SQT Electronics R116 User Manual

Par t 1.0 : Gen eral Featu res

- Full size slim wireless keyboard

- Totally Wireless freedom

- 2.4GHz FSK Autolink technology

- 34 two way R F channels

- Operation distance of 6~10 meters for mouse and keyboard

- Nano receiver for this combo

Par t 2.0 : Phy sic al chara cte ristics

Keyboard

SK-626AG RF2.4GHz Keyboar d

SPECIFICATIONS

SK-626AG

Par t 3.0 : Ele ctr ica l Spe cificatio n

Interface : USB 1.1
Sensor report rate on mouse: times per second 3000
Operation angle: 360 degrees
Operation distance: 6~10 meter for keyboard and
mouse
Receiver power requirement: 5V DC from USB port

R F frequency: 2.4 Ghz (2.408~2.474 Ghz)
R F modulation : F S K Auto-Link
Hopping type : FHSS (frequency hopping spread
spectrum)
R F channel : 34 channels
R F bandwidth : 2.0mHz
Speed of transmit: 1M bps
R F output power : 0dBm
Receiver of sensitive: -85dBm

Mechanical Performance

Operating force of wheel scrolling

Operating force of keyboard keycaps

Buttons

Keyboard : 86 standard keys,

Weight:

Keyboard: 516.2 5 g (battery included)
Receiver: 2 1 g

Multimedia Hotkeys functions:

FN+ESC=Media Player

FN+F1=Play/Pause

FN+F2=Previous Track

RECEIVER

20 10 gf

60 15 gf

FN+F6=Mute

FN+F7=Web home

FN+F8=Search

Battery

Battery type: twoAAAalkaline for keyboard
Battery consumption:

Keyboard:Operating Mode: 6 mA

keyboard:3.0V

Par t 4.0 : Reliab ili ty

Keyboard Button Switch Activation: 8,000,000 cycle
Operating temperature: -5 ~ 40 degrees celsius

Operating humidity: 20% - 90%

Par t 5.0 S yst em Requirem ent

Windows 2000, Windows xp. Windows ME.
Windows VISTA, Windows 7/8/10

FN+F3=Next Track

FN+F4=Volume Up

FN+F5=Volume Down

FN+F9=M y Favorite

FN+F10= Email

FN+F11=Screen Lock

FN+F12= My computer

REV: 1.00
