Product data sheet
Characteristics
MG24110
SUPPLEMENTARY PROTECTOR 277V 1AMP
1P
Main
Circuit breaker applicationcircuit breaker application
Device short namedevice short name
Range of productrange
of product
Circuit protection
C60N
Multi 9
Complementary
Line Rated CurrentLine Rated Current 1 A
System VoltageSystem Voltage 240 V AC
AWG gaugeAWG gauge AWG 14...AWG 4 copper
Breaking capacitybreaking capacity 5 kA 277 V AC
Circuit breaker typecircuit breaker type Standard
Depthdepth 3 in
Heightheight 3.19 in
Magnetic tripping limitmagnetic tripping limit 3.2...4.8 x In B
Mounting supportmounting support DIN rail 35 mm
Number of polesnumber of poles 1
Product destinationproduct destination Panel OEM
Product weightproduct weight 3.85 oz
Protection typeprotection type Short-circuit
Widthwidth 0.71 in
10 kA 120/240 V AC
Environment
Standardsstandards IEC 60947-2
UL 1077
Ordering and shipping details
CategoryCategory 00908 - C60N SUPP PROTECTORS
Discount ScheduleDiscount Schedule DE2
GTINGTIN 00785901880097
Nbr. of units in pkg.Nbr. of units in pkg. 1
ReturnabilityReturnability Y
Country of originCountry of origin FR
Aug 8, 2016
1
Offer Sustainability
Sustainable offer statusSustainable offer status Green Premium product
RoHS (date code: YYWW)RoHS (date code: YYWW)
REAChREACh Reference not containing SVHC above the threshold
Product environmental profileProduct environmental
profile
Product end of life instructionsProduct end of life instructions
Compliant - since 1310 - Schneider Electric declaration
of conformity Schneider Electric declaration of conformity
Available
Need no specific recycling operations
Contractual warranty
Warranty periodWarranty period 18 months
