Speco VL644T Specsheet
2MP HD-TVI Indoor Dome Camera
VL644T
3.6mm fixed lens, black housing
Features
•Full HD resolution over coax
•Easy installation & adjustment
•Compact & lightweight 3 axis design
•Manual 360
•12VDC power supply required (power supply not included)
•5 year warranty
Camera Specifications
Image Sensor 1/2.7” 2MP CMOS Sensor
Resolution 1920x1080
Minimum Illumination 0.01 lux @ F=0.12
Electronic Shutter Auto
S/N Ratio >60dB
Backlight Compensation Auto
Synchronization Internal
Gamma 0.45 typ.
Video Signal Output 1.0Vp-p / 75 ohms
Operating Temperature/
Humidity
Storage Temperature -4F - 140F
Power Consumption 90mA
Power Supply 12VDC (power supply not included)
Dimensions 4.7” (H) x 3.5” (Dia.)
Weight 10.5 oz.
rotation & pan/tilt mechanism
14F - 122F / less than 80% RH
A
R
E
Y
W
Y
A
T
R
N
R
A
Optional Accessories
PSW5
12VDC
Power Supply
