Page 1
MANUAL
CATWALKER TABLE
Page 2
1
1
4
2
3
2
3
CATWALKERMANUAL
- Collect all needed items together.
- Clean the oor and make enough
space for the table installation.
- Place the tabletop upside down to the
oor without removing the packaging.
(to protect your tabletop)
- Open the package and reveal the
undercarriage.
What you will need:
- Ring spanner or a ratchet ring spanner 17MM.
- At least 4 strong hands to carry and turn over the solid wood table of 70-80kg.
- Every table corner corresponds to
a particular leg. Please see the
numbering on each leg.
- Screw the legs on the table with
a 17MM spanner but just tight
enough for the moment.
- Stick the felts on every table leg.
1
If you have any questions, please call us.
P.O. Box 5515, 6802 EM Arnhem, the Netherlands | +31 (0)26 3610162 | [email protected] | www.spell-online.com
CA.TA.11.01
Page 3
4
5
6
- Pick the table up from the tabletop
with 2 strong persons.
Please note: Do not lift up the table
from the legs!
If you have any questions, please call us.
- Flip it over in two steps!
(Switch hands while ipping the table
to protect your back from the weight).
Not in one time!
- Tighten up the screws on the legs and move
the Catwalker in position.
- Wipe the table with a soft cloth and enjoy!
2
P.O. Box 5515, 6802 EM Arnhem, the Netherlands | +31 (0)26 3610162 | [email protected] | www.spell-online.com
CA.TA.11.01
