Spirent DLS6626 Data Sheet

Spirent Physical Layer Solutions

DLS 6626 Production-Grade
Single Line Simulator

ADSL2++/ ADSL2+/ ADSL2/ ADSL and G.SHDSL

Product Overview

The DLS 6626 is a single-line wireline production
simulator in a 1U rack-mountable chassis. It provides
for wide bandwidth with reaches up to 23.5 kft,
suitable for ADSL2++/ADSL2+/ADSL2/ADSL production
and verification testing.

he DLS 6626 production-grade simulator is designed

T
to complement the DLS 410 series of ADSLx lab-grade
wireline simulators used for highly accurate design,
conformance and performance testing. The DLS 6626
provides a lower cost/lower performance alternative for
manufacturing testing and simulates all wireline
parameters using passive components.

Spirent Communications’ DLS products are the
worldwide standard for physical layer equipment used
in conformance, performance and interoperability
testing

With extensive market and technology expertise
leveraged from Spirent’s active participation at all
major standards meetings including ETSI, ANSI, ITU-T,
IEEE 802.3, and DSL Forum, Spirent DLS equipment
provides the industry’s most accurate and repeatable
results – ensuring your equipment is designed for peak
performance.

Features and Benefits

n

Low cost, easy swap: Form-fit-function upgrade
replacement for the DLS 6100. Spirent can upgrade
an existing DLS 6100 into a DLS 6626 for less than
the cost of a new DLS 6626, and even reuse existing
DLS 6100 scripts. This minimizes disruption to
testing and maximizes cost savings. Alternatively, a
technician can simply unplug the DLS 6100 and plug

n a DLS 6626

i

n

4.5 MHz bandwidth: Bandwidth for SHDSL/
ADSL/ADSL2/ADSL2+/ADSL2++ standards testing

n

Loop step size: Variable from 0 to 23.5 kft in 250 ft
increments

n

Simple to operate: Suitable for fast-paced
manufacturing and verification testing

n

Manual and remote control options: Can easily be
integrated into an automated test environment,
allowing for control of the system in a customer’s own
scripting environment. Front panel manual controls
and remote control options of RS-232 and IEEE-488
allow testing to be automated or quickly adjusted

n

Premium accuracy for production: Uses technology
from the DLS 410 ADSLx series of lab-grade
simulators – ensuring the highest degree of accuracy
possible for production-grade simulation

n

Passive simulation components: Lowest noise
floor in production wireline simulation enables
greater accuracy

Spirent

Communications

26750 Agoura Road

Calabasas, CA

91302 USA

E-mail: productinfo

@spirentcom.com

Sales Contacts:

North America

[phone]

Europe,

Middle East, Africa

[phone]

Asia Pacific

[phone]

All Other Regions

[phone]

www.spirentcom.com

Spirent Remote

Control Software

(RS-232 or

IEEE

DSLAM

488

)

OC-3/STM-1

OC-12/STM-4

DS-3

ADSL2+

Gener

affic

r

T

SmartBits 200/2000 System

ation and Analysis

DLS 6626

ireline Simulator

W

SL2+

AD

Ethernet

CPE

2 DLS 6626

DLS 6626 System Specifications

Type of Wire 26 AWG (from ITU-T G.996.1)

Variable Range 0-23.5 kft

Increments 250 ft

andwidth

B

C to 4.5 Mhz

D

DC Rating 100 mA, 200 V maximum DC

ttenuation (Insertion Loss) MAE < 1dB (20kHz - 4.5 MHz)

A

mpedance

I

10% (20kHz - 4.5 MHz)

±

Control Manual/ Remote (remote via IEEE 488 or RS-232)

Connections Manual: 2 (one per side) 8-pin RJ-45 connectors, located on the front panel.

Remote front: 2 (one per side) 8-pin RJ-45 connectors

emote back: 2 (one per side) two-pole terminal strips (one per side)

R
CF connectors (banana plugs)

Power Supply AC Power 100 -130 VAC, 60 Hz or 230-240 VAC (+6/-10%) 50/60 Hz AC to DC

adapter (required for remote unit only)

Environmental

Operating Temperature +10° C to +40° C (50° F to 104° F)

Storage Temperature -20°C to +70°C (-4°F to 158°F)

Cable Reference Temperature 22°C

Humidity 90% (non-condensing) max.

Mechanical

(Unit comes complete with rack mount brackets.)

Weight per chassis 4.5 kg/10 lbs per chassis

Spirent

Communications

26750 Agoura Road

Calabasas, CA

91302 USA

E-mail: productinfo

@spirentcom.com

Sales Contacts:

North America

[phone]

Europe,

Middle East, Africa

[phone]

Asia Pacific

[phone]

All Other Regions

[phone]

www.spirentcom.com

Dimensions per chassis 44 mm x 423 mm x 384 mm

(1.75” x 17” x 15”) (H x W x D) (2U height)

Wireline Simulator Evolution Paths for ADSL
> ADSL2++ Production Testing

Spirent understands the importance of providing its
customers with an evolution path that protects

tments in t

s

e

v

in
migration path from existing tools and technologies to
new technologies.

For customers with existing DLS 6100M or DLS 6100R

e

sed t

a

b
programs to a DLS 6626 are available to meet a variety
of requirements. Please contact your Spirent
representative for further information.

Evolution paths from 6100M/6100R to DLS 6626

de DLS

a

gr

p

U
Upgrade DLS 6100R to DLS 6626 (P/N 6UR6)

est equipment by providing a smooth

sting platforms, cost-effective upgrade

6100M to DLS 6626 (P/N 6UM6)

Spirent Global Services

Spirent Global Services provides a variety of
professional services, support services and education
services — all focused on helping customers meet their
complex testing and service assurance requirements.
For more information, visit the Global Services website

com.com/gs or contact your Spirent

ent

.spir

at www
sales representative.

© 2006 Spirent plc. All rights reserved. “Spirent” and “Analyze, Assure, Accelerate” are exclusive trademarks of Spirent plc and itssubsidiaries.

right

y

op

C
All other names are trademarks or registered trademarks of their respective ownersand are hereby acknowledged. Specifications subject to change without notice.

P/N 79-000442 R

ev

A 0106

.
