Product data sheet
Characteristics
9001K2L35GH13
green illuminated pushbutton Ø 30 - projecting
spring return - 24V - 1OC
Main
Range of product Harmony 9001K
Product or component
type
Device short name 9001K
Type of operator Spring return
Operator profile Green projecting unmarked
Complementary
Bezel material Chromium plated metal
Mounting diameter 30 mm
Shape of signaling unit head Octagonal
Light source Incandescent
Bulb base BA 9s
Light block supply Direct
[Us] rated supply voltage 24 V AC/DC
Connections - terminals Screw clamp terminals (1 x 0.22...2 x 1.5 mm²) conforming to IEC 60947-1
Tightening torque 0.8 N.m conforming to IEC 60947-1
Shape of screw head Cross slotted
Mechanical durability 5000000 cycles
Operating position Any position
[Ui] rated insulation voltage 250 V (degree of pollution: 3) conforming to IEC 60947-1
[Uimp] rated impulse withstand voltage 2.5 kV conforming to IEC 60947-1
Contacts material Silver alloy contacts
Contacts operation Standard
Positive opening Without
Short circuit protection 10 A cartridge fuse conforming to IEC 60947-5-1
[Ith] conventional free air thermal current 10 A
[Icm] rated short-circuit making capacity <= 60 kA at 120 V (AC-15) 7200 VA
<= 30 kA at 240 V (AC-15) 7200 VA
<= 15 kA at 480 V (AC-15) 7200 VA
<= 12 kA at 600 V (AC-15) 7200 VA
Rated breaking capacity <= 6 kA at 120 V (AC-15) 720 VA
<= 3 kA at 240 V (AC-15) 720 VA
<= 1.5 kA at 480 V (AC-15) 720 VA
<= 1.2 kA at 600 V (AC-15) 720 VA
<= 0.55 kA at 125 V (DC-13)
<= 0.27 kA at 250 V (DC-13)
<= 0.1 kA at 600 V (DC-13)
CAD overall width 54 mm
CAD overall height 42 mm
CAD overall depth 103 mm
Terminals description ISO n°1 (13-14-11-12)OF
Product weight 0.166 kg
Complete illuminated pushbutton
Aug 5, 2015
1
Environment
Standards CSA C22-2 No 14
Product certifications NEMA
Protective treatment TC
Ambient air temperature for storage -40...70 °C
Ambient air temperature for operation -25...70 °C
Vibration resistance 7 gn (f = 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance 50 gn conforming to IEC 60068-2-27
Class of protection against electric shock Class II conforming to IEC 61140
IP degree of protection IP66 conforming to IEC 60529
NEMA degree of protection NEMA 4
RoHS EUR status Compliant
RoHS EUR conformity date 0921
EN/IEC 60947-1
EN/IEC 60947-5-1
EN/IEC 60947-5-4
JIS C 4520
JIS C 852
UL 508
UL 508
NEMA 3R
NEMA 3
NEMA 2
NEMA 13
NEMA 12
NEMA 1
