SPHINX Myth11 Service Manual

1.

SERVICE MANUAL

MYTH 11

STEREO

POWER AMPLIFIER

POWER

STANDBY

PROTECT

SPHINX Myth 11 Service Manual

2

1. UNPACKING.......................................................................................................................................3

2. CONTACTING THE MANUFACTURER.............................................................................................3

3. THE POWER AMP AT A GLANCE....................................................................................................4

Front panel................................................................................................................................................... 4

Rear panel ...................................................................................................................................................5

4. OPERATION .......................................................................................................................................6

Power on...................................................................................................................................................... 6

Power off...................................................................................................................................................... 6

5. TECHNICAL SPECIFICATIONS.........................................................................................................7

6. ADJUSTMENT PROCEDURES..........................................................................................................8

Bias..............................................................................................................................................................8

Offset ........................................................................................................................................................... 8

7. PROBLEMS AND SOLUTIONS .........................................................................................................9

8. DIAGRAMS AND PARTS LISTS ......................................................................................................10

Measurement Set-up .................................................................................................................................11

General Overview Myth 11.........................................................................................................................12

Power Supply ............................................................................................................................................. 13

Amplifier Left..............................................................................................................................................14

Amplifier Right............................................................................................................................................15

Input / Output.............................................................................................................................................16

Control ....................................................................................................................................................... 17

Parts List....................................................................................................................................................18

SPHINX Myth 11 Service Manual

3

The Sphinx Myth 11 design

This service manual will help you to optimally
service and repair the Sphinx Myth 11 Stereo
Power Amplifier.

This high quality high end stereo power amp is of
discrete design throughout (no IC's are used).

The power amp uses specially selected Power
MOS-FETs with a power bandwidth of over 20 MHz,
a very fast slew rate and an unsurpassed phase
linearity over the power bandwidth. Each channel
uses four 120W/10 A FETs, operates as a pure
voltage source with an extremely low impedance
and is thus very stable.
The most unique feature is that it works in full
Class-A mode up to 10 W!
Thanks to the generous energy reserve of 69,600
µF, unlimited power is available for the largest
signal peaks.

To obtain the maximum quality from this power amp
it is necessary to use it with top quality audio
components, preferably with other Sphinx
components.

1. UNPACKING

Before leaving the factory every Myth 11 is
subjected to stringent and extensive technical and
exterior quality inspection.
This ensures you will enjoy many years of high
quality audio from a perfect-looking product.

Attention: The power amp weighs over 10 kg!
Never lift it out of the box without someone
helping you.

After unpacking your Myth 11 we therefore
recommend you carefully check it for any transport
damage.

Even if the component is in perfect condition you
should still keep the packing materials. If you need
to transport your Myth 11 at a later time it will be
best protected by the original packing materials.

2. CONTACTING THE MANUFACTURER

In case of any problem not covered in this manual
or if you have other questions you may contact the
Sphinx International Service Department in The
Netherlands (local time: GMT +1h) during office
hours at the following numbers:

Phone: [phone]
Fax: [phone]
E-mail: [e-mail]

It is always very helpful and efficient if you have all
relevant information about the specific product and
the problem ready.

Please also refer to the User Manual of the
Myth 11 for information about functions not
described in this manual.
It is important to familiarise yourself with the
special functions, operation and possibilities
of the Sphinx Myth 11.

SPHINX Myth 11 Service Manual

4

3. THE POWER AMP AT A GLANCE

Front panel

1. STANDBY: To switch the component on and off.

2. POWER LED: Indicates the selected function:
stand-by off
amp on red

3. STANDBY LED: Indicates the selected function:
stand-by red
amp on off

4. PROTECT LED: Normally off. When blinking red
it indicates that the protection circuit is active

POWER

STANDBY

PROTECT

1

2

3

4

SPHINX Myth 11 Service Manual

5

Rear panel

1. Warning label: This shows important safety
warnings.

2. OUTPUT R: To connect the cable from the right
loudspeaker:
red +
black -

3. CONTROL IN: To connect the optical cable from
another Sphinx component like a pre-amp.

4. INPUT: To connect the cinch cables from the
output of the signal source.

5. Manufacturer's label: This shows important
data for the component, such as serial number
and mains power voltage.

6. OUTPUT L: To connect the cable from the left
loudspeaker:
red +
black -

7. AC POWER: Connect the power amp to a
mains outlet (230 - 240 VAC) and the mains
power switch.
The mains fuse is placed behind the cover.

Warning!

!

Do not open!
High voltage inside!
Do not expose thi sunit
to rain ormoisture.

ACVoltage:

220V/60Hz .

Max. Power: 600 W

Made inTh eNetherlands
Manufactured by :

Sphinx Laboratories

Fuse:

3,15 AT

INPUT

CONTROL

IN

OUTPUT R

OUTPUT L

L

R

1234567

SPHINX Myth 11 Service Manual

6

4. OPERATION

Once you have finished connecting all components,
you can switch on the Myth 11.

Connect the mains cable to a mains outlet.

Power on

Switch the Myth 11 on with the O / I switch (7) on the
rear panel.

The STANDBY LED (3) will blink for a while after
which it will light red. The Myth 11 is now in stand-by
mode.

From now on you should switch the power amp on
and off with the STANDBY button (1) on the front
panel or the STANDBY button of another Sphinx
component connected to the optical CONTROL IN
jack.
This way all circuits will remain at working
temperature and the audio quality will be 100 %
within 15 minutes after activating. Additionally it
considerably increases the life span of the
component.

Switch the Myth 11 on with the STANDBY button:
the LED (3) will extinguish and the POWER LED (2)
will light.

If you activate the power amp for the first time or
after a long period of non-use with the power 'off',
the amp will be at maximum performance after one
hour.
From stand-by mode it takes only around 15
minutes.

Power off

You switch the Myth 11 off (stand-by) with the
STANDBY button (1).

N.B.: If you need to switch the system on again
immediately, you should wait for at least 60 sec
though.
Because switching on the amp within 30 sec will
activate the protection circuits: the red PROTECT
LED (4) will blink rapidly.

Only if you will not be using the amp for a long
period (e.g. during holidays) should you switch the
amp off with the O / I switch (7).
In stand-by mode the Myth 11's power consumption
is still around the 70 W mark.

SPHINX Myth 11 Service Manual

7

5. TECHNICAL SPECIFICATIONS

Bandwidth 0 - 300,000 Hz (+0/-0.25 dB)
Phase response error <2° (0 - 20,000 Hz)
Gain 29.5 dB max.
Minimum Power Output (1 - 20,000 Hz) >2x 94.5 W into 8 ohm (19.8 dBW), THD <0.01%

>2x 157.5 W into 4 ohm (22.0 dBW), THD <0.01%
>2x 217.6 W into 2 ohm (23.4 dBW), THD <0.01%

THD+N (IHF-A) <0.06% / 0.006% (2nd harmonic, 10 - 20,000 Hz)
IMD

<0.005% (50 W into 8 Ω)
S/N ratio (IHF-A) >85 dB / 98 dB
Channel separation >90 dB (1 – 20,000 Hz)
Slew rate >100 V/µs
Damping factor >500 (1 – 1,000 Hz)

Input Cinch: unbalanced
level, nominal 1.25V (1.9 dBV)
Impedance

20 kΩ
Supply capacitance 26,000 µF total per channel

Power consumption 550 W max. (70 W standby)
Dimensions (h x w x d) 73 x 434 x 350 mm

Weight 10 kg

This unit conforms to the EMC interference regulations issued by the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and therefore with international safety regulation IEC 65.

Technical specifications may be changed by SPHINX without prior notice if technical developments make this
necessary.

©1999 Audioscript BV

SPHINX Myth 11 Service Manual

8

6. ADJUSTMENT PROCEDURES

The Myth 11 only has three parameters for each
channel (so six in total) that might need adjustment:

- Bias: to set the bias current and bias voltage of
the amplifier for normal use.

- Offset: to set the DC-offset voltage of the
output.

These adjustments might be necessary when the
amplifier has been used for a period of time (and
settings have changed due to ageing) or when parts
of the Myth 11 have been replaced.

Attention:

When re-adjusting any setting please ensure that
there is no loudspeaker connected to the output!
Otherwise the loudspeaker may be seriously
damaged.

Attention:

The amplifier is able to generate high output
voltages of over + or -40 V.
Please be very careful during the adjustments!

Bias

With this procedure you set the proper bias level for
the power FETs. This ensures their Class A
operation at low power levels.
Connect the amplifier according to the drawing
“Measurement Set-up” (page 11).
The input of the amplifier must be shorted (by way
of the MUTE function of the oscillator).

• Switch the amplifier ON and wait until it has

reached the proper working temperature

• Set the millivolt-meter to the DC-range.

• Place the two measuring clips of the meter

across one of the source resistors
Left: R30L, R31L, R39L, R40L
Right: R30R, R31R, R39R, R40R

• The level for each should be 8 mV DC (±2 mV).

If not: adjust potmeter P2L (Left) or potmeter
P2R (Right) until the level is 8 mV.

• Repeat this procedure after 20 minutes to

finalise the adjustment.

• Switch the oscillator on and set it to 1 kHz and a

level of 0 dBV (1 V).

• Check the distortion with a THD analyser: it

should be conform to the specified value
(0.006% IHF-A @ 1 – 20 kHz @ 50 W into 8
ohm).

If this is correct the procedure is finished.
You may now switch off the amplifier or continue
with another adjustment procedure.

Offset

The Offset adjustment procedure minimises the DC
offset value of the amplifier output. This DC offset is
important when capacitive loads are used, such as
electrostatic loudspeakers. These loudspeakers
often use a very low-impedance step-up
transformer. The amplifier ‘sees’ this load as a
short for the DC voltage.

Connect the amplifier according to the drawing
“Measurement Set-up” (page 11).
The input of the amplifier must be shorted (by way
of the MUTE function of the oscillator).

• Switch the amplifier ON and wait until it has
reached the proper working temperature.

• Set the millivolt-meter to the DC-range.

• Place the measurement clips of the meter over

the output terminal.

• The level should not exceed +1 or -1 mV DC.
If it does: adjust potmeter P1L (Left) or P1R
(Right) until the level is within this range.

• Repeat this procedure after 20 minutes to
finalise the adjustment.

• Switch the oscillator on and set it to 1 kHz and a
level of 0 dBV (1 V).

• Check the distortion with a THD analyser: it
should be conform to the specified value
(0.006% IHF-A @ 1 – 20 kHz @ 50 W into 8
ohm).
If this is correct the procedure is finished.

You may now switch off the amplifier or continue
with another adjustment procedure.

SPHINX Myth 11 Service Manual

9

7. PROBLEMS AND SOLUTIONS

At the moment of writing the Myth 11 has one
known specific problem.
If in the future you encounter any problem(s) you
may enter the info in this table. This table can then
be used for future reference.

Please also send (by fax or e-mail) the specific
information to the Sphinx International Service
Department (see page 3): this info can then be
added to the general database to aid others.

Problem Cause Solution Refer to

page…

Protection activates Temperature of amplifier is too

high

Re-adjust bias 14/15

Hum at the output.
Modified from November 1998.

Cinch input connector not
modified.

Separate the ground from L&R
cinch input and place a 10 Ohm
resistor between.

10

SPHINX Myth 11 Service Manual

10

8. DIAGRAMS AND PARTS LISTS

The next pages contain the front and rear panel lay­out and a complete set of schematic drawings
including the associated parts lists (if applicable).

hier massa doorslijpen

RIGHT

LEFT

Tussen beide massa's een weerstand van 1R solderen

Modificatie tegen brommen.

Massa's linker kanaal en rechter kanaal nu appart aansluiten

CN1

RIGHT

CN2

LEFT

R
1R

Right GND

Left GND

TO RIGHT AMP

TO LEFT AMP

SPHINX Myth 11 Service Manual

11

Measurement Set-up

+

GND

+

GND

Left

Right

MYTH 11

out1 out2

inp2

inp1

gnd

THD

Amplitude

Frequency

Oscillator

THD out

(+) (-) (+) (-)

THD ANALYZER

x

y

inp2

time/div

inp1

gnd

SCOOP

out1 out2

inp2inp1

Scoop

SWITCH-BOX

mVmV

8R

8R

GND

GND

GND

GND

SPHINX Myth 11 Service Manual

12

General Overview Myth 11

Myth 11 protection
M11-prot.sch

Myth 11 input
M11-inp.sch

Myth 11 rectifier
M11-rect.sch

Myth 11 amplifier left
M11-ampl.sch

Myth 11 amplifier right
M11-ampr.sch

SPHINX Myth 11 Service Manual

13

Power Supply

D1

SB356

D4

SB356

C2

220n/250V

C1

220n/250V

C3
220n/250V C4

220n/250V

C6

220n/250V

C9

220n/250VC8

220n/250V

C7

220n/250V

+

C5

220u/63V

D3 1N4007

D2 1N40072

1

2
1
2
1
2
1

FASE

NUL

2
1

2
1
2
1
2
1

1
2
1
2

2

1

2

1

2

1

2

1

-OUT1

+OUT1

+50V1

GND_BEV

GNDOUT1

AC1_SEC1

AC1_SEC2

AC2_SEC1 AC2_SEC2

AC3_SEC1 AC3_SEC2

AC4_SEC1 AC4_SEC2

NTC1
NTC-3

AC-PRIM1

AC-PRIM2

NC1

NC2

NC3

NC4

SPHINX Myth 11 Service Manual

14

Amplifier Left

C21L

10u/100V

C1L

120p

C2L

220p

C3L

1u

C14L

100n

C9L

100n

C4L

100n

R1L
475R

R2L
22k

AGND

R9L
22R

R10L
22R

R11L
1k00

R12L
475R

R13L
22k

R3L
475R

R4L
12k

P3L
200R

Q1L
2SK389

Q4L
2SC1775

+

C10L

100u/16V

D1L

LED

AGND

AGND

+

C13L

220u/63V

AGND

Q2L
2SC1775

Q3L
2SC1775

R7L
820R

R8L
820R

R5L
22k

R6L
120k

Q5L
2SA970

Q6L
2SA970

R15L
39R

R17L
39R

R16L
56R

R14L
15k

C12L

100n

+

C11L

220u/63V

AGND

AGND

R20L
300R

R21L
300R

Q8L
2SC2240

Q7L
2SC2240

R18L
3k3

R19L
220R

P4L

500R

Q9L
2SC2240

C6L

100n

R24L
1k

R23L
2R2

R22L
2R2

R25L
22R

R26L
22R

R27L
56R/2W

R28L
100R

R30L
0R22/5W

R37L
100R

R39L
0R22/5W

R29L
68R

R31L
0R22/5W

R38L
68R

R32L
47R/2W

R40L
0R22/5W

Q10L
2SC2705

C5L

10p

Q11L
2SA1145

Q15L
2SJ200

Q18L
2SJ200

Q14L
2SK1529

Q17L
2SK1529

Q12L
2SC4382

Q13L
2SA1668

D6L

1N4007

D7L

1N4007

C7L

47n

AGND

SGNAUDIO

GNDAUDIO

C26L

470p

C28L

100n

+

C32L

2200u/63V

+

C34L

2200u/63V

+

C36L

2200u/63V

+

C38L

2200u/63V

+

C40L

2200u/63V

+

C42L

2200u/63V

+

C44L

2200u/63V

+

C45L

2200u/63V

C27L

470p

C29L

100n

+

C33L

2200u/63V

+

C35L

2200u/63V

+

C37L

2200u/63V

+

C39L

2200u/63V

+

C41L

2200u/63V

+

C43L

2200u/63V

+

C46L

2200u/63V

+

C47L

2200u/63V

+50V

NUL

-50V

AGND

AGND

REL1L
SCHRA_4W

R44L
22K

L1L
EE-K-021

R33L
10R/5W

R34L
10R/5W

C8L

220n

C24L

10n

C23L

1n/400V

AGND

FRAME

OUTPUT-

OUTPUT+

R35L
220R

R36L
100R

C19L

1n

Q16L

2SC1775

D2L

1N4148

A

B

B

A

C4LC6L

C2L

OPTO1L

CNY17

DGND

C3L

OPTO+
OPTO-

PTCL1
PTCL2

C5L

C8L
C10L

C9L
C7L

NC

C1L

SPHINX Myth 11 Service Manual

15

Amplifier Right

C21R

10u/100V

C1R

120p

C2R

220p

C3R

1u

C14R

100n

C9R

100n

C4R

100n

R1R
475R

R2R
22k

AGND

R9R
22R

R10R
22R

R11R
1k00

R12R
475R

R13R
22k

R3R
475R

R4R
12k

P3R
200R

Q1R
2SK389

Q4R
2SC1775

+

C10R

100u/16V

D1R

LED

AGND

AGND

+

C13R

220u/63V

AGND

Q2R
2SC1775

Q3R
2SC1775

R7R
820R

R8R
820R

R5R
22k

R6R
120k

Q5R
2SA970

Q6R
2SA970

R15R
39R

R17R
39R

R16R
56R

R14R
15k

C12R

100n

+

C11R

220u/63V

AGND

AGND

R20R
300R

R21R
300R

Q8R
2SC2240

Q7R
2SC2240

R18R
3k3

R19R
220R

P4R

500R

Q9R
2SC2240

C6R

100n

R24R
1k

R23R
2R2

R22R
2R2

R25R
22R

R26R
22R

R27R
56R/2W

R28R
100R

R30R
0R22/5W

R37R
100R

R39R
0R22/5W

R29R
68R

R31R
0R22/5W

R38R
68R

R32R
47R/2W

R40R
0R22/5W

Q10R
2SC2705

C5R

10p

Q11R
2SA1145

Q15R
2SJ200

Q18R
2SJ200

Q14R
2SK1529

Q17R
2SK1529

Q12R
2SC4382

Q13R
2SA1668

D6R

1N4007

D7R

1N4007

C7R

47n

AGND

SGNAUDIO

GNDAUDIO

C26R

470p

C28R

100n

+

C32R

2200u/63V

+

C34R

2200u/63V

+

C36R

2200u/63V

+

C38R

2200u/63V

+

C40R

2200u/63V

+

C42R

2200u/63V

+

C44R

2200u/63V

+

C45R

2200u/63V

C27R

470p

C29R

100n

+

C33R

2200u/63V

+

C35R

2200u/63V

+

C37R

2200u/63V

+

C39R

2200u/63V

+

C41R

2200u/63V

+

C43R

2200u/63V

+

C46R

2200u/63V

+

C47R

2200u/63V

+50V

NUL

-50V

AGND

AGND

REL1R
SCHRA_4W

R44R
22K

L1R
EE-K-021

R33R
10R/5W

R34R
10R/5W

C8R

220n

C24R

10n

C23R

1n/400V

AGND

FRAME

OUTPUT-

OUTPUT+

R35R
220R

R36R
100R

C19R

1n

Q16R

2SC1775

D2R

1N4148

A

B

B

A

C4RC6R

C10R

OPTO1R

CNY17

DGND

C7R
C8R

PTCR1
PTCR2

C2R

C5R
C1R
C3R

NC
NC

C9R

SPHINX Myth 11 Service Manual

16

Input / Output

INPUT

OPTO
AMP_PHTRAN

RSIG
LSIG
RGND
LGND
OPTO+

OPTO-

SPHINX Myth 11 Service Manual

17

Control

R22
470R/2W

R23
470R/2W

R6A
560R

D6

5V1

D6A

5V1

+

C6

10u/16V

+50V +5V

DGND

R1
4k7

R4
4k7

R3
4k7

R2
4k7

C2

100n

+5V+5V

C1

100n

DGNDDGND

R9
10kR747k

R8
4k7

C5

100n

+50V

DGND

C19

1n

R19
4k7

R21
100k

R24
2k2

C3

100n

+

C4

1u/16V

DGND

DGND

+5V

+5V

C9

100n

S2 S1

DGND

R5
2k2

C12

100n

DGND

R14
390R

C7

100n

D1

LED

DGND

R15
390R

C8

100n

D2

LED

DGND

R18
390R

C11

100n

D3

LED

DGND

C10

100n

C13

100n

R10
560R

R13
560R

DGND

DGND

DGND

DGND

DGND

R12
2k2

R11
2k2

C14

100n

Q1
BD879

D4

BYD77

led protect

led stand_by

power led

LOW BIAS

LOW BIAS

DGND

+50V

D7

BYD17D5BYD17

C17

100n

C18

100n

C16

100n

R26
4k7

R20
10k

R17
10k

R27
4k7

R16
10k

Q4
BC817

Q5
BC817

Q6
BC807

+

C15

330u/6V3

DGND

+5V

C211nC20

1n

DGND

RA2

1

RA3

2

RA4

3

/MCRL

4

GND

5

RB0

6

RB1

7

RB2

8

RB3

9

RB4

10

RB5

11

RB6

12

RB7

13

VCC

14

X2

15

X1

16

RA0

17

RA1

18

U1
PIC16C71

+50V

GND

CR1

CR3

CL1 CR9

CR10
CL2

KAST1KAST2

CL10

CL8

CL7

CL9

CR6
CR4
CL6
CL4

CL3

CR8

RELAYS RIGHT

RELAYS LEFT

OVERCURRENT

OVERVOLTAGE

OPTO INPUT

OVER VOLT.

PTC2 PTC1

CR7
CR5
CR2

CL5

SPHINX Myth 11 Service Manual

18

Parts List

Designator Part Type Description

C1 100n MKT capacitor
C1 220n/250V MKT capacitor
C10 100n MKT capacitor
C10L 100u/16V Electrolytic capacitor
C10L 1PIN Connector
C10R 100u/16V Electrolytic capacitor
C11 100n MKT capacitor
C11L 220u/63V Electrolytic capacitor
C11R 220u/63V Electrolytic capacitor
C12 100n MKT capacitor
C12L 100n MKT capacitor
C12R 100n MKT capacitor
C13 100n MKT capacitor
C13L 220u/63V Electrolytic capacitor
C13R 220u/63V Electrolytic capacitor
C14 100n MKT capacitor
C14L 100n MKT capacitor
C14R 100n MKT capacitor
C15 330u/6V3 Electrolytic capacitor
C16 100n MKT capacitor
C17 100n MKT capacitor
C18 100n MKT capacitor
C19 1n MKT capacitor
C19L 1n MKT capacitor
C19R 1n MKT capacitor
C1L 120p Styroflex capacitor
C1R 120p Styroflex capacitor
C1R 1PIN Connector
C2 100n MKT capacitor
C2 220n/250V MKT capacitor
C20 1n MKT capacitor
C21 1n MKT capacitor
C21L 10u/100V MKT capacitor
C21R 10u/100V MKT capacitor
C23L 1n/400V MKT capacitor
C23R 1n/400V MKT capacitor
C24L 10n MKT capacitor
C24R 10n MKT capacitor
C26L 470p Styroflex capacitor
C26R 470p Styroflex capacitor
C27L 470p Styroflex capacitor
C27R 470p Styroflex capacitor
C28L 100n MKT capacitor
C28R 100n MKT capacitor
C29L 100n MKT capacitor
C29R 100n MKT capacitor
C2L 220p Styroflex capacitor
C2R 1PIN Connector

SPHINX Myth 11 Service Manual

19

Designator Part Type Description

C2R 220p Styroflex capacitor
C3 100n MKT capacitor
C3 220n/250V MKT capacitor
C32L 2200u/63V Electrolytic capacitor
C32R 2200u/63V Electrolytic capacitor
C33L 2200u/63V Electrolytic capacitor
C33R 2200u/63V Electrolytic capacitor
C34L 2200u/63V Electrolytic capacitor
C34R 2200u/63V Electrolytic capacitor
C35L 2200u/63V Electrolytic capacitor
C35R 2200u/63V Electrolytic capacitor
C36L 2200u/63V Electrolytic capacitor
C36R 2200u/63V Electrolytic capacitor
C37L 2200u/63V Electrolytic capacitor
C37R 2200u/63V Electrolytic capacitor
C38L 2200u/63V Electrolytic capacitor
C38R 2200u/63V Electrolytic capacitor
C39L 2200u/63V Electrolytic capacitor
C39R 2200u/63V Electrolytic capacitor
C3L 1u MKT capacitor
C3R 1PIN Electrolytic capacitor
C3R 1u MKT capacitor
C4 1u/16V Electrolytic capacitor
C4 220n/250V MKT capacitor
C40L 2200u/63V Electrolytic capacitor
C40R 2200u/63V Electrolytic capacitor
C41L 2200u/63V Electrolytic capacitor
C41R 2200u/63V Electrolytic capacitor
C42L 2200u/63V Electrolytic capacitor
C42R 2200u/63V Electrolytic capacitor
C43L 2200u/63V Electrolytic capacitor
C43R 2200u/63V Electrolytic capacitor
C44L 2200u/63V Electrolytic capacitor
C44R 2200u/63V Electrolytic capacitor
C45L 2200u/63V Electrolytic capacitor
C45R 2200u/63V Electrolytic capacitor
C46L 2200u/63V Electrolytic capacitor
C46R 2200u/63V Electrolytic capacitor
C47L 2200u/63V Electrolytic capacitor
C47R 2200u/63V Electrolytic capacitor
C4L 100n MKT capacitor
C4R 100n MKT capacitor
C5 100n MKT capacitor
C5 220u/63V Electrolytic capacitor
C5L 10p Styroflex capacitor
C5L 1PIN Connector
C5R 10p Styroflex capacitor
C5R 1PIN Connector
C6 10u/16V Electrolytic capacitor
C6 220n/250V MKT capacitor

SPHINX Myth 11 Service Manual

20

Designator Part Type Description

C6L 100n MKT capacitor
C6R 100n MKT capacitor
C7 100n MKT capacitor
C7 220n/250V MKT capacitor
C7L 1PIN Connector
C7L 47n MKT capacitor
C7R 47n MKT capacitor
C8 100n MKT capacitor
C8 220n/250V MKT capacitor
C8L 1PIN Connector
C8L 220n MKT capacitor
C8R 220n MKT capacitor
C9 100n MKT capacitor
C9 220n/250V MKT capacitor
C9L 100n MKT capacitor
C9L 1PIN Connector
C9R 100n MKT capacitor

CN1 INPUT CINCH-2P

D1 LED LED red
D1 SB356 Diode
D1L LED LED red
D1R LED LED red
D2 1N4007 Diode
D2 LED LED red
D2L 1N4148 Diode
D2R 1N4148 Diode
D3 1N4007 Diode
D3 LED LED red
D4 BYD77 Diode
D4 SB356 Diode
D5 BYD17 Diode
D6 5V1 Zener diode
D6A 5V1 Zener diode
D6L 1N4007 Diode
D6R 1N4007 Diode
D7 BYD17 Diode
D7L 1N4007 Diode
D7R 1N4007 Diode

L1L 47uH Coil
L1R 47uH Coil

NTC1 NTC-3 NTC

OPTO AMP_PHTRAN Optical output
OPTO1L CNY17 Opto-coupler
OPTO1R CNY17 Opto-coupler

SPHINX Myth 11 Service Manual

21

Designator Part Type Description

P3L 200R Adj. potmeter
P3R 200R Adj. potmeter
P4L 500R Adj. potmeter
P4R 500R Adj. potmeter

Q1 BD879 Transistor
Q10L 2SC2705 Transistor
Q10R 2SC2705 Transistor
Q11L 2SA1145 Transistor
Q11R 2SA1145 Transistor
Q12L 2SC4382 Transistor
Q12R 2SC4382 Transistor
Q13L 2SA1668 Transistor
Q13R 2SA1668 Transistor
Q14L 2SK1529 Transistor
Q14R 2SK1529 Transistor
Q15L 2SJ200 Transistor
Q15R 2SJ200 Transistor
Q16L 2SC1775 Transistor
Q16R 2SC1775 Transistor
Q17L 2SK1529 Transistor
Q17R 2SK1529 Transistor
Q18L 2SJ200 Transistor
Q18R 2SJ200 Transistor

Q1L 2SK389 DUAL N-JFET
Q1R 2SK389 DUAL N-JFET

Q2L 2SC1775 Transistor
Q2R 2SC1775 Transistor
Q3L 2SC1775 Transistor
Q3R 2SC1775 Transistor
Q4 BC817 Transistor
Q4L 2SC1775 Transistor
Q4R 2SC1775 Transistor
Q5 BC817 Transistor
Q5L 2SA970 Transistor
Q5R 2SA970 Transistor
Q6 BC807 Transistor
Q6L 2SA970 Transistor
Q6R 2SA970 Transistor
Q7L 2SC2240 Transistor
Q7R 2SC2240 Transistor
Q8L 2SC2240 Transistor
Q8R 2SC2240 Transistor
Q9L 2SC2240 Transistor
Q9R 2SC2240 Transistor

R1 4k7 Resistor
R10 560R Resistor

SPHINX Myth 11 Service Manual

22

Designator Part Type Description

R10L 22R Resistor
R10R 22R Resistor
R11 2k2 Resistor
R11L 1k00 Resistor
R11R 1k00 Resistor
R12 2k2 Resistor
R12L 475R Resistor
R12R 475R Resistor
R13 560R Resistor
R13L 22k Resistor
R13R 22k Resistor
R14 390R Resistor
R14L 15k Resistor
R14R 15k Resistor
R15 390R Resistor
R15L 39R Resistor
R15R 39R Resistor
R16 10k Resistor
R16L 56R Resistor
R16R 56R Resistor
R17 10k Resistor
R17L 39R Resistor
R17R 39R Resistor
R18 390R Resistor
R18L 3k3 Resistor
R18R 3k3 Resistor
R19 4k7 Resistor
R19L 220R Resistor
R19R 220R Resistor
R1L 475R Resistor
R1R 475R Resistor
R2 4k7 Resistor
R20 10k Resistor
R20L 300R Resistor
R20R 300R Resistor
R21 100k Resistor
R21L 300R Resistor
R21R 300R Resistor
R22 470R/2W Resistor
R22L 2R2 Resistor
R22R 2R2 Resistor
R23 470R/2W Resistor
R23L 2R2 Resistor
R23R 2R2 Resistor
R24 2k2 Resistor
R24L 1k Resistor
R24R 1k Resistor
R25L 22R Resistor
R25R 22R Resistor
R26 4k7 Resistor

SPHINX Myth 11 Service Manual

23

Designator Part Type Description

R26L 22R Resistor
R26R 22R Resistor
R27 4k7 Resistor
R27L 56R/2W Resistor
R27R 56R/2W Resistor
R28L 100R Resistor
R28R 100R Resistor
R29L 68R Resistor
R29R 68R Resistor
R2L 22k Resistor
R2R 22k Resistor
R3 4k7 Resistor
R30L 0R22/5W Resistor
R30R 0R22/5W Resistor
R31L 0R22/5W Resistor
R31R 0R22/5W Resistor
R32L 47R/2W Resistor
R32R 47R/2W Resistor
R33L 10R/5W Resistor
R33R 10R/5W Resistor
R34L 10R/5W Resistor
R34R 10R/5W Resistor
R35L 220R Resistor
R35R 220R Resistor
R36L 100R Resistor
R36R 100R Resistor
R37L 100R Resistor
R37R 100R Resistor
R38L 68R Resistor
R38R 68R Resistor
R39L 0R22/5W Resistor
R39R 0R22/5W Resistor
R3L 475R Resistor
R3R 475R Resistor
R4 4k7 Resistor
R40L 0R22/5W Resistor
R40R 0R22/5W Resistor
R44L 22K Resistor
R44R 22K Resistor
R4L 12k Resistor
R4R 12k Resistor
R5 2k2 Resistor
R5L 22k Resistor
R5R 22k Resistor
R6A 560R Resistor
R6L 120k Resistor
R6R 120k Resistor
R7 47k Resistor
R7L 820R Resistor
R7R 820R Resistor

SPHINX Myth 11 Service Manual

24

Designator Part Type Description

R8 4k7 Resistor
R8L 820R Resistor
R8R 820R Resistor
R9 10k Resistor
R9L 22R Resistor
R9R 22R Resistor

REL1L SCHRA_4W Relay
REL1R SCHRA_4W Relay

S1 SWITCH-SPST Switch
S2 SWITCH-SPST Switch

U1 PIC16C71 Micro processor
