SpeechVive SV1001R, SV1002L User Manual

Download

Reviving Speech and

Improving Lives

About SpeechVive™

1-800-392-3309 info@speechvive.com www.speechvive.com

Device Model Number: SV1001R & SV1002L

Registering your SpeechVive will link your

product with important information regarding

proof of ownership, warranty service, and

recall notifications.

You will be asked to provide:

Your contact information SpeechVive specialist Serial #

To Register:

Online: www.speechvive.com/register

Complete and mail the enclosed postcard

Table of Contents

Welcome. . . . . . . . . . . . . . . . . . . . . . . . . 5

Indications for Use . . . . . . . . . . . . . . . . . 6

SpeechVive Components . . . . . . . . . . . . 7

Quick Start Guide . . . . . . . . . . . . . . . . . . 9

Attaching Silicone Ear Tips . . . . . . . . . . 10

Your Charging Station . . . . . . . . . . . . . 11

Charging Your SpeechVive . . . . . . . . . . 12

Wearing Your SpeechVive . . . . . . . . . . .13

Storing Your SpeechVive . . . . . . . . . . . .14

Table of Contents

SpeechVive Care and Maintenance . . . .15

Cleaning the Silicone Ear Tip. . . . . . . . . 16

Frequently Asked Questions . . . . . . . . . 17

Tips for Better Communication . . . . . . . 19

Troubleshooting . . . . . . . . . . . . . . . . . . . 20

Warranty and Service Information. . . . . 21

Technical Information . . . . . . . . . . . . . . 22

Hazards and Warnings . . . . . . . . . . . . . .24

Welcome

Dear SpeechVive User,

On behalf of our entire organization, I want to welcome you to the SpeechVive family.

Our goal is to provide a quality technology that helps you communicate more effectively and stay connected to family and friends. It is our privilege and honor to provide you with a solution that gives you your voice back.

We welcome your feedback and suggestions.

Sincerely,

Steve Mogensen, CEO SpeechVive, Inc smogensen@speechvive.com

Indications for Use

The SpeechVive device provides an audible cue to

automatically trigger the wearer to speak louder

and more clearly.

Low volume Slurred speech Speech rate changes Hoarse/rough voice

The SpeechVive is a medical device. It should only be

used for the intended application. Patients should be

followed by a specialist trained for the SpeechVive

device and speech/voice disorders.

SpeechVive is a prosthetic device that augments

the laryngeal and respiratory system. It provides

more intelligible speech for people with symptoms

of hypokinetic dysarthria.

SpeechVive Components

1- Power Cord 2- Silicone Ear Tips 3- Charging Station 4- Cleaning Tool 5- SpeechVive Device

SpeechVive Components

1-Bridge 2- Ear Piece 3- Silicone Ear Tip 4- Body

1. Attach a Silicone Ear Tip

2. Connect your Charging Station

3. Charge your SpeechVive

4. Wear your SpeechVive

5. Store your SpeechVive

Quick Start Guide

Attaching Silicone Ear Tips

Line up the guides on the back of the silicone tip with the keyhole slots on the earpiece. Gently push the silicone tip into the earpiece and turn the tip 90° clockwise to lock it into place.

Your SpeechVive kit includes small, medium, and large silicone ear tips.

Select the size most appropriate for your

ear. The ear tip should rest gently over the

ear canal, but not inside of it.

If you require assistance selecting the

appropriate size, contact your SpeechVive-

trained specialist.

Your Charging Station

Plug the end of the power cord that does not have prongs into the backside of the charging station. Insert the prongs into a household outlet. The light on the front of the charger will turn

blue.

Charging Your SpeechVive

Place the SpeechVive in the cradle of the charger. The body of the SpeechVive should be toward the back of the charger with the earpiece toward the front of the charger. Close the lid. When the SpeechVive is placed in the charger correctly, the light will turn amber (charging) or

green (fully charged.)

Charge your SpeechVive daily

Wearing Your SpeechVive

Place the ear tip in the conch of the ear. Gently secure the body of the SpeechVive snugly behind the ear, ensuring that the bridge is positioned between your ear and head.

Correct placement of the SpeechVive over the ear

1- Body, 2- Bridge, 3- Conch of the Ear

Storing your SpeechVive

Storing your SpeechVive in the charging station

with the lid closed will maintain optimal battery

performance.

Keep it out of the reach of children and pets. The

small pieces can pose a choking hazard.

WARNING

Moisture will damage your SpeechVive.

Do not wear your SpeechVive in wet/moist

environments.

Store in a cool, dry place.

SpeechVive Care and Maintenance

Inspect the silicone tip for earwax and moisture accumulation.

Ensure there are no cracks, hardening or changes in the silicone tip color. If there are changes, contact SpeechVive to order replacement ear tips.

Do not use soap, cleaning detergents, or solvents to clean the earpiece or device.

To order additional ear tips:

Small: Part #SV1008 (Plantronics-81292-01) Medium: Part #SV1007 (Plantronics- 81292-02) Large: Part #SV1006 (Plantronics- 81292-03)

Contact SpeechVive

1-800-392-3309

Cleaning the Silicone Ear Tip

To remove the silicone tip:

Gently push the silicone tip inward. Turn the tip counterclockwise 90°. Gently pull the silicone tip free of the earpiece.

Use the cleaning tool to gently scrape ear wax from the inside of the silicone tip. Use a soft, dry cloth to clean the outside of the silicone tip and to clear excess debris from the device. Place the silicone tip back into the earpiece for use.

To clean the silicone tip:

WARNING

Only use the cleaning

tool for the silicone

earpiece, not for the

SpeechVive device.

Do not insert the

cleaning tool in the ear.

Frequently Asked Questions

1. How often should I wear my SpeechVive?

It is recommended that you wear your SpeechVive every day during times when you will be talking. Wear it at least 3 hours a day. For best results, read aloud for approximately 30 minutes, 5 days a week to ensure regular practice with the SpeechVive. Follow the recommendations of your SpeechVive-trained specialist.

2. Can I wear my SpeechVive everyday?

Yes, it is recommended that you wear your SpeechVive everyday for best results.

3. Do I have to wear my SpeechVive continuously?

No, you can wear the device as needed during the day.

4. Can I wear my SpeechVive to bed?

No. You could damage the device or cause pain and discomfort to your ear.

5. How often do I need to charge my SpeechVive?

Charge your SpeechVive every evening when you are finished using the device. It may stay in the charger with the lid closed overnight or when not in use.

Frequently Asked Questions, continued

6. How do I know when my SpeechVive is fully charged?

The light on the charging station will turn green when your SpeechVive is fully charged. A full charge takes approximately 2 hrs.

7. What should I do if my SpeechVive stops working?

First, make sure your SpeechVive is fully charged. If it is, make an appointment with your SpeechVive-trained specialist for troubleshooting. The specialist may be able to fix the issue. If not, you will need to contact SpeechVive, Inc for service.

8. Is the SpeechVive a masking device?

No. A masking devices uses a noise stimulus to cover up the perception of a sound (like ringing in your ears caused by tinnitus.) The SpeechVive is not designed for masking; therefore, no effect should be expected.

9. Is SpeechVive a hearing aid?

No. A hearing aid is designed to amplify sound to make sound more audible to a person with hearing loss. The SpeechVive is not an auditory amplifier and no effect should be expected.

Tips for Better Communication

When possible, choose a quiet environment for conversations. Notify your communication partner that you are about to speak. For example, call their name to get their attention before beginning to speak. Let your communication partners know that they need to tell you if they do not understand what you are saying. The sooner the communication breakdown is recognized, the easier it is to repair. Plan communication when your partner is focused on communicating. Use multiple strategies for clarifying your message when a communication breakdown occurs (i.e. repeating, pointing, and gesturing). If possible, communicate face-to-face with others.

Tips adapted from: Yorkston, K.M., Beukelman, D.R., Strand, E.A., and Bell, K.R. with Hustad, K.C. (1999). Optimizing Communication Effectiveness: Bringing It Together, Management of Motor Speech Disorders in Children and Adults (pp. 483-541). Austin, TX: Pro-Ed.

Troubleshooting

Warranty and Service Information

Your investment is protected with SpeechVive,

Inc.'s lifetime warranty. The warranty covers

repairs and replacements due to manufacturing

defects. No warranty claims will be considered for

a device exhibiting normal wear and tear, improper

handling or care, chemical influences, or was

penetrated by moisture.

In the event of damage cause by third parties

or non-authorized service, the SpeechVive

warranty is null and void.

To Contact SpeechVive:

info@speechvive.com

1-800-392-3309

NOTE: Do NOT attempt to open the device or

repair it. Doing so will invalidate the

manufacturer's warranty.

Technical Information

The SpeechVive is worn over the ear and contains an accelerometer that detects when the user speaks. Upon exceeding a threshold value, indicating that the user is speaking, the SpeechVive plays background audio that automatically improves the user's speech. The SpeechVive does not play the background audio when the user is not speaking. The SpeechVive accelerometer sensitivity settings are programmed by the user's SpeechVive-trained specialist.

The SpeechVive charging station is externally powered from 100-240 Vac, 50/60 Hz, 150 mA max AC Mains power source. The charging station output is rated at 5.1 Vdc and 500 mA Max.

The SpeechVive is powered by an internal 3.7 Vdc Lithium-Ion Rechargeable Battery. Your battery may need to be replaced in the future. Please contact SpeechVive, Inc. to arrange this service.

The SpeechVive should be stored or transported in a safe, dry environment. When the device is not in use, it should be kept in the charging station.

Technical Information, continued

The sound level output from the SpeechVive is approximately 85 dBA, which is within the accepted guidelines per IEC 60601-1 12.4.2. This level may be adjusted by your SpeechVive-trained specialist at their professional discretion.

For disposal, follow local code requirements for proper equipment disposal and/or for recycling of the SpeechVive charging station and device, which contains an internal Lithium-Ion Battery.
