Mini Desk/Travel Clock Camera
Quick start guide
www.spytecinc.com
Getting Started with Your Clock
1. On the right side of the clock, rotate the black side
panel counter-clockwise to locate the USB port, Micro
SD Card Slot and On/O switch for the hidden camera.
2. Locate the Micro SD card slot labeled “TF”. Insert your
Micro SD card into the slot with the gold contacts facing up.
3. Connect the USB power adapter for 4 hours to fully
charge the clock.
4. Put the On/O switch in the ON position to enable
the camera feature.
5. On the remote, pull the plastic tab from battery to
activate the remote.
6. While pointing the remote at the clock, press the
button and a blue light will appear at the bottom-right
side of the clock, indicating that the clock’s camera
is in stand-by mode. Pressing the button again
will cause the light to disappear, indicating that the
camera is turned o.
Using the Video Recording Feature
1. While the clock is in stand-by mode, press the
button on the remote and the blue light will slowly
blink 3 times and shut o. The clock will now be recording.
2. To stop recording, press the button again and
the blue light will reappear.
Using the Motion Detection Video Recording
1. While the clock is in stand-by mode, press the motion detect button, symbolized by the icon showing a
camera and stick figure. Once pressed, the blue light
will blink 3 times and shut o. The clock will now record any motion that is detected.
2. To stop recording, press the same button again and
the blue light will reappear.
Using the Camera to Take Pictures
1. While the clock is in stand-by mode, press the
to take a picture. The blue light will turn o and reappear after 2 seconds.
Using the Voice Recorder Feature
1. While the clock is in stand-by mode, press the microphone button on the remote and the blue light will
blink 3 times and shut o. The clock will start voice
recording.
2. To stop the recording, press the microphone button
again.
View Videos on a PC or Mac
1. On a PC
a. Turn the On/O switch near the battery to the ON posi-
tion and press the button on the remote to switch on
the camera.
b. Connect the Clock to the PC using the enclosed USB cable.
c. Double-click on “My Computer” and locate “Removable
Disk”.
d. Double-click on “Removable Disk”.
e. Double-click on “DCIM”.
f. Double-click on “10020101”.
g. You may now copy, move, or play your video files.
2. On a Mac
a. Turn the On/O switch near the battery to the ON posi-
tion and press the button on the remote to switch
on the camera.
b. Connect the Clock to the Mac using the enclosed USB
cable.
c. The Clock will be recognized as an External Hard Drive.
d. Double-click on the External Hard Drive.
www.spytecinc.com
