for operation -25...70 °C
Ambient air temperature for storage -40...70 °C
Protective treatment TC
Product certifications CCC
Standards CENELEC EN 50041
Class I conforming to IEC 61140
CSA
UL
EN 60204-1
EN 60947-5-1
IEC 60204-1
IEC 60947-5-1
UL 508
CSA C22.2 No 14
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 0951 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Product end of life instructions Need no specific recycling operations
Contractual warranty
Warranty period 18 months
2
Product data sheet
Dimensions Drawings
Dimensions
XCKJ10541
(1) 1 tapped entry Pg 13.5
3
Product data sheet
Mounting and Clearance
Mounting with Cable Entry
Position of Cable Gland
(1) Recommended
(2) To be avoided
XCKJ10541
4
Product data sheet
Mounting and Clearance
Mounting with Rotary Heads and Levers
Type of Cam
(1) Recommended
(2) To be avoided
XCKJ10541
5
Product data sheet
Mounting and Clearance
Setting-up with Lever Head
XCKJ10541
(1) 5° steps throughout 360° / Tightening torque (Min : 1) (Max : 1.5)
(2) 45° steps throughout 360° / Tightening torque (Min : 1) (Max : 1.5)
(a) Tightening torque (Min : 1) (Max : 1.5)
6
Product data sheet
Mounting and Clearance
Setting-up with Head ZCKE05
Direction of Actuation Programming
XCKJ10541
7
Product data sheet
Connections and Schema
Wiring Diagram
2-pole NC + NO Snap Action
XCKJ10541
8
Product data sheet
Technical Description
Characteristics of Actuation
Switch Actuation by 30° Cam
XCKJ10541
9
Product data sheet
Technical Description
Functionnal Diagram
(1) Closed
(2) Open
(3) Tripping
(4) Resetting
XCKJ10541
XCKJ10541 is replaced by:
Industrial range XCKJ10541H29
limit switch XCKJ - th.plastic roller lever var. length - 1NC+1NO - snap - M20
Qty 1
Reason for Substitution: Rebranding | Substitution date: 15 February 2006
