Sprint Mobile Broadband Express Card Modem
by Novatel Wireless
Merlin™ EX720
www.sprint.com
© 2008 Sprint Nextel. All rights reserved. SPRINT and other trademarks are trademarks of Sprint Nextel.
© 2008 Novatel Wireless. All rights reserved. Novatel Wireless, Merlin, and the Novatel Wireless logo are
trademarks of Novatel Wireless.
All other trademarks are property of their respective owners.
Table of Contents
Welcome to Sprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
0A. Your Sprint Mobile Broadband
Express Card Modem ii
0B. How to Use This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Section 1: Introducing the Sprint Moblie Broadband Express Card Modem . . . 1
1A. Introducing the Sprint Mobile Broadband Express Card Modem . . . . . . . . 2
Your Sprint Mobile Broadband Express Card Modem . . . . . . . . . . . . . . . . . . . 2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Section 2: Installing and Using the Express Card Modem. . . . . . . . . . . . . . . . . . . . 5
2A. Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing the Software on a Windows Computer . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing the Software on a Mac Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2B. Using Your Express Card Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Starting the Windows Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Starting the Mac Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Activating Your Express Card Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the PC Card Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Viewing the User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Removing the Express Card Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Attaching an External Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contacting Sprint Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Section 3: Technical Specifications, Regulatory and Safety Information. . . . . . 17
3A. Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
LED Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Environmental Specifications
Mechanical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Transmitter Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Receiver Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Hardware Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3B. Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Regulatory Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Additional Information and Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3C. Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Important Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Safety and Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3D. Novatel Wireless Limited Warranty and Liability . . . . . . . . . . . . . . . . . . . . . . 32
Welcome to Sprint
Sprint is committed to bringing you the best wireless technology available. We
built our network right from the start to give you what we believe you
really want from a wireless service provider—clear connections, private
communications, and time-saving features.
This guide will familiarize you with your new Sprint Mobile Broadband
Express Card Modem through simple, easy-to-follow instructions.
Welcome and thank you for choosing Sprint.
i
Your Sprint Mobile Broadband
Add Product image
Express Card Modem
Thank you for purchasing a Sprint Mobile Broadband Express Card
Modem. This Express Card Modem offers more freedom than ever before.
No wires, no cables—just access to your data when you need it. The
power of the Internet is truly at your fingertips.
ii
How to Use This Guide
The advantages of Sprint are as clear as each wireless connection you
make. With Sprint service, we give you what you really want from a
wireless service provider—clear connections, easy-to-understand
service plans, and self-servicing options for managing your account. All
this is designed to make your life easier and worry-free.
We know you’re eager to start using your Express Card Modem right
away, and the sections of this guide are designed to help you do just
that.
The first section (page 1) gives an overview of the Express Card
Modem package contents.
The second section (page 5) guides you through the steps
required to install your Sprint Mobile Broadband Express Card
Modem and the Windows® or Mac® software, describes how to
start the software once it is installed, and how to use the optional
PC Card Adapter with your Express Card Modem.
The third section (page 21) lists the technical specifications, regulatory
and important safety information for your Sprint Mobile Broadband
Express Card Modem.
Getting More Information About the Express Card Modem and Service
This guide describes how to install and start the software. To learn how
to use all the features of your Express Card Modem and software,
consult the user guide (see page 14 of this document) or online help.
iii
Section 1
Introducing the Sprint Moblie
Broadband Express Card Modem
Section 1A
Introducing the Sprint Mobile Broadband Express Card Modem
⽧ Your Sprint Mobile Broadband Express Card Modem (page 2)
⽧ Package Contents (page 3)
⽧ Care and Maintenance (page 4)
This section introduces your Sprint Mobile Broadband Express Card
Modem, and describes what is included with your Express Card Modem.
Your Sprint Mobile Broadband Express Card Modem
The Novatel Wireless Merlin™ EX720 Express Card Modem is a dualband wireless Express Card Modem. It enhances the functionality of your
mobile computing devices by adding wireless connectivity to the Internet.
Your Sprint Mobile Broadband Express Card fits into an Express Card or
PC Card slot (with a PC Card Adapter) available on most notebook and
desktop computers.
2 Section 1A. Introducing the Sprint Mobile Broadband Express Card Modem
Package Contents
Your Sprint Mobile Broadband Express Card Modem package contains
the following components:
䢇 Sprint Mobile Broadband Express Card Modem by Novatel Wireless
(Merlin™ EX720)
䢇 Getting Started guide (this document)
䢇 PC Card Adapter
Introduction
Section 1A. Introducing the Sprint Mobile Broadband Express Card Modem 3
Care and Maintenance
As with any electronic device, the Express Card Modem must be handled
with care to ensure reliable operation. Follow these guidelines in using
and storing the Express Card Modem:
䢇 The Express Card Modem should fit easily into your Express Card or
PC Card slot (with a PC Card Adapter). Forcing the Express Card
Modem into a slot may damage the connector pins.
䢇 Protect the Express Card Modem from liquids, dust, and excessive heat.
䢇 When not installed in your computer, store the Express Card Modem in
a safe place.
䢇 Remove the Express Card Modem before storing or transporting your
computer.
䢇 When inserting or removing the Express Card Modem, always grip it by
the sides rather than the end, as this prevents damage to the Express
Card Modem antenna and connector.
䢇 Do not use the Express Card Modem with a handheld computer; it is
designed only for notebook or desktop computers running Windows
Vista, Windows XP, or Mac OS X.
䢇 Do not handle or operate the Express Card Modem while driving or
operating a vehicle. Doing so may distract you from properly operating
the vehicle. In some jurisdictions, operating communication devices
while in control of a vehicle is a criminal offense.
4 Section 1A. Introducing the Sprint Mobile Broadband Express Card Modem
Section 2
Installing and Using the
Express Card Modem
Section 2A
Installing the Software
⽧ Installing the Software on a Windows Computer (page 7)
⽧ Installing the Software on a Mac Computer (page 8)
Important
Do not insert your card until you have installed Sprint SmartViewSM
onto your computer or until instructed to do so by Sprint SmartView.
The installation process has two stages:
䢇 Installing the Software and Drivers — Insert the Sprint SmartView Installation
CD to install the drivers and the software (for Windows, see below; for
Mac, see page 8).
Activating Your Express Card Modem — Start the software, activate your
account, and configure the Express Card Modem to use your account.
For complete instructions, consult the user guide, located on the
Installation CD and also available online at
www.sprint.com.downloads.
6 Section 2A. Installing the Software
Installing the Software on a Windows Computer
System Requirements
The Sprint Mobile Broadband Express Card Modem is supported on:
䢇 Windows Vista
䢇 Windows XP with Service Pack 2 or later
To install and run the Express Card Modem and accompanying Sprint
SmartView software on a Windows computer, you will need an Express
Card slot or a PC Card* slot.
* To use the Express Card Modem in a PC Card slot, you must use the
PC Card Adapter. See page X.
This Sprint device is designed to be activated on the Sprint network and has
Note
a software programming lock that, in part, protects many of the device's
features and functions against tampering and unauthorized reprogramming.
This device will work with Sprint services - service plans and other services/
options must be purchased separately. Operates within the Sprint CDMA
frequency band of 800 MHz/1.9 GHz. This device will not operate on any
iDEN network. Coverage is not available everywhere. Product meets current
FCC Radio Frequency Emission Exposure Guidelines. FCC Equipment
Authorization ID number: PKRNVWMX720.
(c)2008 Sprint. Sprint and the logo are trademarks of Sprint. Merlin and the
Novatel Wireless logo are all trademarks of Novatel Wireless Inc. All other
brands and product names are trademarks of their respective owners.
Manufactured under US Patent No. 5129098. Other patents pending. All
rights reserved.
Installing the Software and Drivers
Installing the Software
Windows Vista users: You must log in with administrative privileges to
Note
install the software and drivers.
Windows XP users: You may need to log in with administrative privileges,
depending on your Windows configuration.
As part of the installation process you may be prompted to restart your
computer; save any open documents.
Section 2A. Installing the Software 7
1. If your Express Card Modem has not yet been activated, ensure you
are in the network coverage area (not roaming).
2. Gripping both sides of the Express Card Modem, insert it into your
computer’s Express Card slot.
If your computer does not have an Express Card slot and if you must use a
Note
PC Card slot, you may use the PC Card Adapter that was included in the
box. See page X for instructions on use.
Installing the Software on a Mac Computer
System Requirements
The Sprint Mobile Broadband Express Card Modem is supported on Mac
®
OS
X, version 1.4 or newer, computers equipped with an Express Card
or PC Card slot.
To check your version, from the Apple menu ( ) choose
If your version is earlier, then:
䊳 Visit www.apple.com/downloads/macosx/apple for upgrading
instructions.
– or –
1. In Finder™, choose Go > Applications > System Preferences.
2. Double-click the System Preferences icon.
3. Double-click Software Update.
4. Click Check Now.
To install and run the Express Card Modem and accompanying Sprint
SmartView software on a Mac computer, you will need one Express Card
slot or PC Card slot (for use with the PC Card Adapter).
About This Mac.
8 Section 2A. Installing the Software
Installing the Software and Drivers
As part of the installation process you will be prompted to restart your
Note
computer; save any open documents.
Important
Do not insert your Express Card Modem until you have installed
Sprint SmartView onto your computer or until instructed to do so by
Sprint SmartView.
1. Insert the installation CD for Sprint SmartView, into your PC's CD-
ROM or DVD-ROM drive. The installer should run automatically. If
the setup program does not start, go to Finder and open the
contents of the CD drive. Click to open Sprint SmartView
Installer.mpkg.
The Sprint SmartView software can also be downloaded from
Note
www.sprint.com/downloads.
2. Follow the on-screen instructions, using the Continue and Go Back
buttons to navigate through the installation wizard, noting the
following:
䡲 In order to continue with the installation, you must accept the
terms of the License Agreement.
䡲 Click Install to load the software. You may be prompted to restart
your computer to after the installation completes, if so, click
Continue Installation.
䡲 Click Restart to complete the installation once the Finish Up screen
appears.
Installing the Software
Section 2A. Installing the Software 9
Section 2B
Using Your Express Card Modem
⽧ Starting the Windows Software (page 11)
⽧ Starting the Mac Software (page 11)
⽧ Activating Your Express Card Modem (page 12)
⽧ Using the PC Card Adapter (page 13)
⽧ Viewing the User Guide (page 13)
⽧ Removing the Express Card Modem (page 13)
⽧ Attaching an External Antenna (page 14)
⽧ Contacting Sprint Customer Service (page 14)
⽧ Troubleshooting (page 15)
10 Section 2B. Using Your Express Card Modem
Starting the Windows Software
Important
Do not insert the Express Card Modem into your computer's
Express Card or PC Card Slot (with PC Adapter) until instructed to
do so.
1. Double-click the program’s icon [ ] on your desktop.
– or –
Start > All Programs > Sprint > Sprint SmartView.
Select
2. Sprint SmartView launches and the "No Wireless Device Detected"
dialog appears.
3. Insert the Express Card Modem with the Sprint label facing up into
your computer's Express Card slot or PC Card slot with the PC
Card Adapter (see page XX). (Do not forcefully insert the card, as
this may damage it.)
4. Please wait a few moments while Windows automatically installs
the necessary drivers for this device. A series of "Found New
Hardware" messages appear. Once the driver installation is
complete, the Sprint SmartView dialog changes to read "Ready:
Sprint Mobile Broadband".
Proceed to “Activating Your Express Card Modem” on page 12.
Starting the Mac Software
If the Sprint SmartView software has not started automatically:
䊳 In Finder, choose Go > Applications, and then double-click Sprint
SmartView.
Using Your Modem
Section 2B. Using Your Express Card Modem 11
Activating Your Express Card Modem
If your Express Card Modem has not been preactivated or you have not
activated it at the time of purchase, you must activate your account and
configure the Express Card Modem to use your account.
If the “One Touch Activation” window appears, click Yes to indicate that
you’d like to have the network autoprogram your Express Card Modem.
Sprint SmartView will display “Preparing services, Please wait.”
If One Touch Activation is successful, Sprint SmartView will then display
“Sprint is ready to Connect,” after which you are ready to connect to the
network. Proceed to “Viewing the User Guide” on page 14.
One Touch Activation may also be accessed from the Tools menu. Go to
Note
Tools > Activate Device.
If One Touch Activation was not successful, a message window is
displayed. For instructions on activating your Express Card Modem, see
the user guide (see “Viewing the User Guide” on page 14). Use the
spaces below to write down important information related to the activation
process and your account. ESN/MEID Activation code Sprint Phone
number MSID Account password Sprint User Name.
ESN/MEID
Activation code
Sprint Phone number
MSID
Account password
Sprint User Name
12 Section 2B. Using Your Express Card Modem
Using the PC Card Adapter
ADD IMAGE: EX720
PC Card Adapter
1. Insert the Express Card Modem, label facing up, through the PC
Card Adapter opening, with the Express Card to PCMCIA Adapter
label facing up.
[DO NOT force the Express Card into the PC Card Adapter].
2. Ensure that the Express Card connects or locks with the connector
pins on the adapter.
3. Properly insert into your computer’s PC Card (PCMCIA) slot.
Viewing the User Guide
The user guide provides detailed information on the Windows and Mac
versions of the Sprint SmartView software.
䊳 In Windows, select Start > All Programs > Sprint > Sprint SmartView User
Guide.
– or –
On your Mac desktop, double-click
Sprint SmartView User Guide.PDF.
Removing the Express Card Modem
1. Exit the Sprint SmartView software if it is open.
2. Remove the Express Card Modem from your computer’s Express
Card or PC Card slot by gripping both sides of the Express Card
Modem and pulling straight out
Using Your Modem
WARNING
When inserting or removing your Express Card Modem, always grip it
by its sides, as this prevents damage to the Express Card Modem.
Section 2B. Using Your Express Card Modem 13
Attaching an External Antenna
You can improve the signal strength by attaching an external antenna
with an SMK connector (sold separately).
1. If the Express Card Modem is connected to your computer, remove it.
2. Gently flip open the unlabelled tab on the side of the Express Card
Modem.
3. Hold the antenna cable by the connector (end) part, and carefully
insert the connector part of the cable into the corresponding
connector on the Express Card Modem.
4. Reinsert the Express Card Modem into your computer.
Contacting Sprint Customer Service
You can reach Sprint Customer Service by:
䢇 Logging on to your account at www.sprint.com.
䢇 Calling us toll-free at 1-800-SPRINT1 (personal use) or 1-800-927-2199
(business use).
䢇 Writing to us at Sprint Customer Service, P.O. Box 8077, London, KY
40742.
14 Section 2B. Using Your Express Card Modem
Troubleshooting
For a more complete listing of errors and possible solutions, please see
the user guide or online Help. You may also visit
contact Sprint Customer Service (see page 14).
www.sprint.com or
Problem/error Solution
The Express Card Modem has no power.
(The LED indicator is off.)
Ensure the following:
䢇 The Express Card
Modem is properly
inserted.
䢇 The computer is
turned on and not in
suspend mode
(Windows) or sleep
mode (Mac).
No service is available.
(The LED indicator is off.)
Try the following:
䡲 Reorient your
䡲 If you are inside a
䡲 Check with Sprint
Using Your Modem
computer.
building or near a
structure that may
be blocking the
signal, change the
position or
location of your
computer.
— a network or
account problem
may be preventing
the Express Card
Modem from
obtaining service.
Section 2B. Using Your Express Card Modem 15
16 Section 2B. Using Your Express Card Modem
Section 3
Technical Specifications,
Regulatory and Safety Information
Section 3A
Technical Specifications
⽧ LED Overview (page 19)
⽧ Environmental Specifications (page 20)
⽧ Mechanical Specifications (page 21)
⽧ Software Specifications (page 21)
⽧ Transmitter Specifications (page 22)
⽧ Receiver Specifications (page 23)
⽧ Hardware Specifications (page 24)
⽧ Miscellaneous (page 24)
This section describes the LED indicators and various specifications of
your Sprint Mobile Broadband Express Card Modem.
18 Section 3A. Technical Specifications
LED Overview
Your device, has an LED light located near the antenna of the device.
The light operates as follows:
LED Status Indicates
Off (no light) The device has no power. The device may
Red No Service.
Amber Error; Reset Modem.
Green (solid) The device is powered but is not
Green (blinking
slowly)
Green
(intermittent
blinking)
not be completely inserted into the
computer.
transmitting or receiving data.
The device is powered and is searching for
the network.
The device is powered, connected, and is
sending or
receiving data.
Specifications
Section 3A. Technical Specifications 19
Environmental Specifications
Operating temperature 0° C to +55° C
(32°F to 131° F)
Storage temperature -20° C to +65° C
(-4° F to 149° F)
Humidity 5% to 90% over operating
Vibration Stability 5 Hz to 500 Hz, 0.1 octave/second
Drop 1 meter drop, no damage – fully
temperature
operational
20 Section 3A. Technical Specifications
Mechanical Specifications
Dimensions (W x D x H) 34 mm x 5 mm x 112 mm
Weight 43 g (1.4 oz.)
Battery Pack N/A
LED Yes
Antenna External Flip-Up and Intern
Software Specifications
CDMA specification EVDO Rev A
Data service Support
SMS (IS-637) Currently not supported
IOTA Support
OTAPA (IS-683A) Support
PRL (preferred roaming
list)
Authentication Support
NAM 1
Mobile IP Support
Support
Specifications
Section 3A. Technical Specifications 21
Transmitter Specifications
Type of multiplexing EVDO and 1xRTT
Normal output power 7-10 dBm
TX Max power 23 dBm
Frequency range 1850 MHz to 1919 MHz
Frequency stability Compliant with CDG1
Bandwidth 1.25 MHz
Occupied bandwidth 1.25 MHz
Modulation method O-QPSK/HPSK
Waveform quality .944
Conducted spurious emission Complies with Title 47, Part 24
Common RF impedance 50 ohms
22 Section 3A. Technical Specifications
of the FCC Rules
Receiver Specifications
Type of receiving EVDO and 1xRTT
Frequency range 1930 MHZ to 1990 MHz
Bandwidth 1.25 MHz
Occupied bandwidth 1.25 MHz
Modulation method O-QPSK/HPSK
Receiver sensitivity -104 dBm
Inter-modulation spurious
response attenuation
Common RF impedance 50 ohms
Complies with CDG stage 1
Specifications
Section 3A. Technical Specifications 23
Hardware Specifications
Interface type USB; Express Card 34/54/card
Common air interface 1xEVDO Rev A
Channel spacing 50 kHz
Chipset
Transmitting (max. data rate) Forward link: 3.1 Mbps
Supply voltage 500 mA
Battery N/A
Charger (charging time) N/A
Current consumption
Sleep/idle
Average in-use
Max. (peak)
Communication ports USB
Voice capabilit No support
GPS capability Support
bay (requires card caddy
accessory)
QUALCOMMTM MSM6800
Reverse link: 1.8 Mbps
60 mA
400 mA
700 mA
Miscellaneous
Certification & Approval FCC (parts 2, 22, & 24, SAR),
24 Section 3A. Technical Specifications
UL, CDG, etc.
Section 3B
Regulatory Information
⽧ Regulatory Notices (page 25)
⽧ Trademarks (page 27)
⽧ Copyright (page 27)
⽧ Additional Information and Updates (page 28)
⽧ Additional Information and Updates (page 28)
This section contains important regulatory notices about your Sprint
Mobile Broadband USB modem, and also patent and other information.
Regulatory Notices
This device is compliant with Parts 2, 22, and 24 of the FCC Rules.
Operation of this device is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesirable operations.
In order to comply with FCC RF Exposure requirements, this device
must be installed so that a minimum separation distance of 8.5mm
(0.33”) is maintained between the antenna and all persons during
ordinary operating conditions contingent upon the following:
1. The laptop or PC is placed on a desktop, table or flat surface
2. The device is placed on a flat surface
In accordance with FCC rules and regulations, the combination of the
MX720/V740 ExpressCard Transmitter with the XUA-1 ExpressCard
Adapter results in a FCC Class B computer peripheral approved under
Declaration of Conformity: tested to comply with FCC Standards.
FCC ID: PKRNVWMX720
CAUTI ON: Unauthorized modifications or changes not expressly
approved by Sprint Communications Company L.P. could void
Regulatory Information
Section 3B. Regulatory Information 25
compliance with regulatory rules and thereby your authority to use this
equipment.
WARNING (EMI) – United States FCC Information
This equipment has been tested and found to comply with the limits
pursuant to Parts 2, 22, and 24 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
an appropriate installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
䢇 Reorient or relocate the notebook PC.
䢇 Increase the separation between the equipment and receiver.
䢇 Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
䢇 Consult the dealer or an experienced radio/TV technician for help.
WARNING (EMI) – Canada
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the interference causing
equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques
applicables aux appareils numériques de Classe B prescrites dans la
norme sur le matériel brouilleur: “Appareils Numériques,” NMB-003
édictée par le ministre des Communications.
If you have purchased this product under a United States Government
contract, it shall be subject to restrictions as set forth in subparagraph
(c)(1)(ii) of Defense Federal Acquisitions Regulations (DFARs) Section
252.227-7013 for Department of Defense contracts, and as set forth in
Federal Acquisitions
26 Section 3B. Regulatory Information
Regulations (FARs) Section 52.227-19 for civilian agency contracts or
any successor regulations. If further government regulations apply, it is
your responsibility to ensure compliance with such regulations.
Trademarks
SPRINT and other trademarks are trademarks of Sprint Nextel.
Novatel Wireless, Merlin, the Novatel Wireless logo, and the red wave
design are trademarks of Novatel Wireless.
Windows® is a registered trademark of Microsoft Corporation.
Mac OS is a trademark of Apple Inc., registered in the U.S. and other
countries.
QUALCOMM® is a registered trademark of QUALCOMM Incorporated.
All other trademarks are property of their respective owners.
Copyright
©2008 Sprint Nextel. All rights reserved. No reproduction in whole or in
part without prior written approval. SPRINT and other trademarks are
trademarks of Sprint Nextel.
©2008 Novatel Wireless. All rights reserved.
Limitation of Liability
The information in this manual is subject to change without notice and
does not represent a commitment on the part of Novatel Wireless.
NOVATEL WIRELESS AND ITS AFFILIATES SPECIFICALLY DISCLAIM
LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL,
INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES
INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE
OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE
OR INABILITY TO USE ANY NOVATEL WIRELESS PRODUCT, EVEN IF
NOVATEL WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE
OR FOR CLAIMS BY ANY THIRD PARTY.
Regulatory Information
Section 3B. Regulatory Information 27
Notwithstanding the foregoing, in no event shall Novatel Wireless and/or
its affiliates aggregate liability arising under or in connection with the
Novatel Wireless product, regardless of the number of events,
occurrences, or claims giving rise to liability, be in excess of the price
paid by the purchaser for the Novatel Wireless product.
Additional Information and Updates
For up-to-date product descriptions, documentation, application notes,
firmware upgrades, troubleshooting tips, and press releases, visit
www.sprint.com.
28 Section 3B. Regulatory Information
Regulatory Information
Section 3B. Regulatory Information 29
Section 3C
Important Safety Information
⽧ Important Notice (page 30)
⽧ Safety and Hazards (page 30)
Important Notice
Because of the nature of wireless communications, transmission and
reception of data can never be guaranteed. Data may be delayed,
corrupted (i.e., have errors), or be totally lost. Although significant delays
or losses of data are rare when wireless devices such as the Sprint
Mobile Broadband Express Card are used in a normal manner with a
wellconstructed network, they should not be used in situations where
failure to transmit or receive data could result in damage of any kind to
the user or any other party, including but not limited to personal injury,
death, or loss of property. SPRINT SPECTRUM L.P. accepts no
responsibility for damages of any kind resulting from delays or errors in
data transmitted or received using the Sprint Mobile Broadband Express
Card, or for failure of the Sprint Mobile Broadband Express Card to
transmit or receive such data.
Safety and Hazards
Do not operate the Sprint Mobile Broadband Express Card in areas
where blasting is in progress, where explosive atmospheres may be
present, near medical equipment, life support equipment, or any
equipment which may be susceptible to any form of radio interference. In
such areas, the Sprint Mobile Broadband Express Card MUST BE
POWERED OFF. It can transmit signals that could interfere with this
equipment.
Do not operate the Sprint Mobile Broadband Express Card in any aircraft,
whether the aircraft is on the ground or in flight. In aircraft, the Sprint
Mobile Broadband Express Card MUST BE POWERED OFF. When
operating, it can transmit signals that could interfere with various onboard
systems.
30 Section 3C. Important Safety Information
The driver or operator of any vehicle should not operate the Sprint
Mobile Broadband Express Card while in control of a vehicle. Doing so
will detract from the driver or operator's control and operation of that
vehicle. In some jurisdictions, operating such communications devices
while in control of a vehicle is an offense.
Important Safety Information
Section 3C. Important Safety Information 31
Section 3D
Novatel Wireless Limited Warranty and Liability
Novatel Wireless warrants for the 12 month period immediately following
receipt of the Product by Purchaser that the Product will be free from
defects in material and workmanship under normal use. THESE
WARRANTIES ARE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ALL IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
The exclusive remedy for a claim under this warranty shall be limited to
the repair or replacement, at Novatel Wireless’ option, of defective or nonconforming materials, parts or components. The foregoing warranties do
not extend to (I) non conformities, defects or errors in the Products due to
accident, abuse, misuse or negligent use of the Products or use in other
than a normal and customary manner, environmental conditions not
conforming to Novatel Wireless’ specification, of failure to follow
prescribed installation, operating and maintenance procedures, (II)
defects, errors or nonconformity’s in the Product due to modifications,
alterations, additions or changes not made in accordance with Novatel
Wireless’ specifications or authorized by Novatel Wireless, (III) normal
wear and tear, (IV) damage caused by force of nature or act of any third
person, (V) shipping damage, (VI) service or repair of Product by the
purchaser without prior written consent from Novatel Wireless’ (VII)
products designated by Novatel Wireless as beta site test samples,
experimental, developmental, reproduction, sample, incomplete or out of
specification Products, or (VIII) returned products if the original
identification marks have been removed or altered.
32 Section 3D. Novatel Wireless Limited Warranty and Liability
Notes
Limited Warranty and Liability
Section 3D. Novatel Wireless Limited Warranty and Liability 33
Notes
34 Section 3D. Novatel Wireless Limited Warranty and Liability
Loading...
