Product data sheet
Characteristics
Main
Range of product Harmony XB5
Bezel material Plastic
Product or component type Annunciator
Mounting diameter 22 mm
Head type Standard
Cap/Operator or lens colour Black
XB5KSB
continuous or intermittent buzzer 24v ac/dc
Complementary
[Us] rated supply voltage 24 V (+/- 10 %)
Supply circuit type AC/DC
Supply frequency 50/60 Hz
Current consumption <= 28 mA
Signalling type Continuous or intermittent tone
Resistance to high pressure washer 9000000 Pa at 82 °C,distance: 0.1 m
Height 29 mm
Width 29 mm
Depth 55 mm
Product weight 0.024 kg
Environment
Noise level 90 dB 4 kHz
90 dB 6.8 kHz
Protective treatment TH
Ambient air temperature for storage -40...70 °C
Ambient air temperature for operation -40...70 °C
Overvoltage category Class II conforming to IEC 60536
Electrical shock protection class Class II conforming to IEC 60536
IP degree of protection IP69
IP67
IP66 conforming to IEC 60529
IP69K
NEMA degree of protection NEMA 13
Feb 12, 2018
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
NEMA 4X
IK degree of protection IK03 conforming to EN 50102
Standards EN 60947-1
Product certifications BV
IK03 conforming to IEC 50102
EN 60947-5-1
EN 60947-5-4
IEC 60947-1
IEC 60947-5-1
IEC 60947-5-4
JIS C 4520
UL 508
CSA C22.2 No 14
CSA
DNV
GL
LROS (Lloyds register of shipping)
RINA
UL listed
Contractual warranty
Warranty period 18 months
