Speco Technologies O2FD4M User Manual
O2FD4M
Flexible Intensifier® Technology
Indoor/Outdoor
Dome IP Camera
OO22FFDD44MM UUsseerr’’ss GGuuiiddee
Directions
Be careful not to cause any physical damage by dropping or throwing the camera. Especially keep the
device out of reach from children.
Do not disassemble the camera. No after service is assumed when disassembled.
Use only power adapters compatible with the unit.
Be careful to prevent moisture or water penetration into the unit. Particular attention is needed when
installing the unit. The screw holes for the installation screws and pipe should be maintained water tight
during the whole life time of the product.
All the electrical connection wires running into the unit should be prepared so that water from the outside
cannot flow into the unit through the surface of the wires. Penetration of the moisture through the wire for
extended period can cause malfunction of the unit or deteriorated image.
Note
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generate, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into and outlet on a circuit different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV technician for help.
Caution
Any changes or modifications in construction of this device which are not explicitly approved by the
party responsible for compliance could void the user’s warranty.
Rev.1.0 (Dec. 2015)
2
OO22FFDD44MM UUsseerr’’ss GGuuiiddee
Revision History
Date Revision Details
12/15/2015 1.0 Initial version
Rev.1.0 (Dec. 2015)
3
OO22FFDD44MM UUsseerr’’ss GGuuiiddee
Contents
1. Introduction .................................................................................................................................................... 5
1.1. Overview ............................................................................................................................................... 5
1.2. Specifications ........................................................................................................................................ 6
2. Product Description ...................................................................................................................................... 8
2.1. Contents ................................................................................................................................................ 8
2.2. Product Preview .................................................................................................................................... 8
2.3. Physical description .............................................................................................................................. 9
2.3.1. External View .............................................................................................................................. 9
2.3.2. Dimensions ................................................................................................................................. 9
2.3.3. External Connector ................................................................................................................... 10
2.3.4. Factory Default Switch .............................................................................................................. 10
2.4. Functional Description ........................................................................................................................ 11
3. On Site Installation ...................................................................................................................................... 13
4. Getting Started ............................................................................................................................................. 14
4.1. PC Requirement ................................................................................................................................. 14
4.2. Quick Installation Guide ...................................................................................................................... 15
4.2.1. Connect PC and O2FD4M to network. ..................................................................................... 15
4.2.2. Set IP parameters on O2FD4M ................................................................................................ 15
4.2.3. Remote video connection to O2FD4M ..................................................................................... 16
4.2.4. Additional settings through connection to the Admin Page ...................................................... 18
5. Troubleshooting ........................................................................................................................................... 19
5.1. No power is applied ............................................................................................................................ 19
5.2. Cannot connect to the Video ............................................................................................................... 20
5.3. Technical Assistance ........................................................................................................................... 21
Appendix A – Important Notice in Exchanging SD Card (Micro SD) ......................................................................... 22
Rev.1.0 (Dec. 2015)
4
OO22FFDD44MM UUsseerr’’ss GGuuiiddee
1. Introduction
1.1. Overview
The O2FD4M is a 1080p resolution, dual-codec (H.264, MJPEG) network camera. It enables real time
transmission of synchronized video. Remote clients can connect to the O2FD4M for real time video/audio
through PCs and smartphones. Real-time 2-way communication is available through the bidirectional audio
communication feature.
Flexible Intensifier® Technology is the most optimized solution to handle any lighting condition to fit the
installation environment. Intensifier® mode can be used to display a color image in low light. In extreme
darkness, adaptive, super IR LEDs can be used to illuminate the scene without IR saturation of the scene.
Lastly, when a monochrome image is desired without the assistance of IR LEDs, a clear image can be captured
with just a little bit of ambient light.
Designed to be a stand-alone streaming audio & video transmission device, O2FB3M can be applied to various
application area such as video security, remote video monitoring, distance education, video conference or
internet broadcasting system.
Rev.1.0 (Dec. 2015)
5
OO22FFDD44MM UUsseerr’’ss GGuuiiddee
1.2. Specifications
Camera
Image sensor Progressive scan 1/3 inch CMOS 2M pixels
Full resolution 1,920 x 1,080 pixels (Full HD)
Sync System Internal
Lens 2.8 ~ 11mm Motorized Focus & Zoom
Day & Night AUTO, DAY, NIGHT
Sensitivity Intensifier Max – 0.0005 Lux / IR LED on : 0.0 Lux
Back Light Compensation ON / OFF
White Balance ATW(2.000K ~ 10,000K) / MANUAL / PUSH
Exposure DC / ESC
WDR ON / OFF
3D-DNR 0 ~ 20
Intensifier AUTO ON (Max 128x) / OFF
Privacy Mask ON / OFF (10 Programmable Zones)
Motion Detection ON / OFF (4 Programmable Zones)
Digital Zoom 1x ~ 12x
Mirror H / V / Rotate
DEFOG ON / OFF
OSD BUILT IN
Heater Yes
IR range
50 ft (depending on scene reflection)
Video
Compression method Simultaneous Dual Codec (H.264 / MJPEG)
Resolution 1,920 x 1,080@30fps
Multi-Profile Streaming
Intelligent Bit-Rate Control VBR or CBR
PTZ Digital PTZ & Video crop
Image Setting Text overlay, Privacy mask, De-interlace filter
Motion detection Cell-based configuration
Audio
Mono Upstream 32Kbps G.726 ADPCM, 64Kbps 16bit µ-law PCM ~ MIC/Line-in
Mono Downstream 64Kbps 16bit µ-law PCM ~ Line-out
- 5 simultaneous video profiles
- Select the codec type, resolution and frame rates for each profile.
Rev.1.0 (Dec. 2015)
6
OO22FFDD44MM UUsseerr’’ss GGuuiiddee
Network
- IPv4, TCP, UDP, IGMP, ICMP, ARP, RARP, PPPoE, RTCP
Network Protocol
Dynamic IP Speco DDNS (free of charge)
Security
Streaming method
External Terminals
LAN 10/100BaseT LAN (auto MDIX)
Analog output 1 channel D1 CVBS output
Alarm input / output Alarm I/O (1 Sensor input & 1 Relay output)
Factory Reset Supported
Audio MIC/Line in, Line out
- RTP, RTSP, SDP, HTTP, SMTP, FTP, DHCP, UPnP
- NTP, DNS, DynDNS
- User ID & Password protection, IP address filtering
- Digest Authentication, User Access Log
- RTSP streaming with proprietary format for control information
- standard RTSP streaming
- HTTP streaming
Power DC 12V input
Alternate Power
Standard PoE IEEE802.3af
Alarm & Event
Intelligent Video Motion Detection
Alarm Triggers Motion Detection + Sensor Input
Alarm Events Video file upload(FTP), Still Image transmission(Email), Relay output
Alarm Buffer (Audio/Video) Configurable Pre-alarm (5~15 sec) & Post-alarm (10~60 sec)
Miscellaneous
Operating Temperature -4°F ~ 122°F
Operation Humidity 8 ~ 80% RH
Power DC 12V, 0.6A
Dimensions(H x Ø) 3.62 x 5.11”
Weight 2 lbs
Outdoor Rating IP66
Approvals FCC, RoHS
Package information Unit, CD, mounting screws, chameleon cover
Rev.1.0 (Dec. 2015)
7
