Splawn Nitro Owner`s Manual

Page 1

OWNERS MANUAL

Page 2

Thank you for purchasing your new Splawn amplifier. We have put together a little information that will help you understand the amp and all of its functions. All of our amps are built in our shop in Dallas NC right here in the USA. We build all of our speaker cabs and head boxes in house. Some parts of the amplifier are out sourced such as the chassis's, circuit boards and transformers. The transformers are custom wound by Heyboer and are also made in the USA. We hope that this amplifier will give you years of tonal pleasure.

_______________________________________OVERDRIVE CHANNEL_______________________________

POWERONSTANDBYONRESONANCE

1. Power Switch

2. Standby Switch

3. Resonance Control

4. Presence Control

5. Bass Control

6. Middle Control

7. Treble Control

8. Solo Volume

-Switches main AC power on or off

-Switches the high voltage on or off

-High frequency control on the output section

-Controls the bass frequency on the overdrive channel

-Controls the middle frequency on the overdrive channel

-Controls the treble frequency on the overdrive channel

-Switchable volume control on the overdrive channel activated by the footswitch

PRESENCE

BASS

MIDDLE

TREBLE

SOLO

ITRO

Nitro Front Panel Controls

-Low frequency control on the output section

VOLUME

Splawn

GAIN

_____________CLEAN CHANNEL_______________

BASS

TREBLE

VOLUME

GAIN

9. Master Volume

10. Gain Control

11. Clean Bass Control

12. Clean Treble Control

13. Clean Volume Control

14. Clean Gain Control

-Controls the overall volume of the overdrive channel

-Controls the amout of pre-amp gain to the overdrive channel

-Controls the bass frequency on the clean channel

-Controls the treble frequency on the clean channel

-Controls the amount of pre-amp gain to the clean channel

-Controls the overall volume of the clean channel

Splawn Amplification

115 South Gaston St.

Dallas, NC 28034

704-922-0020

www.splawnguitars.com

Page 3

ITRO

A B

Splawn

OUT/+4 db

IN/-10 db

EFFECTS LOOP

OUT/BYPASS

IN/ACTIVE

HALF POWER

SPEAKERS

SELECTOR

MAINS INPUT

100v-120v 220v-240v

MAINS FUSE

4A 120V

HT FUSE

1A Slow-Blow

FOOTSWITCH

1. Footswitch A

2. Footswitch B

LEVEL

-TRS 1/4" Jack Tip switches Solo Volume-- Ring switches OD1/OD2

-TRS 1/4" Jack Tip switches Clean/Overdrive

3.Series Effects Loop Level Switch

4. Series Effects Loop Bypass Switch

5. Series Effects Loop Return Jack

6. Series Effects Loop Send Jack

7. Half Power Switch

-Disconnects the outside power tubes always set the amps impedence to half of the speaker cabs impedence when using half power

8. Speaker Outputs

9. Impedence Selector

10. Main Voltage Selector

11. Main Fuse

-Connection to the speaker cabinet (never run a tube amp without a speaker)

-4/8/16 ohm selector to match the load of the speaker cabinet

-100/120/220/240 voltage selector to match the input voltage

-Use 4 amp 250 volt fuse for 100 or 120 volt setting Use 2 amp 250 volt fuse for 220/240 volt setting

BYPASS

RETURN

SEND

FULL POWER

100 WATT RMS

Nitro Rear Panel Controls

-+4db -10db switch for matching line levels to effects units

-True bypass switch

-Connection from the output of the effects device

-Connection to the input of the effects device

OUTPUT

VOLTAGE

2A 220/240V

12. High Tension Fuse

1. Pre-amp tube

2. Pre-amp tube

3. Pre-amp tube

4. Pre-amp tube

5. Power Tube

6. Power Tube

7. Power Tube

8. Power Tube

- 12AX7 2nd gain stage of the clean channel

-12AX7 Side A 1st gain stage for clean & OD channels -- Side B 2nd gain stage of OD channel

-12AX7 Side A 3rd gain stage of OD channel -- Side B 4th gain stage of OD channel

-12AX7 Phase Inverter

- EL34/KT77 -- KT88/6550

-Use 1 amp 250 volt Slow Blow Fuse

1 2 3 4

Tube Layout

5 6 7 8

Page 4

Clean/Overdrive

Overdrive 1/ Overdrive 2

Nitro Footswitch Operation

Solo Boost

1. Clean/Overdrive Switch

2. Overdrive 1 / Overdrive 2 Switch

3. Solo Boost Switch

Footswitch connections -- Two 1/4" TRS plugs on a 25' cable

After unpacking your new amp, Turn the amp around so the back faces you. Remove the four screws to

remove the back cover of the amp. You will find the tubes packaged tightly on the left side of the Amp.

Carefully remove the package and remove the tubes. You will have three preamp tubes and four power

Un-box the Power section tubes. Keep the boxes!! They are marked with tube ratings! You will see on the

base of the tube there is a “key” guide to align the tube into the socket. Starting with the tube socket on the

the tube into the socket until the base of the tube is flush with the Socket. Insert these tubes into the tube

sockets. The tubes are matched so you may install them in no particular order. After you install a tube carefully hold the tube spring retainer and stretch it over the top of the tube and center it. These are light metal and can bend. If you happen to bend them you can shape it to the tube while its installed. Reinstall

Please Check the Voltage selector on the back for proper Voltage selection! Please check the volume

control levels on all channels before powering on. After you plug in the amplifier, Flip the power switch

down to turn on. Wait for a minute for the tubes to warm, then turn on the Standby switch. The Amp is ready

- LED on indicates OD Channel -- LED off indicates Clean Channel

- LED on indicates OD2 gain boost -- LED off indicates OD1

- LED on indicates Solo Volume control activated

Setting up the Amplifier:

section tubes.

Power Section Tubes:

far right, Line up the key with the slot in the socket, From the top of the tube, firmly press

the rear cover and get ready to fire this monster amplifier to life!

WARNING:

for explosive guitar sounds!

This Amplifier will get VERY loud. Remember you only have one set of ears!

Dimensions

29” Wide, 11.5” Tall, 8.5” Deep, 50lbs

Limited Lifetime Warranty.

New Amplifiers are lifetime warranted to the original purchaser

against failure of materials and workmanship. No other warranty applies. Tubes, transformers and speakers are

warranted for a period of ninety days. This warranty applies only if the amplifier has not been damaged by

accident, misuse or as a result of repair or modification. Splawn reserves the right to make any design changes

without notice or obligation to incorporate these changes in products previously purchased. All warranty repairs are to be done by Splawn Amplification.

Splawn Amplification 115 South Gaston St.

Dallas, NC 28034
