Spinal Guides Labs
SGL SmartRay System, V4.0 User Manual
9/11/2013
Thank you for acquiring the SGL SmartRay System, V4.0
Please read through this User Guide carefully to ensure safe usage
If you have any technical issues contact Spinal Guides Labs Technical Support Center via
Contents
1. Introduction ........................................................................................................................................... 2
Indication for Use ..................................................................................................................................... 2
2. Precautions for Safe Use: ...................................................................................................................... 3
3. Manufacturer’s Declaration .................................................................................................................. 3
4. FCC Statement ..................................................................................................................................... 3
Page 1 of 4
Page 2
Spinal Guides Labs
SGL SmartRay System, V4.0 User Manual
9/11/2013
1. Introduction
IndicationforUse
SGL SmartRay System, V4.0 is an accessory to a stationary X-ray system and is indicated for acquiring
X-ray images for measurements in the orthopedic field (spinal segments, skeleton) with control of optical
distortions.
Caution:
Federal Law restricts this device to sale by or on the order of a physician or a practitioner trained in its
use.
Warning:
a. Calibrate before use SmartRay System according to the manufacturer’s specification,
otherwise the measured values of length and angles will not be correctly red by the System
b. Do not spray, pour or spill any liquid on the sensors or components of the System
c. Do not use any organic solvent or chlorine bleach on the System
d. Do not work the System between -10 C and +60 C
e. Do not operate in the environment between -20 C and + 70 C
f. Do not drop or give strong impact to the sensors of the System
g. Do not dismantle of modify the product
h. Do no use any sterilizer such as an Autoclave
i. To disinfect a ny part of the System, wipe with a soft cloth damped with ethyl alcohol
j. Avoid transport of the System, or sensors, whichever case may be without designated for that
purpose special packaging
k. Avoid damaging the BSS-1 cable
Page 2 of 4
Page 3
Spinal Guides Labs
SGL SmartRay System, V4.0 User Manual
9/11/2013
2. PrecautionsforSafeUse:
a. Do not run any other software program on the computers of the System
b. Use third party computer hardware with the System according to the SGL Radiology System
requirements listed in each individual module under “Hardware Requirements”
3. Manufacturer’sDeclaration
Applicable Standard
1. FSS Standard
Title 47: Telecommunication
Part 15- RADIO FREQUNCY DEVICES
Subpart C- Intentional Radiators
Paragraph 15.247 Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz
2. The manufacturer includes with purchase scheduled training sessions. Please call 718-880-2086
to schedule a session with one of our trainers.
4. FCCStatement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Page 3 of 4
Page 4
Spinal Guides Labs
SGL SmartRay System, V4.0 User Manual
9/11/2013
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the e quipment.
NOTE: This equipment has been tested an d found to comply with the limits for a Class B
digital device, pursuant to Part 15 of th e FCC R u le s. The se limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses a n d ca n radiate radio frequency ener g y an d, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to rad io or television recepti on,
which can be determine d b y t u rning the equipment off and on, the us er is encouraged to try to
correct the interference by one or more of the following m easures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and rece iver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet ge neral RF exposure requirement. The device can be used
in portable exposure condition without restriction.
Page 4 of 4
