Product data sheet
Characteristics
9001SKS11B
30MM SELECTOR SWITCH 2 POSITION
Main
Range of product Harmony 9001SK
Product or component type Selector switch
Device short name 9001SK
Complementary
Bezel material Plastic
Mounting diameter 30 mm
Device presentation Basic element
Compatibility code 9001SK
Environment
Protective treatment TC
Ambient air temperature for storage -40...70 °C
Ambient air temperature for operation -25...70 °C
Electrical shock protection class Class II conforming to IEC 61140
IP degree of protection IP66 conforming to IEC 60529
NEMA degree of protection NEMA 1/2/3/3R/4/4X/6/12/13
Product certifications CE
UL listed file E42259 CCN NKCR
CSA LR24590 class 3211 03
Offer Sustainability
RoHS (date code: YYWW) Compliant - since 0921 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
Mar 12, 2018
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
