Product datasheet
Characteristics
XACA201
pendant station XAC-A pistol grip - 2 push buttons
Main
Range of product Harmony XAC
Product or component type Pendant control station
Device short name XACA pistol grip
Complementary
Control station type Double insulated
Enclosure material Polypropylene
Control type Intuitive
Electrical circuit type Control circuit
Enclosure type Complete ready for use
Control station application Control of single speed hoist motor
Control station composition 2 push-buttons
Control button type First push-button 1 NO raise, slow
Second push-button 1 NO lower, slow
Product compatibility ZB2BE101 for each direction
Mechanical interlocking With mechanical interlocking
Control station colour Yellow
Connections - terminals Screw clamp terminals 1 x 2.5 mm² with or without cable end
Screw clamp terminals 2 x 1.5 mm² with or without cable end
Standards EN/IEC 60204-32
EN/IEC 60947-5-1
UL 508
CSA C22.2 No 14
Product certifications CSA
UL
Protective treatment TH
Ambient air temperature for operation -25...70 °C
Ambient air temperature for storage -40...70 °C
Vibration resistance 15 gn 10...500 Hz IEC 60068-2-6
Shock resistance 100 gn IEC 60068-2-27
Overvoltage category Class II IEC 61140
IP degree of protection IP65 IEC 60529
IK degree of protection IK08 EN 50102
12 Jan, 2019
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Mechanical durability 1000000 cycles
Cable entry Rubber sleeve with stepped entry 7...15 mm
Contact code designation A600 AC-15 240 V 3 A IEC 60947-5-1 appendix A
[Ithe] conventional enclosed thermal
current
[Ui] rated insulation voltage 600 V 3 IEC 60947-1
[Uimp] rated impulse withstand voltage 6 kV IEC 60947-1
Contact operation Slow-break
Resistance across terminals <= 25 MOhm
Operating force 13...15 N
Short-circuit protection 10 A fuse protection cartridge gG
Rated operational power in W 40 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C
Terminals description ISO n°1 (13-14)NO
Terminal identifier (11-12)NC
Product weight 0.27 kg
A600 AC-15 600 V 1.2 A IEC 60947-5-1 appendix A
Q600 DC-13 250 V 0.27 A IEC 60947-5-1 appendix A
Q600 DC-13 600 V 0.1 A IEC 60947-5-1 appendix A
10 A
48 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C
65 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C
(13-14)NO
Contractual warranty
Warranty period 18 months
