APPROVAL SHEET
Article No. : SP-AP-SC-A419
Issue Date : Nov 6 , 2012
Version : A/0
Http://www.spirecoolers.com
Http://www.spirepower.com
Http://www.spire-corp.com
CPU Coolers
SALES MODEL NO: SP805S3-PWM
ENGINEER NO: SC805S3-PWM
Audited by
Checked by Drafted by
Tel.: +86-755-26801568 Fax: +86-755-26801561
Version:A/0 Page 1 of 12
Spire Corp.
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
Approval Sheet Revisement Record
SALES MODEL NO: SP805S3-PWM
ENGINEER NO: SC805S3-PWM
Article No: SP-AP-SC-A419
Version
Revised
Description
Chapter
A/0 N/A First Version 2012-11-6 N/A
Revised
Date
Drafte
d by
Audited
by
ECN
No.
Version:A/0 Page 2 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
Contents
1. Main Components List……………………………………..….……….………4
2. Multi views and images……………………………………..….………………………5
2.1 Coolers images…………………………………………………………………5
2.2 Components images……………………………………………………………6
3. Featuresand Specifications ……………………….....…………………….…………7
4. Product Drawing………………………....….……………….…………………8
4.1 Assembly Drawing……………………...……………………...………………….8
4.2 Cooler Drawing………………… …….…………………………………………..9
5. Fan Specification…………………………………………………. ……………… 10
6. P&Q Characteristic curves…………..……………………………………………. 11
7. CorrelativeCertification compliance…..…………………………………………. 12
Version:A/0 Page 3 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
1. Main Components List
Item Components Part No. Quantity Material
1 Heat sink 01AL805AW1 1 AL
2 Clip 03CM048 1 Metal
3 Screw 03SW023 4 Metal
4 Fan SF09025SRM4W2-PWM 1 Plastic
Version:A/0 Page 4 of12
Version:A/0 Page 5 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
2. Multi views and images
2.1 Cooler images
Picture 1 : Full view Picture 2 : Top view
Picture 3 : Base view Picture 4 : Side view
Version:A/0 Page 6 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
2.2 Components images
Picture 1 : Heatsink Picture 2: Screw
Picture 3: Fan Picture 4: Clip
Picture 5: Fan Label Picture 6: 4 PIN PWM (2510)
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
3. Features and Specifications:
Main features:
Supports all new AM2/AM3/AM3+/FM1/FM2 micro-processors
Ø95x25mm sleeve fan for silent operation
High-density extruded heat-sink with large base for optimal heat conductivity
Specifications：
Heat sink : 77X85X34 mm
Dimensions
12VDC Fan : Ø 95x25mm
Material
Bearing Sleeve Bearing
Rated speed
Rated power 1.92 W
Noise level 10.0~26.0 dBA
Air flow 45.26CFM Max.
Current 0.16A
Life hours Sleeve: 30,000
Connector 4 PIN PWM(2510)
Application AMD: AM2/AM3/AM3+/FM1/FM2
AL
Cooler 600~2200 RPM +/-10%
Single fan 600~2200 RPM +/-10%
TDP 95W
Thermal
resistance
Thermal type Stars-TIG780-50 grease
weight 238g(Cooler only)
Version:A/0 Page 7 of12
0.347°C/W
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
4. Product Drawing
1
2
3
4
5
6
432
1
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
5
6
432
1
DATE
DESCRIPTION
REV
Drawn
Checked
Approved
Part No.
Unit
10
TOLERANCE
TO
Finish
100
over
250
30
Scale
Version
Material
1/1
Angles
Page
UNSPECIFIED TOLLERENCE
10
100
250
30
OVER
0
±0.5 °
±0.50
±0.40
±0.30
±0.20
±0.10
Spire Corp.
APVD
CHK. BY
DRN. BY
Date
Date
Date
THIRD ANGLE PROJECTION
File Name
DSN. BY Date
mm
A/0
Inspection Items
Article No.
BOM No.
Spec No.
Item Component Part No. Quantity
1
2
3
4
Screw
Fan
Clip
Heatsink
4
1
1
1
03SW023
SF09025SRH4W2-PWM
03CM048
01AL805AW1
SP805 Components images
N/A
1:1
N/A
SP805S3-PWM
4.1 Assembly Drawing
Version:A/0 Page 8 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
4.2 Cooler
5
6
432
1
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
5
6
432
1
DATE
DESCRIPTION
REV
Drawn
Checked
Approved
Part No.
Unit
10
TOLERANCE
TO
Finish
100
over
250
30
Scale
Version
Material
1/1
Angles
Page
UNSPECIFIED TOLLERENCE
10
100
250
30
OVER
0
±0.5 °
±0.50
±0.40
±0.30
±0.20
±0.10
Spire Corp.
APVD
CHK. BY
DRN. BY
Date
Date
Date
THIRD ANGLE PROJECTION
File Name
DSN. BY Date
mm
A/0
Inspection Items
Article No.
BOM No.
Spec No.
SP805S3-PWM
SP805 COOLER
N/A
1:1
N/A
CKM
1
2 3 4
2510-4P
220±10MM
ITEM
2510-4P PH=2.54
1
2
3
UL 1007 #26 BLACK
UL 1007 #26 RED
UL 1007 #26 YELLOW
4
UL 1007 #26 GREEN
Version:A/0 Page 9 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
5. Fan Specification:
FAN MODEL: SF09025SRM4W2-PWM
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed（only fan） : 600~2200RPM ±10%
4) Static Pressure : 2.11 mm-H2O
5) Air Flow : 45.26 CFM Max.
6) Rated Current : 0.16 A
7) Rated Power : 1.92WATTS
8) MAX Noise Level : 10.0~26.0 dB(A)
9) Operating Temperature : -10 to 700C
10) Storage Temperature : -40 to 700C
11) Bearing System : Sleeve Bearing
12) Connector : 4 PIN PWM(2510)
13) Weight : 64.0g
Version:A/0 Page 10 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
6. P&Q Characteristic curves
0
0.9
1.8
2.7
3.6
0
0.035
0.071
0.106
0.142
0 15 30 45 60
0
0.425
0.85 1.275 1.70
CFM
CMM
inch-H2O
mm-H2O
Version:A/0 Page 11 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
7. Correlative Certification compliance
Item # Certification type Certification Number Certification listing Remark
1 EMC BCT07LC-807E www.bontek.com.cn
2 LVD BCT07LC-807S www.bontek.com.cn
3 FCC ASZ08041007FK www.aovt.com
4 ROHS GZ0803038947A/CHEM www.rohs.cn.com
5 TUV R50131773 www.sz.chn.tuv.com
Version:A/0 Page 12 of12
