Product data sheet
Characteristics
H361
SWITCH FUSIBLE HD 600V 30A 3P NEMA1
Product availability: Stock - Normally stocked in distribution facility
Main
Commercial Status Commercialised
Product or component
type
Line Rated Current 30 A
Product certifications UL listed
NEMA degree of
protection
Device composition None
Disconnector device
type
Short-circuit current 200 kA R, J or L
Device mounting Surface
Number of poles 3
Electrical connection Lugs
Series name Heavy duty
System Voltage 600 V AC/DC
AWG gauge 14...6 AWG copper
Single Throw Safety Switch
NEMA 1 steel
Fusible disconnect
10 kA H or K
12...6 AWG aluminium
Ordering and shipping details
Category 00008 - H&HU, 2&3P, N1, 30-200A
Discount Schedule DE1
GTIN 00785901481843
Nbr. of units in pkg. 1
Package weight(Lbs) 8.04
Product availability Stock - Normally stocked in distribution facility
Returnability Y
Country of origin US
Offer Sustainability
Sustainable offer status Not Green Premium product
RoHS (date code: YYWW) Will be Compliant on 3Q2014
REACh Reference not containing SVHC above the threshold
Contractual warranty
Period 18 months
Jan 12, 2015
