Spectech T244 User Manual

WARNING

Please read and follow all of the instructions & safety precautions detailed below prior to using this

product. Failure to do so may result in serious personal injury and / or property damage.

Safety Precautions

 Do not expose this product to heat sources (including open flame or direct sunlight)
 Do not expose this product to water or liquids. If liquid enters the product, immediately unplug

the product from any connected power sources or devices.

 Do not disassemble or modify the product
 Avoid dropping this product (or any other heavy impact which might damage the internal

circuit)

 In the unlikely event of any abnormalities (such as strange odor, overheating, leaking, color

change, etc.), discontinue use immediately.

 Avoid cleaning this product using liquids or chemical substances (use dry cloth only)
 Only use attachments/accessories specified by the manufacturer
 Dispose of this item properly (do not dispose of it in trash receptacles and do not attempt to

incinerate it)

 Do not leave this product unattended while it is in use or while it is being charged
 This product is not a toy: KEEP AWAY FROM CHILDREN
 Only re-charge this device using a USB port wall adapter (not included)

 Do not re-charge via USB port on a computer
 When not being used for prolonged periods of time please charge every 3 months to avoid

damaging the battery

T244 User Manual

The T244 is a plastic Wireless V3.0 speaker, with seven interchanging multicolored LED lights
(displayed when speaker is in use). Please see below user instructions.

T244 Specifications

Battery Type: Grade A Lithium Polymer rechargeable battery
Battery Duration/Lifespan: 500 times
Capacity: 180 mAh
Power Input & Current: 3.7V/0.5A
Speaker Output: 3W x 1
Sensitivity: 80dB
Frequency Response: 80Hz-20KHz
Distortion Rate: 1%
Wireless Version: V3.0
Range of Wireless Communication: within 10 meters
Charge Time (0-100%): 1 hour
Playback Time: Up to 1.5 hours
Accessories: Integrated 3.5mm AUX/USB re-charging cable
Product Size: 2” in diameter (sphere speaker)
Net Weight: 80g

T244 Product Map

T244 Operation
Wireless Mode

1. Wireless Mode: Push ON/OFF switch once to the right (aligned with the icon, see Product
Map)

2. AUX Mode: Push ON/OFF switch to the far right (under the ON icon)

3. OFF: Push switch to the far left (under the OFF icon)

Wireless Pairing

1. Once power switch is pushed to the icon, T244 is entered in WIRELESS pairing mode
(multicolored LED lights will appear to indicate that the T244 is ready for Wireless pairing)

2. Enable Bluetooth function on your electronic device.

3. Search Bluetooth signal Spector T244 & pair your device (a short audio prompt will indicate
the devices are paired)

NOTE: previously paired devices will automatically connect to the T244 speaker

Wireless Mode

1. Turn the T244 speaker on by setting button to the Icon

2. Play/Pause/Volume control/Skip songs must be controlled directly on your audio device (no
built-in microphone for answering incoming calls)

AUX Mode

1. To activate AUX mode turn the T244 ON & plug the 3.5mm audio jack into your audio device

2. Play/pause/volume control/skip songs can controlled directly on your audio device only

To Charge the T244

1. Insert the 3.5mm audio output (attached to the T244) into the audio input/USB cable
accessory provided

2. Insert USB output & cable accessory to a wall adapter (not included)

3. A red LED light indicates the device is charging (red LED will turn OFF once fully charged)

Power ON/OFF button

Wireless icon
