Intelligent Network Pan & Tilt Camera
Quick Operation Guide www.spypet.net
In The Box
1. SPYPET Camera
2. USB Power Adaptor (10w/2Amp)
3. USB Power Cable
4. Temperature & Humidity Sensor (Option)
5. Installation Base & 4 x Screws
3. USB Power Cable
2. USB Power Adaptor
1. SPYPET Camera
2
5. Installation Base & 4 x Screws
4. Temperature & Humidity Sensor
SPYPET Features
1. Photoresistor: Color/B&W
2. Infrared LED’s
3. LED: Network, Record & Alarm
4. 720P HD Lens
5. Microphone
6. LAN Interface
7. Temperature & Humidity Sensor:
(Optional) set and monitor temperature range for your pet.
8. Reset Button: Continuous 5 second press for restoring factory default camera settings.
9. Antenna Interface
10. Power: Connection of USB Power Adaptor (10w/2Amp)
11. MicroSD Card: Insert MicroSD card (maximum 32Gb) allowing user to record video clips.
12. Speaker
Wi-Fi Antenna Built into SPYPET camera
3
Step 1
Download SPYPET App
1. IOS (Apple) clients search & download “SPYPET” from the Apple App Store.
2. Android clients search & download “SPYPET”from the Google Play Store.
Step 2
Add a SPYPET Camera
Once App has been downloaded for your smartphone Go to ”My Camera”
Please Note: Camera default password is 123 (this can be changed later in “Settings” within
the App). The default password “123” is also found on the base of the SPYPET camera.
You have two options to connect your SPYPET camera…
1. Smart Wi-Fi
If you choose to connect via Smart Wi-Fi, you will need to press and hold the RESET button
for 5 to 10 seconds until you hear a “Whoosh” sound which means that the camera has
been successfully reset. At this point – the camera will reboot and you will hear a “DDD”
sound. Smart Wi-Fi can now be started and connected automatically.
4
2. Manual
If you choose to connect via the manual option, it is simply a matter of connecting an
Ethernet cable from your SPYPET camera to your router, and inputing the “Input device ID”
(This is a unique series of numbers found on the base of your SPYPET camera) input the
device name, this is optional if you wish to customize the name of your SPYPET camera,
and finally input device password (This is the default password 123).
1. First, Connect USB Power Adaptor & USB Power Cable into camera.
2. Next, connect Ethernet cable (supplied) from SPYPET camera to your router LAN port.
3. Finally, once connected successfully, you will see a constant orange and flashing
Green lights on camera LAN port.
5
Step 4
Check for the latest firmware update
We are constantly improving and adding features to SPYPET for a better user experience,
to do this: Go to the sliding menu tab, found on the top left hand side of the App, then
go to “About” “Check about Version” Then Check the camera is updated,
go to “My Camera” “settings” “Device Update”.
6
Mounting Options Available to Enjoy SPYPET
Your SPYPET camera can simply be mounted on any flat surface, remember, once your
SPYPET camera is connected to your Wi-Fi network, all you need to do is have the power
connected to the back of the camera and PRESTO you are on-line!
If you prefer – you are able to mount your SPYPET camera either on a vertical wall or on
a ceiling, to do this simply use the transparent install base provided in the packaging
with the supplied screws.
Please Note:
When using the install base, ensure the surface wall or ceiling area is flat and clean, and be
sure you look for the marked on the install base this will ensure it aligns with the camera
direction. Once you have the install base affixed to your flat surface with the screws, take
your SPYPET camera and turn it clockwise until you hear a “click” sound, once you hear
this sound the camera is now safely connected to the install base.
Don’t forget to consider concealing your power supply, if you are mounting
your SPYPET camera on a wall or ceiling.
7
SPYPET Camera Features
Real 720P HD Network Camera
Supports 2 way audio communication
Supports Smart Wi-Fi link
Alarm Notifications – sends photo snapshot & video to your email
Supports motion detection trigger alarm
Supports temperature & humidity display (optional)
Supports Max 32Gb MicroSD card format
FAQ’s – Refer back to the website for further information www.spypet.net
1. Q. When adding a camera, the App didn’t prompt the discovery
of a new camera?
A. Check to ensure the camera & smartphone are on the same LAN network
2. Q. When viewing live video, the App comes up with “incorrect password”.
A. Please check and ensure that the remote access password which is being used by the
camera is correct. If not, select edit and rest the password from the list of entries from
the camera. Please Note: If you have forgotten your remote access password, we suggest
you press the reset button to restore the camera to factory default (password: 123).
3. Q. Unable to search for recorded video clips.
A. Please check and ensure the MicroSD card is not damaged and or inserted in
the correct way, also check and ensure the correct time and date have been
set on the camera.
