Product data sheet
Characteristics
QO115GFI
Mini CB, QO, 15 A, 1P, 120 V, 10 kA, Plug in, GFI
Product availability : Stock - Normally stocked in distribution facility
Main
Product Miniature circuit-breaker
Range QO
Line Rated Current 15 A
System Voltage 120 V AC
Mounting Type Plug-in
Number of Poles 1P
Circuit Breaker Type Ground fault protecting class A 6 mA
Ratings Not rated
Electrical Connection Pressure plate
Complementary
Inturrupt Rating 10 kA at: 120 V AC 50/60 Hz
Number of Panel Spaces 1
Wire Size AWG 14...AWG 8 (copper)
Height 4.12 in
Depth 2.91 in
Width 0.75 in
AWG 12...AWG 8 (aluminium)
Environment
Certifications CSA
Ambient Rating 104 °F (40 °C)
UL listed
Ordering and shipping details
Category 00003 - QO 1&2 POLE GFI CB 30A MAX
Discount Schedule DE2A
Mar 12, 2019
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
GTIN 00785901255062
Nbr. of units in pkg. 1
Package weight(Lbs) 0.5
Returnability Y
Country of origin MX
Offer Sustainability
Sustainable offer status Green Premium product
RoHS (date code: YYWW) Compliant - since 1340 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference contains SVHC above the threshold - Go to CaP for more details
Go to CaP for more details
Product environmental profile Available
Product end of life instructions Available
California proposition 65 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Contractual warranty
Warranty period 18 months
