Product data sheet
Characteristics
460R480
TRANSFORMER VOLTAGE 480:120 0.6W
Main
Product Voltage transformer
Certifications UL Listed
Ratio 4/1
Enclosure Type NEMA 1
Phase 1 phase
Primary Voltage 480 V
Power Rating 150VA
Secondary Voltage 120 V
Electrical Connection Studs
Ordering and shipping details
Category 15505 - CLASS 4210 VT'S (LC 5101)
Discount Schedule PA1
GTIN 00785901098546
Nbr. of units in pkg. 1
Package weight(Lbs) 8.5lb(US) (3.86kg)
Returnability Yes
Country of origin US
Packing Units
Package 1 Height 6.40in (16.256cm)
Package 1 width 6.80in (17.272cm)
Package 1 Length 7.80in (19.812cm)
*Price is “List Price” and may be subject to a trade discount – check with your local distributor or retailer for actual price.
Aug 6, 2020
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
1
Offer Sustainability
California proposition 65 WARNING: This product can expose you to chemicals including: Formaldehyde (gas) which
REACh free of SVHC Yes
EU RoHS Directive Compliant
Toxic heavy metal free Yes
Mercury free Yes
RoHS exemption information Yes
China RoHS Regulation China RoHS declaration
PVC free Yes
Halogen content performance Halogen free plastic parts product
is known to the State of California to cause Carcinogen harm. For more information go to
www.p65warnings.ca.gov
EU RoHS Declaration
Pro-active China RoHS declaration (out of China RoHS legal scope)
Contractual warranty
Warranty 18 months
