Speco Technologies PBM240AT Users Manual

INSTRUCTION MANUAL

PBM240A – 240 WATT RMS PUBLIC ADDRESS AMPLIFIER

PBM240AT – 240 WATT RMS PUBLIC ADDRESS AMPLIFIER WITH TUNER

PBM240AU – 240 WATT RMS PUBLIC ADDRESS AMPLIFIER WITH TUNER/CD/USB

For more information contact Speco Technologies 200 New Highway, Amityville, NY 11701• Toll Free: 1-800-645-5516•Fax: 631-957-9142 or 631-957-3880•www.specotech.com

PRECAUTIONS

1. Unpacking

After removing the amplifier from the carton, inspect for any exterior damage to the unit. If damage is noted, notify the carrier at once so that a claim can be justified. Save all packing material. This is important when the claim is processed.

2. Ventilation

To offset heat generated by the unit, it is necessary to provide ample ventilation around the unit. Avoid blocking or impeding the ventilation holes on the unit. To prevent unnecessary problems, install the unit in a place free from any vibrations, direct sunlight, humidity or dust circulation.

3. Prevent liquids or other materials to enter cabinet

If the unit gets wet or any foreign material enters the amplifier cabinet, immediately disconnect the AC power cord and consult your dealer or qualified technician.

For more information contact Speco Technologies 200 New Highway, Amityville, NY 11701• Toll Free: 1-800-645-5516•Fax: 631-957-9142 or 631-957-3880•www.specotech.com

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions completely.

2. Keep these instructions for future reference.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block ventilation openings. Install in accordance with instructions.

8. Do not install on or near any heat sources such as radiators, heat registers,

stoves or other apparatus (including amplifiers) that produce heat.

9. Do not defeat purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider that the other. A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at

plugs, convenience receptacles and where connected to the apparatus.

11. Only use the attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. Apparatus shall not be exposed to dripping or splashing and no objects

filled with liquids, such as vases, shall be placed on the apparatus.

16. WARNING – To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture.

17. CAUTION – Use of any controls or adjustments or performance of

procedures other than those specified herein may result in hazardous radiation exposure.

For more information contact Speco Technologies 200 New Highway, Amityville, NY 11701• Toll Free: 1-800-645-5516•Fax: 631-957-9142 or 631-957-3880•www.specotech.com

Thank You!

We at Speco Technologies thank you for your purchase of our PBM240A, PBM240AT or PBM240AU amplifier. The PBM240A is an energy efficient Class D amplifier line.

We have taken our customers’ input and created the perfect amplifier for almost any application. In addition to the great features you’ve come to expect in a Speco Technologies amplifier, the PBM-A series has ample inputs, an included IR-remote control, an RS232 input for integration with control systems, front panel locking capability, and includes all rack-mounting hardware.

With a stylish appearance and all these additional features at a price similar to previous generation amplifiers, the PBM-A series is sure to become your go-to amplifier.

Please review this checklist of components to make sure you received all items with your amplifier:

Inside the box (PBM240A)

· One amplifier

· One product manual

· One IR remote control (Battery included)

· One set of rack mounting hardware including two (2) brackets

· AC Power Cord

If you have purchased a PBM240AU or PBM240AT, the module will already be factory installed, and this box should also include:

· AM Antenna

· FM Antenna

Please make sure you have all accessories and your box and unit did not suffer any noticeable damage during transit prior to connecting your amplifier.

TABLE OF CONTENTS Page 3 Safety Instructions Page 5 Features and Specifications Page 5 Front Panel Page 7 Rear Panel Page 10 Reference Information Page 11 PBM240AU Instructions Page 14 PBM240AT Instructions Page 15 IR Remote

For more information contact Speco Technologies 200 New Highway, Amityville, NY 11701• Toll Free: 1-800-645-5516•Fax: 631-957-9142 or 631-957-3880•www.specotech.com

SECTION 1: FEATURES AND SPECIFICATIONS

· 240W RMS/480W Max Power

· AC 100-240V, 50/60Hz

· 3 XLR Microphone inputs with selectable phantom power (Mic 1 has selectable priority)

· Telephone paging input

· Music on hold output

· 5 zoned speaker outputs (70V)

· Non-zoned 4/8 Ohm output

· RCA or XLR line output

· Front Bass and Treble controls

· Individual volume control for each input

· Master digital volume control

· Digital front panel lock

· RS232 input for integration with popular control systems

SECTION 2: Controls and Connections

FRONT PANEL

Module Bay:

a. This will be empty for the PBM240A. b. This will contain a factory-installed Tuner/CD/USB/SD player for the PBM240AU

c. This will contain a factory-installed AM/FM Tuner for the PBM240AT (Page 11).

Zone Selector:

a. Turn specific speaker runs on or off, either via buttons on front panel or

(Page 9).

For more information contact Speco Technologies 200 New Highway, Amityville, NY 11701• Toll Free: 1-800-645-5516•Fax: 631-957-9142 or 631-957-3880•www.specotech.com
