BUN DRAWER
For Use with RollsRight Commercial Roller Grill
Operating Instruction Manual
EHD-30-BD
compatible with
EHD-30NS
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this SPECTRUM commercial cooking equipment accessory. SPECTRUM takes pride
in the design and quality of our products. When used as intended and with proper care and maintenance, you will
experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow
the instructions in this manual carefully. It’s important to save these instructions for future reference.
EHD-50-BD
compatible with
EHD-50NS
Table of Contents
Introduction ................................................................................ 2
Packaging .................................................................................... 2
Installation .................................................................................. 2
Cleaning, Care & Maintenance ................................................. 2
Exploded View ........................................................................... 3
Spare Parts List ............................................................................ 3
Introduction
Package Contents
Congratulations on the purchase of your SPECTRUM Bun Drawer.
This unit is designed to enhance the use of the SPECTRUM Roll Right
Commercial Roller Grill. Please take time to carefully read through this
manual to properly install and maintain this unit to ensure the best
possible performance from the product for many years.
SPECTRUM will not accept liability for the following if:
• The instructions in this manual have not been followed correctly.
• Non-authorized personnel have tampered with the machine.
• Non-original spare parts are used.
• The unit has not been handled and cleaned correctly.
• There is any use damage to the unit.
Immediately Inspect for Shipping Damage
All containers should be examined for damage before and during
unloading. The freight carrier has assumed responsibility for its safe
transit and delivery. If equipment is received damaged, either apparent
or concealed, a claim must be made with the delivering carrier.
A. Apparent damage or loss must be noted on the freight bill
at the time of delivery. It must then be signed by the carrier
representative (Driver). If this is not done, the carrier may refuse
the claim. The carrier can supply the necessary forms.
B. If concealed damage or loss is not apparent until after equipment
is uncrated, a request for inspection must be made to the carrier
within 15 days. The carrier should arrange an inspection. Be
certain to keep all contents and packaging material.
All units come with Operation Instructions manual and the following:
• SPECTRUM Bun Drawer
• Pan
SPECTRUM prides itself on quality and service, ensuring that at the
time of packing, all products are supplied fully functional and free
of damage. Should you nd any damage as a result of freight, please
contact your SPECTRUM dealer immediately.
Unpacking the Equipment
DISPOSE OF ALL PACKAGING MATERIALS IN AN
ENVIRONMENTALLY RESPONSIBLE MANNER.
1. Remove all packing materials and tape, as well as any protective
plastic and cardboard, from the unit.
2. Clean any glue residue left over from the plastic or tape.
3. Place the unit in the desired position and height.
NOTE
Please remember that this manual and the warning
labels do not replace the need to be alert, to properly
train and supervise operators, and to use common
sense when using this equipment.
2
Installation
Cleaning, Care & Maintenance
1. Remove the SPECTRUM Bun Drawer from the packaging, ensuring
that all protective packaging, plastic and residues are thoroughly
cleaned from its surfaces.
2. Place the Bun Drawer on a rm level surface.
3. Before installing and operating the Bun Drawer, it is the user’s
responsibility to ensure that all Health & Safety regulations are
met concerning safe positioning, spacing, ventilation, electrical
installation and re prevention.
WARNING AVERTISSEMENT
Fire Hazar d.
Correc t installation p recautions,
procedu res and regulatio ns
must be fo llowed. Operati on
and safe ty training is ne cessary
for all use rs of this equipme nt.
The equip ment must be
install ed by qualied per sonnel
only. Correc t installatio n
precau tions, procedur es and
regulati ons must be followe d
in order to re duce the risk of
re. Hood an d re suppression
system s must be maintaine d
per manuf acturer's guid elines.
Only quali ed and trained
person nel are to use this
equipme nt.
Risque d'incendie
La surcha ue des vapeurs d' huile ou de
l'huile peu t s'enam mer et provoquer
un incendi e. Surveillez la temp érature,
la qualité et l e niveau d’huile. Uti lisez et
entrete nez le système d'élimi nation des
vapeur s d'huile.
Faire chau er l'huile avec précau tion. Si
l'huile fum e, réduire le feu. Ne p as laisser
l'appareil s ans surveillance. Si l e feu se
produit , éteindre l'apparei l, couvrir jusqu'à
refroi dissement. Ne pa s mettre l'eau dans
l'huile chau de ou enammée. Ne fa ites pas
fonct ionner avec de l'huile s ous la barre
d'huile. L’huile sal e a un point d'éclair
plus bas. Re mplacer l'huile sur un e base
régulièr e. Maintenir le niveau d'h uile
correc t. Utiliser un sy stème d'évacuation
de la vapeur d' huile (capot) pour réd uire
l'accumulati on de graisse et d'hu ile sur les
surfa ces de paroi ou de plaf ond.
To maintain the appearance and increase the service
life, clean your unit daily. The SPECTRUM Bun Drawer
should be cleaned after each day’s operation;
however, the unit may require more frequent
cleaning depending on the volume
of production.
1. NEVER use abrasive powders or pads; these cleaners may damage
the stainless steel nish.
2. Discard waste; clean with a damp cloth using warm, soapy water.
Warm soapy water is recommended for cleaning; prolonged use
of cleaning agents may damage stainless steel.
3. Replace the unit when completely dry.
3
Exploded View
MODEL EHD30BD
Spare Parts List
MODEL EHD50BD
No. Description
EHD-30-BD
Part #
EHD-50-BD
Part # QTY
1-1 Pan EHDB-P1-A EHDB-P1-A 1
1-2 Pan N/A EHDB-P1-B 1
2 Drawer Assembly EHDB-P2-30 EHDB-P2-50 1
3 Slider Assembly EHDB-P3 EHDB-P3 1
5 Main Body EHDB-P5-30 EHDB-P5-50 1
6 Bracket Plate – foot EHDB-P6 EHDB-P6 4
7 Feet EHDB-P7 EHDB-P7 4
8 Rear Cover EHDB-P8-30 EHDB-P8-50 1
Please keep this manual in a safe place for future use!
