Speco Technologies P120FACD, P240FACD User Manual

Public Address Amplifier

P120FACD/P240FACD

Operation Manual

Welcome

A personal welcome to you from the management and employees of Speco Technologies

All of the co-workers here at Speco Technologies are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.

We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete satisfaction, we will endeavor to make things right.

* This product may overheat if installed in closed box or ill-ventilated place.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

*Do not install this equipment in a confined space such as a book case or similar unit. *The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus. WARNING FOR YOUR PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOISTURE: Unit should not be used near water(e.g. near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do not fall and liquids are not spilled into the enclosure through openings. WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. WARNING: It has heed to be easy to disconnect the device. To disconnect the device from power, separate AC input cable from inlet or unplug the

AC Cord. WARNING: This apparatus shall be connected to a mains socket outlet with a protective earthing connection. WARNING: The appliance inlet or ac mains attachment plug are considered as the main disconnect device. Caution: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any

servicing other than that contained in the operating instructions unless you are qualified to do so.

NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of important operation and maintenance (servicing) instructions in the literature accompanying the appliance.

Caution: To prevent electric shock do not use this (polarized) plug with

an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.

Attentions: Pour prévenir les chocs électriques ne pas utiliser cette

fiche polarisée avec un prolongateur, une prise de courant on une autre sortie de courant, sauf si les lames peuvent étre insérées à fond sans en laisser aucune partie à découvert.

PUBLIC ADDRESS AMPLIFIER

P120FACD/P240FACD

Contents

Unpacking .......................................................................................................................................2

Installation

Environment....................................................................................................................................2

Important Safety Instructions.............................................................................................................2

Features............................................................................................................................................3

Operation ........................................................................................................................................4

Additional Descriptions .................................................................................................................4

Front Panel ......................................................................................................................................5

Rear Panel .......................................................................................................................................8

Connecting Speakers...................................................................................................................11

FM Operation................................................................................................................................12

CD Operation................................................................................................................................13

Channel EQ SETUP .......................................................................................................................14

SETUP Mode ..................................................................................................................................15

Applications ..................................................................................................................................17

Block Diagrams.............................................................................................................................18

Specifications ................................................................................................................................19

Service

Procedures....................................................................................................................................20

Warranty .......................................................................................................................................20

PUBLIC ADDRESS AMPLIFIER

P120FACD/P240FACD

Installation

Environment

Never place this product in an environment which could alter its performance or reduce its service life. Such environments usually include high levels of heat, dust, moisture, and vibration.

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with these instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Unpacking

Although your P120FACD / P240FACD is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation.

As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely event the product must be returned for servicing, the original packaging (or reasonable equivalent) is required.

S3125A

PUBLIC ADDRESS AMPLIFIER

P120FACD/P240FACD

Features

- DIGITAL PROCESSING & DIGITAL AMPLIFIER

Designed with full digital amplifier, low power consumption, low set weight and low heat.

- BUILT IN SOUND SOURCE

You can use the FM digital tuner and MP3CD player which are built in the system for your convenience.

- SPEAKER SELECTOR (5 ZONE)

Six speaker select switches enable you to select any combination of up to five speakers.

- RS-232C IN/OUT CONTROL

AMX/CRESTRON Interface can be used with the RS-232C terminal

- DIGITAL 3 BAND EQ

Digital 3 band EQ for 6 Mic inputs.

- PRIORITY MUTING

Selectable audio signal priority for MIC Channel 1 and 2. Priority : EM > TEL-IN > RM > MIC1/2

- ANNOUNCEMENT CHIME

Convenient two-tone and four-tone chime for announcement.

- EM (EMERGENCY)

When the EM terminals are connected in emergencies, EM broadcasting stored in VOICE IC is outputted.

ACCESSORIES

- One detachable AC power cord is provided for use with this product.

- FM Antenna

PUBLIC ADDRESS AMPLIFIER

P120FACD/P240FACD

Additional Descriptions

MP3 (MPEG AUDIO LAYER-3)

MP3 is a music file format that can contain music with stereo sound quality as good as an audio CD. Compression rate is 1MB/1 minute, thus about 3-5MB for a typical 3-5 minute song. Different from an audio CD, a CD comprised of MP3s can contain over 130 songs, and playing time would be about 6 to 10 hours. The MP3 format removes high frequencies which human ears cannot hear, so it has the advantage of being able to compress the a file to 1/12 or so while maintaining sound quality equivalent to an audio CD. The size of a typical audio CD is roughly 50MB. If the same tracks are compressed to MP3s, it then becomes about 4-5

MB.

- WMA (WINDOWS MEDIA AUDIO)

WMA is a multimedia compression method developed by Microsoft Corporation® and is used to compress music exclusively used in “Windows Media Technologies.” It provides the same sound quality as MP3s using half the Kbps (64 Kpbs vs. 128 Kbps). In other words, it’s half the file size of an MP3 with the same sound quality.

Operation

1. Make sure that speakers and input/output cables are properly connected before you plug in the power.

2. Set all volumes to the minimum position before you turn the power on.

3. Be sure the AC power is the correct voltage before you plug in the power cord.

4. Ensure that the VFD displays and the unit functions when the power button is pressed.

5. Adjust the volume for each channel, as well as the master volume.

6. Adjust the mic channel EQ.

7. Please refer to the CD / FM operation method or Set Up mode section for details.

PUBLIC ADDRESS AMPLIFIER

P120FACD/P240FACD

Front Panel

1. POWER SWITCH

Pressing this switch turns the unit on, and the VFD (Vacuum Fluorescent Display) will show the status of the unit. Pressing again will turn the unit off. If the AC power is connected, the unit will enter Standby mode, and the “POWER” LED will light.

When the protection circuitry is activated, the “POWER” LED will blink. This indicates that the unit is not operating normally. This is typically due to rare cases of overheating, overload or output line shorts. Please check the input and output conditions of the amplifier in this event. The unit will automatically turn the power on and check the protection state 1 minute after the protection circuitry has been activated. If you want to release the protection manually, press the POWER switch.

2. SPEAKER SELECTOR

These switches are used to select speaker output zones. The “All” button will select all speaker zones (SP1, SP2, SP3, SP4 and SP5). 8Ω output is not controlled by the speaker selector buttons.

3. DIMMER BUTTON

Press this button to change the brightness of the display.

4. FM /CD/AUX BUTTON

1) FM MUTE Button This button can be used to mute the FM output while searching for a station with a good signal.

2) FM/CD/AUX select button This button will allow you to toggle between the 3 possible sources.

3) REPEAT Button Press this button to repeat a track or tracks on a CD.

4) GROUP Button Press this button to select a folder on an MP3 disk.

5) RANDOM Button Press this button to randomly play CD tracks.

34 78 9 1012 5 6

15 16 17 1814131211

PUBLIC ADDRESS AMPLIFIER

P120FACD/P240FACD

5. IR WINDOW

6. DISC INSERT SLOT

Insert a CD or CD-ROM here. The player will automatically accept the CD as it’s entered into the slot.

7. NUMERICAL BUTTONS

Press the track number buttons to skip to a specific track on a CD. Press the preset number button to go to a specific preset FM station.

8. CD / FM RELATED BUTTONS

1) (Play/Pause) / PRESET SCAN Button In CD function - Play or Pause Button. In FM function - Preset Scan Button.

2) , / PRESET , PRESET Button In CD function - Backward Skip and Forward Skip Button. In FM function - Preset Down and Preset Up Button

3) (Stop) / MEMO Button In CD function - Stop Button. In FM function - Memory Button

4) , / TUNING , TUNING Button In CD function - Backward Search and Forward Search Button. In FM function - Tuning Down and Tuning UP Button

9. EJECT BUTTON

Press this button to eject the CD from the unit.

10. CHIME BUTTON

CHIME 1 Button : Press this button to activate the 2 tone chime. CHIME 2 Button : Press this button to activate the 4 tone chime.

11. CHANNEL VOLUME

Controls the individual volume level of Mic Channels.

12. SOURCE VOLUME

Controls the volume level of the selected source.

13. TONE CONTROL

Adjust Bass or Treble to cut(decrease) or boost(increase) the frequency of 100Hz or10kHz.

14. MIC TONE CONTROL OF CH1 ~ CH6

Controls High (8kHz), MID (1kHz), or LOW (250Hz) tones. First, press ‘ENTER’ button to enter into EQ Mode, then select the tone of the channel you want, adjust the MIC Tone Control Volume and press ‘ENTER’ to save and exit the EQ Mode. Please refer to the ‘CHANNEL EQ SETUP’ section (page 14).
