3M™ Speedglas™ 100
Welding Shield

BEFORE WELDING

For your own protection read these instructions carefully before using the
Speedglas 100 welding shield.

The complete assembly is illustrated in fi gure A:1.
Adjust the welding shield according to your individual requirements to

reach the highest comfort. (see fi gure B:1 - B:3).
Shade number should be chosen according to table on page 217.
The Speedglas 100 welding shield gives permanent protection (shade 12

equivalent) against harmful UV- and IR-radiation, regardless of whether
the fi lter is in the light or dark state or whether the auto-darkening function
is operational.

Two lithium batteries are used as the power source (3V CR2032).

WARNING!

When used in accordance with these user instructions, this product is
designed to help protect the wearer‘s eyes and face from harmful radiation
including visible light, ultra-violet radiation (UV), infrared radiation (IR)
and sparks and spatter resulting from certain arc welding processes.

Use of this product in any other application such as laser welding/cutting
or gas welding/cutting may result in permanent eye injury and vision loss.

Do not use any welding product without appropriate training. Read
instructions before use.

Use only with original Speedglas brand spare parts such as inner and
outer protection plates according to the part numbers provided in these
instructions. The use of substitute components or modifi cations not
specifi ed in these user instructions might impair protection and may
invalidate claims under the warranty or cause the shield to be non­compliant with protection classifi cations and approvals.

The Speedglas 100 welding shield is not designed for heavy duty
overhead welding/cutting operations due to the risk of burns from falling
molten metal.

•

•

•

•

•

1 ï

2

The manufacturer is not responsible for any modifi cations to the welding
fi lter or use with welding shields other than the Speedglas 100 welding
shield. Protection may be seriously impaired if unsuitable modifi cations
are made.

Wearers of ophthalmic spectacles should be aware that in the case of
severe impact hazards the deformation of the shield might cause the
inside of the shield to come into contact with the spectacles creating a
hazard for the wearer.

APPROVALS

Speedglas 100 has been shown to meet the Basic Safety Requirements
under Article 10 of the European Directive 89/686/EEC and is thus CE
marked. The product complies with the harmonized European Standards
EN 175, EN 166, EN 169 and EN 379. The product was examined at the
design state by DIN Certco Prüf- und Zertifi erungszentrum (Notifi ed body
number 0196).

Markings

The welding fi lter is marked with the shade range and optical
classifi cations.

The following is an example (EN 379):

3 / 8-1 2 3M 1 / 2 / 2 / 3 / EN379 CE
Light shade

Dark shade(s)
Manufacturer identifi cation
Optical class
Diffusion of light class
Variations in Luminous transmittance class
Angle dependency class (optional marking)
Certifi cation mark or number of standard

Note! The above is an example. Valid classifi cation is marked on the
welding fi lter.

The markings on the welding shield and the protection plates, indicate
safety class for protection against high speed particles. S stands for the
basic requirement for increased robustness, F stands for low energy impact
and B stands for medium energy impact.

•

•

1 ï

3

If the protection meets the requirements at extremes of temperature (-5°C
to +55°C) the marking is completed with the letter T. Additional markings
on the product refer to other standards.

FUNCTIONS

On/Off

To activate the welding fi lter, press the ON/SHADE button. The welding
fi lter automatically turns OFF after 1 hour of inactivity.

The welding fi lter has two photo sensors (see fi g A:2) that react independently
and cause the fi lter to darken when a welding arc is struck. The welding
fi lter may not go to dark position if the sensors are blocked or the welding
arc is totally shielded.

Flashing light sources (e.g. safety strobe lights) can trigger the welding
fi lter making it fl ash when no welding is occurring. This interference can
occur from long distances and/or from refl ected light. Welding areas must
be shielded from such interference.

Shade

Models Speedglas 100S-10 and Speedglas 100S-11 have a fi xed dark
shade where no setting is required.

Model Speedglas 100V has selectable dark shade settings. Five different
Shade Number settings, 8-12, are available in the dark state. In order to
see the current Shade Number setting, momentarily press the ON/SHADE
button. To select another Shade Number, press the ON/SHADE button
repeatedly while the LED indicators on the display are fl ashing. Move the
fl ashing LED to the desired Shade Number.

In all welding processes the arc should only be viewed with the
recommended dark shade. See table page 217.

1 ï

4

Sensitivity setting (Speedglas 100V only)

The sensitivity of the photo detector system (which responds to the
light from the welding arc) can be adjusted to accommodate a variety of
welding methods and workplace conditions. In order to see the current
sensitivity setting, momentarily press the SENS button. To select another
setting, press the SENS button repeatedly until the LED shows the desired
setting.

Position 1 Least sensitive setting. Used if there is interference
from other welders’ arcs in the vicinity.

Position 2 Normal position. Used for most types of welding
indoors and outdoors.

Position 3 Position for welding with low current or with stable
welding arcs. (eg TIG welding)

If the fi lter does not darken during welding as desired, increase the
sensitivity until the welding fi lter switches reliably. Should the sensitivity
be set too high, the fi lter may remain in the dark state after welding is
complete due to ambient light. In this case, adjust the sensitivity downward
to a setting where the welding fi lter both darkens and lightens as desired.

Low battery indicator

The batteries should be replaced when the low battery indicator fl ashes or
LEDs do not fl ash when the buttons are pressed.

WARNING

Should the Speedglas 100 welding shield fail to switch to the dark state
in response to an arc, stop welding immediately and inspect the welding
fi lter as described in these instructions. Continued use of a welding fi lter
that fails to switch to the dark state may cause temporary vision loss. If the
problem cannot be identifi ed and corrected, do not use the welding fi lter,
contact your supervisor, distributor or 3M for assistance.

MAINTENANCE

Replacement of outer protection plate.

Remove front frame. (see fi gure C:1)
Remove the used outer protection plate and place the new outer protection

plate on the welding fi lter. (see fi gure C:2)
Front frame must always be used (see fi gure C:3).

1 ï

5

Replacement of welding fi lter

The welding fi lter can be removed and replaced according to fi gure E:1 -
E:4.

Replacement of inner protection plate

The used inner protection plate is removed as illustrated in fi gure D:1. The
new inner protection plate should be mounted after the protective fi lm is
removed as illustrated in fi gure D:2.

Magnifying lens (accessory) mounting (see fi gure D:3).

Replacement of batteries

The welding fi lter must be removed from the welding shield to access the
battery compartment (see fi gure E:1-E:4). Take out the battery holder (use
a small screwdriver if necessary). Insert new batteries in the battery holder
according to fi gure G:1. Slide the battery holder into the welding fi lter
until it snaps in position. Note that all settings will be reset to the original
manufacturing setting.

Replacement of headband

The headband can be replaced according to fi gure F:1-F:2.

CAUTION

The used batteries/worn out product parts should be disposed of according
to local regulations. The welding fi lter should be disposed of as electronic
waste.

Temperature range

The recommended operating temperature range for the product is -5°C to
+55°C. Store in a clean and dry environment, temperature range -30°C to
+70°C and relative humidity less than 90%.

Inspection

The sensors (see fi g A:2) on the welding fi lter must be kept clean and
uncovered at all times for correct function.

To check that the electronics and buttons are working, press the buttons
and the LED indicators will fl ash.

1 ï

6

WARNING

Carefully inspect the complete Speedglas 100 welding shield assembly
before each use. Check for cracks in the shield and look for light leaks.
Cracked, pitted or scratched fi lter glass or protection plates reduce vision
and can seriously impair protection. All damaged components should be
replaced immediately.

To avoid damage to the product do not use solvents for cleaning. Clean
the welding fi lter and protection plates with a lint-free tissue or cloth.
Clean the welding shield with a mild detergent and lukewarm water. Do
not immerse in water or spray directly with liquids.

The welding shield is heat resistant and approved against standard
requirements for fl ammability but can catch fi re or melt in contact with open
fl ames or very hot surfaces. Keep the shield clean to minimize this risk.

Materials that come into contact with skin may cause allergic reactions
to susceptible persons.

Parts List 3M™ Speedglas™ 100

Part no. Description
Spare parts

75 11 10 SPEEDGLAS 100 Shield with SPEEDGLAS 100S-10 Auto
darkening welding fi lter Single shade 3/10

75 11 11 SPEEDGLAS 100 Shield with SPEEDGLAS 100S-11 Auto
darkening welding fi lter Single shade 3/11

75 11 20 SPEEDGLAS 100 Shield with SPEEDGLAS 100V Auto
darkening welding fi lter Variable shade 3/8-12

75 11 00 SPEEDGLAS 100 Shield
75 00 10 SPEEDGLAS 100S-10 Auto darkening Welding Filter Single

shade 3/10
75 00 11 SPEEDGLAS 100S-11 Auto darkening Welding Filter Single

shade 3/11
75 00 20 SPEEDGLAS 100V Auto darkening Welding Filter

Variable 3/8-12
75 11 90 SPEEDGLAS 100 Shield without headband
77 20 00 SPEEDGLAS 100 front frame
70 50 10 Headband including assembly parts
70 60 00 Mounting details for headband
73 10 00 Battery cover

•

•

•

•

1 ï

7

Consumables
77 60 00 SPEEDGLAS 100 Outer protection plate standard pkg of 10
77 70 00 SPEEDGLAS 100 Outer protection plate scratch resistant

pkg of 10
77 70 70 SPEEDGLAS 100 Outer protection plate heat resistant

pkg of 10
16 75 20 Sweatband, in towelling, purple, 2 pcs
16 80 10 Sweatband, in fl eece, brown, 1 pcs
42 80 00 Inner protection plate pkg of 5 plate marking 42 02 00
42 80 20 Inner protection plate +1 shade pkg of 5 plate marking 42 02 00
42 80 40 Inner protection plate +2 shade pkg of 5 plate marking 42 02 00
42 20 00 Battery pkg of 2
Accessories
16 40 05 Ear and neck protection in leather (3 parts)
16 90 01 Neck protection in TecaWeld
16 91 00 Hood neck/head in TecaWeld
17 10 17 SPEEDGLAS 100 holder for magnifi er
17 10 20 Magnifying Lens 1.0
17 10 21 Magnifying Lens 1.5
17 10 22 Magnifying Lens 2.0
17 10 23 Magnifying Lens 2.5
17 10 24 Magnifying Lens 3.0

209

Technical Specifi cation

Weight:

Weight welding shield
(incl welding fi lter): 440 g

Viewing area: 44 x 93 mm

UV/IR protection: According to shade number 12
(permanent)

Switching time light to dark: 0.1 ms (+23°C)
Opening time dark to light (delay) 100 ms-250 ms
Light state: shade no 3
Dark state: shade no 8-12
Battery type: 2 x CR2032 (Lithium 3V)
Operating temperature: -5°C to + 55°C

Battery life: 1500 hours
Head sizes: 50-64

Material

Shield: PA
Welding fi lter: PA
Headband: PA
Protection plate: PC

B:1
page 210

new B:3
page 211

new F:1
page 215

Speedglas 100 User Instruction changes 2008-06-02

Position 1 Position 2 Position 3 Position 4

B:2
page 211

F:2
page 215

047103 Speedglas 100 sheet 2008

210

A:2

B:1

A:1

211

Position 1 Position 2 Position 3 Position 4

B:2

B:3

212

C:1

C:2

C:3

213

D:1

D:2

D:3

214

E:1

E:3

E:2

E:4

215

F:1

F:2

216

G:1

217

Recommended shade numbers
according to EN 379:2003

1 3M United Kingdom PLC

3M Centre, Cain Road
Bracknell, Berkshire RG12 8HT
Tel: [phone]
www.3m.com/uk/ohes

ï 3M Ireland

3M House, Adelphi Centre
Upper Georges Street
Dun Laoghaire, Co. Dublin
Tel: [phone]
www.3m.com/uk/ohes

3 3M Deutschland GmbH

In der Heubrach 16
63801 Kleinostheim
Tel: 0 60 27 / 46 87 - 0
[e-mail]
www.3marbeitsschutz.de

% 3M Östereich GmbH

Brunner Feldstraße 63
2380 Perchtoldsdorf
Tel: [phone]
[e-mail]
www.3m.com/at/arbeitsschutz

$ 3M Schweiz AG

Eggstrasse 93, 8803 Rüschlikon
Tél: [phone]
Fax: [phone]
www.3marbeitsschutz.ch

2 3M France

Bd de l’Oise,
95006 Cergy Pontoise Cedex
Tél: [phone]
[e-mail]
www.3m.com/fr/securite

r 3М Россия

125445 Москва
yл. Cмольнaя, дом 24/Д

Бизнес-центр “Меpидиaн”
Тел: [phone]
Факс: [phone]

u 3М Україна

Бiзнес-центр “Подiл Плаза”
Вул. Спаська, 30-а, офiс 7-3Б
04070 Київ, Україна
тел. [phone]

Факс: [phone]
[e-mail]
www.3m.com/ua/siz

4 3M Italia S.p.A.

Via San Bovio 3, Loc San Felice,
20090 Segrate (MI),
Tel: [phone]
Numero verde: 800-012410
www.3msicurezza.it

6

3M Nederland B.V.

Industrieweg 24,
2382 NW Zoeterwoude
Tel: [phone]
[e-mail]
www.3msafety.nl

^ 3M Belgium N.V./S.A.

Hermeslaan 7, 1831 Diegem
Tel: [phone]
Fax: [phone]
www.3Msafety.be

5 3M España, S.A.

Juan Ignacio Luca de Tena 19-25,
28027 Madrid
Tel: [phone]
www.3m.com/es/seguridad

- 3M Portugal

Rua do Conde de Redondo, 98
1169-009 Lisboa
Tel: [phone]
Fax: [phone]

9 3M Norge A/S

Avd. Verneprodukter
Postboks 100, Hvamveien 6,
2026 Skjetten
Tlf: 06384 - Fax [phone]
www.3m.com/no/verneprodukter

7 3M Svenska AB

Bollstanäsvägen 3,
191 89 Sollentuna
Tel: [phone]
www.personskydd.se

8 3M a/s

Fabriksparken 15,
DK-2600 Glostrup
Tel: [phone] - Fax: [phone]
[e-mail]
www.3Msikkerhed.dk

0 Suomen 3M Oy

PL 90, Lars Sonckin kaari 6,
02601 Espoo
Puh: 09-52 521
www.3m.com/fi /tyosuojelutuotteet

/

é 3M Eesti fi liaal

Mustamäe tee 4, 10621 Tallinn
Tel: [phone], Faks: 6 115 901
[e-mail]

| 3M atstovybė

Švitrigailos g. 11b,
LT-03228 Vilnius, Lietuva
Tel: [phone]
Faks: [phone]

l 3M pārstāvniecība Latvijā

K. Ulmaņa gatve 5, LV-1004 Rīga
Tālr.: [phone]
Fakss: [phone]

H 3M Poland

Aleja Katowicka 117, Kajetany
05-830 Nadarzyn
Tel: [phone]
Fax: [phone]

F 3M Česko, spol. s.r.o.

Vyskočilova 1, 140 00 Praha 4
Tel: [phone]
Fax: [phone]

J 3M Hungária Kft.

1138 Budapest,
Váci út 140
Tel: [phone]

L 3M România SRL

Bucharest Business Park, corp D,
et. 3, Str. Menuetului nr. 12,
sector 1, Bucureşti
Telefon: [phone]
Fax: [phone]
www.mmm.com/ro

S 3M (East) AG

Produžnica v Ljubljani
Cesta v Gorice 8,
SI-1000 Ljubljana
Tel: [phone],
Faks: 01/2003-666

D 3M (East) AG

Obchodné zastupitel’stvo
Vajnorská 142,
831 04 Bratislava 3, Slovakia
Tel: [phone], 238
Fax: [phone]
[e-mail]
www.3m.com/sk/oopp

A 3M (East) AG Predstavništvo

Žitnjak bb, 10000 Zagreb
Tel: [phone]
Fax: [phone]

k 3M (East) AG rep. offi ce in

Kazakhstan

4140 Dostyk Ave., 3rd fl oor,
050051, Almaty
tel. [phone],
2374729 direct
fax [phone]
e-mail: [e-mail]

K 3M Търговско

представителство България

1766 София,
Младост 4 Бизнес парк, бл. 4
Тел.: [phone]
Факс: [phone]

: 3M Sanayi ve Ticaret A.Ş.,

Türkiye

İş Güvenliği ve Çevre Koruma
Ürünleri
Nisbetiye Caddesi Akmerkez,
Blok 3 Kat: 5, Etiler 80600
İstanbul
Tel: [phone],
Faks: (212) 282 17 41

= 3M Hellas Limited

Κηψισίας 20
151 25 Μαρούσι,

ΑΘήνα-Μαρσύοι
Τηλ: 210/68 85 300

www.3m.com/gr/occsafety

i מ״עב לארשי 3M

91 םידוהיה תנידמ ׳חר
46120 הילצרה 2042 ד.ת
09 – 9615000 :לט
09 – 9615050 :סקפ

© 3M 2008. All rights reserved. Speedglas is a trademark of 3M. DV-9663-0030-8 / 047102 / 02-2008 / GB-IE-DE-FR-RU-UA-IT-NL-ES-PT-NO-SE-DK-FI-AE

EE-LT-LV-PL-CZ-HU-RO-SI-SK-HR-KZ-BG-TR-GR-IL
