Speco Technologies VL647iLT User Manual

INSTRUCTION
MANUAL

Intense Light

Color Dome Camera

VL647iLT

Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.

Rev. 6/9/10

CAUTION

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ISO14001

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ISO14001

RISK OF ELECTRIC SHOCK
DO NOT OPEN

CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

ISO14001

The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.

INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.

WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.

CAUTION : To prevent electric shock and risk of fire hazards:

☞Do NOT use power sources other than those specified.
☞Do NOT expose this appliance to rain or moisture.

This installation should be made by a qualified service person and
should conform to all local codes.

- 2 -

Contents

Contents

Precautions

Sefety Instructions

SPECIFICATIONS

FEATURES

FEATURES

Menu Set Up

▶

Menu Set Up

3

4

5

6

7

8

9

11

▶

Lens Set Up

▶

Exposure

▶

Back Light

▶

S-WDR

▶

White Bal.

▶

Day & Night

▶

S-DNR

▶

Special

◈

Camera Title

◈

D - Effect

◈

Motion

◈

Privacy

◈

Return

▶

Adjust

12
13

15

18
19

20

21

22

23
25
27

28

29

29

▶

Reset

▶

Exit

Trouble Shooting

30
30

31

- 3 -

Precautions

Do not install the camera in
extreme temperature conditions.

Only use the camera under conditions
where temperatures are between

-10°C and +50°C. Be especially careful to provide
ventilation when operating under high
temperatures.

Never keep the camera pointed
directly at strong light.

Do not install the camera under
unstable lighting conditions.

Severe lighting change or flicker can
cause the camera to work improperly.

Do not drop the camera or subject
it to physical shocks.

Do not touch the front lens of the
camera.

This is one of the most important parts of the
camera. Be careful not to leave
fingerprints on the lens cover.

Do not expose the camera to
radioactivity.

It can cause malfunctions to occur.

* If the camera is exposed to

spotlight or object reflecting strong light, smear or blooming may occur.

* please check that the power satisfies the normal specification before

connecting the camera.

Severe lighting change or flicker can
cause the camera to work improperly.

NOTE

If exposed to radioactivity the CCD
will fail.

- 4 -

Sefety Instructions

Precautions for use

◑

This camera should be installed by qualied personnel only

◑

There are no user serviceable parts inside

◑

Do not disassemble this camera other than to make initial adjustments

◑

Use a UL approved regulated 24 volt AC or 12 volt DC power supply

◑

Use appropriate low voltage power cable to prevent re or electrical shock

◑

Please insure that your installation area can support the weight of the camera

Please handle this camera carefully :

◑

Do not use a strong or abrasive detergent when cleaning the camera

◑

Do not install near cooling or heating device

- 5 -

Intense Light Color Dome Camera

DC Auto Iris Varifocal Lens(2.8mm-12mm)

SLC

0.00001LUX

x256

580

Speco Light
Compensation

VL647iLT

■

580TV Lines
DC Auto Iris Varifocal
Lens(2.8mm-12mm)

SPECIFICATIONS

MODEL

Sensor
Total Pixels
Effective Pixels
Scanning System
Synchronization
O.S.D
Backlight
Resolution
S/N (Y signal)
Min. Illumination
White Balance
Electronic Shutter Speed
INTENSE-LT
Gain Control
S-DNR
S-WDR
Motion Detection
Privacy
Mirror
Freeze
Sharpness
D&N Selection
Digital Zoom
Power
Power Consumption
Lens
Operating Temperature/Humidity
Storage Temperature/Humidity
Dimension
Weight

VL647iLT

1/3” Sony Super HAD ll CCD
NTSC=811(H) * 508(V) / PAL=795(H) * 595(V)
NTSC=768(H) * 494(V) / PAL=752(H) * 582(V)
2:1 Interlace
Internal
Available
SLC / HLC / Off Selectable
580TV Lines
52dB (AGC Off, Weight On)

0.00001Lux(Intense Light * 256)
ATW / AWB / AWC → SET / Manual / Indoor / Outdoor
AUTO (1/50sec, 1/60sec ~ 1/100,000sec)
Off / Auto(Selectable limit *2 ~ *256)
High, Middle, Low, Off Selectable
Off/On (0~100 Level Adjustable)
Indoor / Outdoor / Off
On/Off (4 Zone, Alarm Output)
On/Off (8 Zone)
Off / Mirror / V-Rev / Rotate
On/Off
0~31’(Level Adjustable)
Color /BW /Auto
On(*32) / Off
DC 12V
200mA
DC Auto Iris Varifocal Lens(2.8mm-12mm)
14~122ºF RH 95% Max

-4~140ºF RH 95% Max

4.33"(W) * 3.23"(H) * 4.33"(D)

1.54 lbs

FEATURES

HIGHT RESOLUTION

Horizontal resolution of 580 TV lines is achieved by using a SONY Super­HAD CCD with 410,000 pixels, and a custom DSP yielding images with a
high S/N ratio.

Day / Night

The camera can be congured to either display color images in all lighting
conditions or be set automatically switch to B/W in low light conditions.

INTENSE-LIGHT

1/3 inch high-density CCD and Digital Signal Processor permit high quality
image to be captured in very low light conditions.

S-WDR (Speco Wide Dynamic Range)

Enables the camera to obtain clear and high quality images even in strong
backlight conditions.

S-DNR (Speco Dynamic Noise Reduction)

Removes image noise efciently to display sharp images in low light
conditions.

SLC (Speco Light Compensation)

Enables the camera to obtain a clear image when the background image
has strong lighting.

- 7 -

FEATURES

HLC (High Light Compensation)

This function reverses bright spots in the picture (such as headlights).
It enables the entire system to do a better job of resolving and displaying
grayscale information such as license plate.

FREEZE

This function freezes the current scene for detailed viewing.

PRIVACY

It also has the ability to mask up to 8 areas of the picture where viewing is
not desired. Each zone can be independently programmed via the OSD.

OSD

All camera functions are menu driven for easy use.

MIRROR

Picture can be reversed vertically or horizontally.

D-ZOOM

Digital zooming up to X32.

- 8 -

Menu Set-Up

SET UP MENU DEFAULT SET MENU

LENS

EXPOSURE

WHITE BAL.

DAY / NIGHT.

DC

SHUTTER
AGC: --­INTENSE-LT
SLC
S-WDR
RETURN

ATW

COLOR

DC : LEVEL (0 ~100 Adjustable)

SHUTTER : FLK/ 1/60 / 1/250, 1/500, 1/2000, 1/5000,
1/10000, 1/100000
AGC : OFF / LOW / MIDDLE/ HIGH
INTENSE-LT : x2~ x256 Level Selectable
SLC : OFF / SLC (GAIN : LOW, MIDDLE, HIGH/ DEFAULT :

LEFT/RIGHT, WIDTH, TOP/

BOTTOM, HEIGHT, RTURN) /

HLC (LEVEL : RANGE 0~8 Selectable/ DEFAULT :

LEFT/RIGHT, WIDTH, TOP/BOTTOM,

HEIGHT, RETURN)
S-WDR : OFF / INDOOR/ OUTDOOR
RETURN
ATW/ AWB/ MANUAL(R Gain : 0 ~100 Level Selectable,

B Gain : 0 ~100 Level Selectable)
/ AWC SET / INDOOR / OUTDOOR

B/W : BURST, RETURN
COLOR
AUTO : DELAY (0~63) / S-LEVEL(0~100)/ E-LEVEL(0~100)
RETURN

S-DNR

SPECIAL

ADJUST

RESET

EXIT

ON

Refer to the next page

SHARPNESS
BLUE
RED
RETURN

FACTORY

ON (RANGE : 0 ~100 Level Selectable) / OFF

SHARPNESS : (RANGE : 0 ~ 31 Level Adjustable)
BLUE : (RANGE : 0 ~ 100 Level Adjustable)
RED : (RANGE : 0 ~ 100 Level Adjustable)
RETURN

RETURN

Save the SETUP Menu and exit

- 9 -

Special Menu

SPECIAL MENU DEFAULT SET MENU

CAMERA TITLE ON

D - EFFECT ON

MOTION OFF

PRIVACY OFF

ON / OFF

FREEZE / MIRROR/ D-ZOOM/ GAMMA/ NEG. IMAGE /RETURN

AREA SELECT : AREA 1~AREA 4
AREA DISPLAY : ON / OFF
LEFT / RIGHT : 0 ~ 100 Level Adjustable
WIDTH : 0 ~ 100 Level Adjustable
TOP / BOTTOM : 0 ~ 100 Level Adjustable
HEIGHT : 0 ~ 100 Level Adjustable
SENSITIVITY : 0 ~ 40 Level Adjustable
MOTION VIEW : ON / OFF
RETURN

AREA SELECT : AREA 1~AREA 8
AREA DISPLAY : ON / OFF
LEFT / RIGHT : 0 ~ 100 Level Adjustable
WIDTH : 0 ~ 100 Level Adjustable
TOP / BOTTOM : 0 ~ 100 Level Adjustable
HEIGHT : 0 ~ 100 Level Adjustable
COLOR : Selectable in 15 Color
RETURN

RETUEN

END

- 10 -

Menu Set Up

Menu items can be selected by using the OSD buttons of the camera

1. Press the Set Up button.

* The Set Up menu will be displayed on the monitor.

SETUP

LENS

EXPOSURE
WHITE BAL
DAY / NIGHT
S-DNR
SPECIAL
ADJUST
RESET
EXIT

DC

ATW
COLOR
ON

2. Move and select the required function using the Up and Down button.

* Move the arrow indicator Up or Down to select the desired feature by pressing

the Up or Down button.

SETUP

LENS

EXPOSURE
WHITE BAL
DAY / NIGHT
S-DNR
SPECIAL
ADJUST
RESET
EXIT

DC

ATW
COLOR
ON

- 11 -
