Product data sheet
Characteristics
VW3A9509
kit for flush-mounting in a dust and damp proof
enclosure - ATV61/ATV71
Main
Range of product Altivar
Accessory / separate part category Mounting and fixing accessory
Accessory / separate part type Mounting kit
Product compatibility ATV61HD37Y
Accessory / separate part destination Variable speed drive
Range compatibility Altivar 61
Product specific application For mounting the drive power section outside the enclosure
ATV61HD45N4
ATV61HD45Y
ATV61HD55N4
ATV61HD55Y
ATV61HD75N4
ATV61HD75Y
ATV61HD90Y
ATV71HD37Y
ATV71HD45N4
ATV71HD45Y
ATV71HD55N4
ATV71HD55Y
ATV71HD75N4
ATV71HD75Y
ATV71HD90Y
Altivar 71
Complementary
Kit composition Fixing accessories
Product weight 5.2 kg
1 user manual
1 cutting and drilling template
1 fan support
1 metal frame of the right size for drive rating
Corner pieces
Seals
Jul 28, 2017
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Environment
Environmental characteristic Dust and damp proof
Contractual warranty
Warranty period 18 months
