Spicer
®
Drive Axle
AB
Information Bulletin
Bulletin Type: Service/Technical Information
Topic: Heavy Axle End Fitting Part Number Interchanges
Affected Models: All Drive Axle Yokes & Flanges
To better serve or customers and the market place, Dana Corporation’s Heavy Vehicle
Technologies and Systems Service (HVTSS) division is pleased to announce the following
changes to select axle end fitting part numbers and the process for ordering these numbers.
Effective immediately, we have changed the part numbers of select axle end fittings to better
align with the numbering scheme with all other Spicer® end fittings. Attached is a cross
reference chart from the old part numbers, formally used by our Henderson, Kentucky axle
facility, to the new numbers. The “Henderson type” part numbers will no longer be recognized
by our system. Please make these part number changes in your system and begin ordering
using the new numbers immediately.
Certain Henderson numbers were identified as obsolete and have been superceded to a “half
round” configuration end fitting. To incorporate this new configuration it is necessary to replace
the universal joint kit on the mating end of the driveshaft and will also require the appropriate
strap and bolt kit identified in the last column of the cross reference chart. This change will
allow the driveshaft to properly mate with the new end fitting.
Additionally, oil seals were often include with end fitting that were shipped from the Henderson
facility, but will no longer be included. Oil seals are now required to be ordered separately
using their respective original OEM part numbers.
Finally, these part numbers must be ordered through our Holland, OH Customer Service
department. The Henderson, Kentucky Customer Service department has been consolidated
into the Holland, Ohio group.
Information regarding these changes was also communicated via Service Bulletin JOI-PNI-198.
IB-0607
Original Dana
Henderson Part-No.
030383 6-4-4171X
039521 5-4-5121X
042200 3-4-5791-1X
047999 4-4-3581-1X
048976 4-4-4071-1X
050567 5-4-5111X
073589 5-4-4761X
073590 5-4-4761X
073592 6-4-4851X
073593 6-4-4861X
073594 6-4-4861X
082468 6-4-4751X
083800 6-4-4591
083801 6-4-5481X
084886 6.5-4-2361X
087512 6.5-4-2401X
087513 6.5-4-2401X
088912 6-4-5151X
099715 5-4-5161X
109639 6.3-4-241X
119334 3-4-5791-1X
119336 4-4-1901-2
119649 5-4-8711X
119739 5-4-6591-1X
119951 3-4-6221-1X
119953 3-4-5791-1X
126253 6.5-4-2361-1X
126310 6-4-7651X
126425 3-4-10461-1X
126427 3-4-10471-1X
126429 4-4-5611-1X
126469 5-4-7301X
126531 5-4-7301-1X
126532 3-4-10261-1
126533 3-4-10471-1X
126535 6-4-7581-1X
126555 4-4-5691-1X
126561 5-4-8131-1X
126581 6-4-7531X
126583 6.3-4-1161X
126585 6.5-4-3921X
126651 6-4-9191X
126652 6.3-4-1641X
126653 6.5-4-4621X
126686 6-4-7531-1X
Now Sold as
Driveshaft Part-No.
Original Dana
Henderson Part-No.
126688 6.3-4-1161-1X
126690 6.5-4-3921-1X
126716 6-4-4171-1X
126868 3-4-11921-1X
126872 3-4-11921-1X
127001 6.3-4-1331-1X
127003 6-4-7971-1X
127187 127187
127414 232511
127415 6-4-9031X
127557 232514
127558 6-4-9041X
127617 6-4-8981-1X
127618 6.3-4-5221X
127619 6.5-4-4571X
127620 5-4-9261-1X
127621 6.5-4-4571-1X
127622 6.3-4-5221-1X
127624 6-4-9001X
127637 6-4-8991X
127638 5-4-9271X
127698 127698
127702 6-4-7651-1X
127738 5-4-8441X
127739 6-4-8511X
127740 6-4-8521X
127742 6-4-8541X
127743 5-4-8421X
127744 6-4-8531X
127745 5-4-8411X
127747 4-4-7551-1X
127748 4-4-7551-1X
127749 6.5-4-4351-1X
127750 5-4-8431-1X
127751 6.3-4-1481-1X
127752 6-4-8551-1X
127753 6.5-4-4351X
127754 6-4-8551X
127755 6.3-4-1481X
128056 128056
128410 6-4-8511-1X
128412 6-4-8531-1X
128444 5-4-8901-1X
128506 6-4-8541-1X
128508 6-4-8521-1X
Now Sold as
Driveshaft Part-No.
Original Dana
Henderson Part-No.
128720 5-4-9241X
128722 6-4-9001-1X
128737 6-4-9041-1X
128745 6-4-9031-1X
128746 6-4-8991-1X
128765 5-4-8411-1X
128788 128788
128873 6.3-4-1651-1X
128874 6-4-9201-1X
128875 6.5-4-4611X
128876 6.3-4-1651X
128878 6.5-4-4621X
128881 6-4-9191X
128883 5-4-9121X
128884 6-4-9171X
128885 6-4-9181X
128887 6.5-4-4601X
128889 5-4-9111-1X
128890 6-4-9171-1X
128891 6.3-4-1631-1X
128892 6.5-4-4601-1X
128937 5-4-9121-1X
128938 6-4-9181-1X
128986 6-4-9191-1X
129019 5-4-9241-1X
129043 5-4-9231-1X
129162 3-4-13061-1X
129164 3-4-13081-1X
129166 4-4-7571-1X
130805 130805
131896 5001766
131897 5001768
210727 6.3-4-1621-1X
210728 6-4-9161-1X
210729 6.5-4-4591-1X
210730 5-4-9101-1X
210732 6-4-9161X
210733 6.3-4-1621X
210739 6.5-4-4611-1X
210782 210782
210783 210783
210785 5-4-9451-1X
210787 5-4-9441-1X
210817 5-4-9131-1X
210821 250-4-51-1
Now Sold as
Driveshaft Part-No.
Original Dana
Henderson Part-No.
210823 170-4-121-1X
210825 170-4-141-1X
210827 170-4-161-1X
210829 170-4-181-1X
210831 170-4-201-1X
210833 250-4-81-1X
210835 170-4-221-1X
210837 170-4-241-1X
210839 170-4-261-1X
210841 170-4-281-1X
210843 170-4-301-1X
210845 250-4-101-1X
210847 170-4-341-1X
210851 170-4-321-1X
210853 170-4-361-1X
210855 170-4-381-1X
210859 170-4-31-1X
210861 250-4-41-1X
210865 170-4-101-1X
210905 5-4-9131-1X
210923 90-4-251-1X
210937 100-4-1381-1X
210941 6-1-6051X
210947 90-4-691-1X
210950 100-4-1371-1X
210952 140-4-1401-1X
210967 210967
213168 6.5-4-4351X
213169 6-4-8551X
213170 6.3-4-1481X
213171 6.5-4-4351-1X
213172 5-4-8431-1X
213173 6.3-4-1481-1X
213174 6-4-8551-1X
213175 5-4-8441X
213176 6-4-8511X
213177 6-4-8521X
213179 6-4-8541X
213180 5-4-8421X
213181 6-4-8531X
213182 5-4-8411X
213183 5-4-8131-1X
213184 4-4-7551-1X
213185 4-4-7551-1X
216472 6-4-9201-1X
Now Sold as
Driveshaft Part-No.
3
Original Dana
Henderson Part-No.
Now Sold as
Driveshaft Part-No.
216473 6.3-4-1651X
216474 6.3-4-1651-1X
216475 6.5-4-4611-1X
216476 6.5-4-4611X
216480 6-4-9191X
216482 6.5-4-4621X
5001783 5006977
5006976 3-4-14781-1
5006977 5006977
131433K 131433K
131434K 131434K
131435K 131435K
131436K 131436K
131437K 131437K
131438K 131438K
131439K 131439K
131440K 131440K
131441K 131441K
131442K 131442K
131443K 131443K
131444K 131444K
131446K 131446K
131447K 131447K
131448K 131448K
131449K 131449K
131450K 131450K
131451K 131451K
131480K 131480K
131482K 131482K
131518K 131518K
131519K 131519K
131520K 131520K
131530K 131530K
132863K 132863K
132931K 132931K
133660K 133660K
133661K 133661K
140-4-371-1X 140-4-371-1X
140-4-931-1X 140-4-931-1X
170-4-1041-1X 170-4-1041-1X
170-4-1891-1 131433K
170-4-221-1X 170-4-221-1X
170-4-641-1 170-4-641-1
170-4-721-1X 170-4-721-1X
170-4-821-1 170-4-821-1
Original Dana
Henderson Part-No.
Now Sold as
Driveshaft Part-No.
170-4-831-1 170-4-831-1
170-4-851-1X 170-4-851-1X
170-4-901-1X 170-4-901-1X
250-4-391-1X 250-4-391-1X
3-4-12101-1X 3-4-12101-1X
3-4-13351-1X 3-4-13351-1X
3-4-13391-1X 3-4-13391-1X
3-4-14791-1X 3-4-14791-1X
3-4-14841-1X 3-4-14841-1X
4-4-6961-1X 4-4-6961-1X
4-4-6981-1X 4-4-6981-1X
4-4-7001-1X 4-4-7001-1X
4-4-7111-1X 4-4-7111-1X
5-4-8501-1X 5-4-8501-1X
5-4-8571-1X 5-4-8571-1X
5-4-8591-1X 5-4-8591-1X
5-4-8611-1X 5-4-8611-1X
5-4-8691-1X 5-4-8691-1X
55-4-41-1X 55-4-41-1X
55-4-81-1X 55-4-81-1X
6-3-4-1041X 6.3-4-1041X
6-3-4-1521-1X 6.3-4-1521-1X
6-3-4-1711-1X 6.3-4-1711-1X
6-4-8681-1X 6-4-8681-1X
6-4-8701-1X 6-4-8701-1X
6-4-8721-1X 6-4-8721-1X
6-4-8761-1X 6-4-8761-1X
6-4-8801-1X 6-4-8801-1X
6-4-9031-1X 6-4-9031-1X
6-4-9281-1 6-4-9281-1
6-4-9301-1X 6-4-9301-1X
6-4-9411-1 6-4-9411-1
6-5-4-4481-1X 6.5-4-4481-1X
6-5-4-4611-1X 6.5-4-4611-1X
6-5-4-4661-1X 6.5-4-4661-1X
6.5-4-5091-1 131443K
70-4-61-1X 70-4-61-1X
73169-X 3-4-11081-1X
90-4-551-1X 90-4-551-1X
90-4-571-1X 90-4-571-1X
90-4-591-1X 90-4-591-1X
90-4-611-1X 90-4-611-1X
4
Original
Dana
Henderson
Part-No.
Now Sold As Half
Round End Yoke
Driveshaft Part-No. Series UJ Needed
Installation
050568 5-4-5111-1X 1610 5-674X 5-70-28X
119647 6-4-9841-1X 1710 5-675X 6.5-70-18X
119911 6-4-9841X 1710 5-675X 6.5-70-18X
126298 6-4-8511-1X 1710 5-675X 6.5-70-18X
126544 6.5-4-3691X 1810 5-676X 6.5-70-18X
126650 5-4-9131-1X 1610 5-674X 5-70-28X
126689 6.5-4-3921-1X 1810 5-676X 6.5-70-18X
127550 6-4-8981-1X 1710 5-675X 6.5-70-18X
127741 5-4-8451X 1610 5-674X 5-70-28X
127746 5-4-8131-1X 1610 5-674X 5-70-28X
128534 6-4-9041-1x 1710 5-675X 6.5-70-18X
128877 6-4-9201-1X 1710 5-675X 6.5-70-18X
128879 5-4-9131-1X 1610 5-674X 5-70-28X
128882 5-4-9111-1X 1610 5-674X 5-70-28X
128886 6.3-4-1071-1X 1760 5-677X 6.5-70-18X
210742 6.3-4-1641X 1760 5-677X 6.5-70-18X
213178 6-4-8981-1X 1710 5-675X 6.5-70-18X
216471 6-4-9201-1X 1710 5-675X 6.5-70-18X
216479 5-4-9131-1X 1610 5-674X 5-70-28X
216481 6.3-4-1621X 1760 5-677X 6.5-70-18X
Kit
For spec’ing or service assistance, call 1-800-621-8084 24
Or visit our web site at: http://www.spicerparts.com
Dana Corporation
ABIB-0607 Copyright Dana Corporation, 2006 Heavy Vehicle Technologies and Systems Service
July 2006 All Rights Reserved. P.O. Box 321
Printed in U.S.A. www.dana.com Toledo, Ohio 43697-0321
hours a day, 7 days a week.
