900-06002
SPHERE TWIN LNB SATELLITE SYSTEM. SSA-850
SERVICE MANUAL
Please read the User Manual in its enrety before installing or operang this product.
Disclaimer:
Coast RV PTY LTD accepts no liability for any loss or damage, which may occur as a result of improper or unsafe use of its
products.
Warranty is only valid if the product has not been modied or misused and the original proof of purchase can be provided.
coastrv.com.au coastrv.co.nz
2
Dip Switch Function
Dip Switch Mode Dip Switch Mode
: Up
: Dn
: Up
: Dn
NORMAL
OPERATION
N/A
N/A
Manual Mode
Elevation
N/A
Manual Mode
Azimuth
N/A
Manual Mode
Skew
coastrv.com.au coastrv.co.nz
3
coastrv.com.au coastrv.co.nz
4
coastrv.com.au coastrv.co.nz
5
coastrv.com.au coastrv.co.nz
6
coastrv.com.au coastrv.co.nz
7
coastrv.com.au coastrv.co.nz
8
