SPT SH-113FB, SH-113FP, SH-113FW User Manual

This product contains Li-Batteries inside. Before initial
use or after a long period of non-usage, please fully
charge the warmer.
* Be cautious of low temperature burn.
* Li-Batteries are rechargeable up to 500 times and will
retain up to 80% of standard capacity.

PART IDENTIFICATION

Power Key
(On/Off, High,
Low)

Indicator Light

front back

Mini USB
interface (B­female socket)

Heat plate
Lanyard hole
USB to Mini USB cable

USB to AC power adapter

CHARGING

USB power

Personal computer / laptop

 Connect Mini-USB plug of dedicated charging line into

warmer’s Mini-USB socket.

 Connect USB plug of dedicated charging line to

standard USB equipment, such as PC, notebook, etc.
* While charging, unit will power off (heat function
stops) and Power key will not respond.
When charging is complete, all lights will illuminate
with no rotation.
* Charging time is approximated 5 hours.

 Disconnect cable when charging is completed.

* Charge unit within ambient temperature of 32-104°F.
* If charging causes static in radio or TV, please relocate unit to a
different location.

OPERATING INSTRUCTIONS

Cold hands

Backaches

Muscle pain

Menstrual pain

 In OFF mode, press and hold the Power Key for 3

seconds to turn on warmer. Lights will rotate twice
(clockwise)

 Warmer will begin to heat in Low setting.
 Double click the Power Key to switch between Low

and High setting.

 To turn off warmer, press and hold Power Key for 3

seconds. Lights will rotate twice (counter-clockwise).

 Heat function will turn off when warmer is in charge.
 When using the warmer in very cold weather, the

heating temperature may not be sufficient enough. To
isolate from cold environment, it is suggested to wrap
the warmer with cloth, such as a sock or glove.
* Only the metal side of the warmer will heat.
* Power Key doesn’t work in charge mode.

REMAINING BATTERY CAPACITY

Indicated once after warmer is turned on (after the lights rotate twice
clockwise).

LIGHTS STATUS

CAPACITY

Lights step slowly from 1 to 4
then back from 4 to 1

≤100%

Lights step slowly from 1 to 3
then back from 3 to 1.

≤75%

Lights step slowly from 1 to 2
then back from 2 to 1

≤50%

prepare to charge

Light 1 blinks

≤25%

low capacity

please charge soon

LIGHTS STATUS

LIGHTS STATUS

INDICATION

Two lights blink slowly on and off

Heating in low setting

Four lights blink slowly on and off

Heating in high setting

Four lights constantly rotate counter­clockwise

Charging

Four lights remain on

Charging completed

Fast clockwise rotation (twice)

Turning on

Fast counter-clockwise rotation (twice)

Turning off

HEATING TEMPERATURE

Heat

Setting

Highest

Temperature*

Average

Temperature**

Usage

Time***

Low

104°F

100°F

Approx 10 hrs

High

113°F

106°F

Approx 7 hrs

* Highest temperature: temperature standing after 1 hour.
** Average temperature based on 68°F ambient temperature.
*** Usage time may vary due to different ambient temperature.

SPECIFICATION

Model

SH-113F

Input

5V – 1A

Dimension

3.57L x 2.6W x 0.8H inches

Weight (unit only)

3.175 oz.

Heat temperature range

100°F ~ 113°F

Operating temperature range

14°F ~ 113°F

Batteries (inside)

Li-batteries 3.7V 2600mAh

Charge time

Approx 5 hours

Heating time

Approx 7 ~ 10 hours

CAUTION

Do not use warmer
in high moisture
environments, such
as bathroom.

Do not place in
oven; keep away
from heat sources

Avoid impact

Do not use near
flammable or
explosive objects

PORTABLE WARMER

SH-113FB (Black)
SH-113FP (Pink)
SH-113FW (White)

User manual
Thank you for your purchase. Please read this user manual thoroughly
before using. Keep in safe place for future reference.

Stop using if unusual
smell, discoloration
or deformation
occurs

To prevent warmer
from dropping, do
not place warmer
on sloped surfaces

If liquid from warmer
leaks and comes in
contact with eyes,
flush with clean
water immediately
and consult a
physician

Keep away from
reach of young
children. Keep
close supervision
when used by child

What is low-temperature burn?

Low temperature burn occurs when body is in prolong contact with an
object that has a temperature slightly higher than body temperature.
Symptoms may include redness and blistering.

Avoid low-temperature burn

This product is controlled by a microcomputer ship, which is designed
with comprehensive consideration of temperature that can cause low­temperature burn. To prevent low-temperature burn:

 Do not place warmer on one specific area for too long
 Stop using immediately if you sense something unusual
 Do not use while sleeping.

TROUBLESHOOTING

SYMPTOM

POSSIBLE CAUSE

TREATMENT

Not heating

Low capacity

Charge

Power key doesn’t

respond

Unit is charging

Stop charge or wait
till charge complete

Warmer’s usage

time is shorter

Unit not fully charged

Charge till full

Reached batteries’
lifespan. Batteries’

capacity reduces
slightly with each
charge

Replace batteries
Low ambient
temperature

Wrap warmer with
cloth

Long charging time

External temperature
too high or too low

Charge where
ambient
temperature is
between 32°F ~
104°F

Cannot charge
(lights do not rotate)

USB cable not
inserted firmly

Check both ends
for secure
connection

USB equipment has
no 5V output

Try a different
equipment

CLEANING

Wipe product with soft and clean cloth. Do not use wet or damp clost
as it may cause malfunction. Do not use alcohol, thinner, gasoline or
cleanser.

ENVIRONMENTAL PROTECTION

Product contains Li-Batteries, to avoid polluting the environment, do
not dispose dead batteries in garbage, contact your local city hall for
recycling centers.

Your Guarantee

If this product is found to be faulty as a result of faulty
materials or workmanship within one year from date of
purchase, it will be repaired free of charge.

This guarantee is subject to the following terms:

 Sunpentown must be notified of the fault.
 Proof of purchase must be presented to Sunpentown’s

nominated representative.

 The warranty will be void if the product if modified,

misused or repaired by an unauthorized person.

 The warranty after repair will not be extended beyond

the original one-year period.

 All replacement parts will be new or reconditioned.
 Parts, which are replaced, become the property of

Sunpentown.

 The warranty applies for the use of the product in the

USA only.

What is NOT COVERED:

 Warranty does not include freight charges.
 Incidental or consequential damage caused by

possible defects with this product.

 Damage to product caused by improper power supply

voltage, accident, fire, floods or acts of nature.

 Failure of product resulting from unauthorized

modifications to the product.

 Improper installation or failure to perform the

necessary maintenance.

This GUARANTEE is in addition to your Statutory Rights

SUNPENTOWN INTERNATIONAL INC.

14625 Clark Ave, City of Industry, CA 91745

Tel: [phone] · Fax: [phone]

[e-mail]

www.sunpentown.com
