Speco SP-5MA-T, SP5MATB, SP6MAT, SP6MATB Specsheet

MA Series 5.25” or 6.5” 70/25V Commercial ABS Plastic Back Can Speakers

SP5MAT 5.25” speaker, off-white housing SP6MAT 6.5” speaker, off-white housing SP5MATB 5.25” speaker, black housing SP6MATB 6.5” speaker, black housing

Off-White

Features

• ABS ame retardant back can

• Easy select transformer dial

• 25V or 70V selector switch

• Safety loop for additional mounting security

• Ported bass

Black

Specications SP5MAT/SP5MATB SP6MAT/SP6MATB

RMS Power .................................. 30W 40W

Max. Power................................... 60W 80W

Transformer Type ......................... 70/25V (selectable) 70/25V (selectable)

Transformer Power Taps .............. 30W, 15W, 7.5W, 2.5W 40W, 30W, 15W, 7.5W, 5W, 2.5W

1W, 0.5W, 0.25W, & 8 Ohms 1W, 0.5W, 0.25W & 8 Ohms

Termination Type .......................... Press terminal

Sensitivity (1W/1M) ....................... 87dB 88dB

Maximum SPL (Pmax/1M) ............ 91.4dB 92.3dB

Driver Impedance ......................... 8 Ohms 8 Ohms

Magnet.......................................... 10 oz. ferrite 10 oz. ferrite

Frequency Response Range ........ 57Hz ~ 20 kHz 34Hz ~20kHz

Dispersion @ 1000Hz .................. 120º Conical 120º Conical

Drivers .......................................... 5.25” Polypropylene woofer 6.55” Polypropylene

1” Mylar tweeter 1” Mylar tweeter

Speaker Dimensions .................... 9.43” (Dia.) x 6.12” (D) 11.02” (Dia.) x 7.58” (D)

Mounting Dimensions ................... 8.38” (Dia.) 9.88” (Dia.)

Weight .......................................... 4.5 lbs. 5.5 lbs.

Material ......................................... Bafe: Fire-resistant ABS Bafe: Fire-resistant ABS

Backcan: Fire-resistant ABS Backcan: Fire-resistant ABS

Grille: Metal Grille: Metal

Color ............................................. Off-White or Black Off-White or Black

Sold

individually

Grilles included

for both models ›

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specications without notice and without incurring any obligation. Spec Rev. 2/5/15

800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com

Optional Accessories

BRC6F

Mounting Bracket

(use with SP5MAT)

BRC8F

Mounting Bracket

(use with SP6MAT)

MA Series 5.25” 70/25V Commercial ABS Plastic Back Can Speakers

Architect & Engineer Specications / SP5MAT / SP5MATB

The loudspeaker system shall be Speco Technologies SP5MAT. System shall include a high performance 5.25” coaxial

loudspeaker, ported bass reex enclosure and press-t grille for conventional ceiling installation.

The total frequency response for the system shall be 57 Hz – 20 kHz.

Sensitivity shall be 87dB average.

Loudspeaker shall be comprised of a 5.25” coaxial cone type driver. Cone shall be constructed of polypropylene with

a rubber surround. The 1” tweeter shall be constructed of Mylar. Magnet shall be Ferrite and a minimum of 10 oz.

Transformer shall be a 70.7V / 25V type with .25, .5, 1.0, 2.5, 5.0, 7.5, 15.0, and 30.0 watt primary taps (@70.7V) with

a front mounted tap selector switch to include transformer bypass setting for 8Ω direct coupled operation.

Enclosure shall be a ame-retardant ABS Plastic enclosure design.

External wiring shall be accomplished via press-terminals to provide both secure wire termination and fast installation

of wires.

Seismic support eye shall be provided on side of enclosure for additional suspension point when used in drop

tile ceilings.

The mounting system shall be Speco Technologies BRC6F and include a support backing plate to reinforce the ceiling

material and tile support rails for use on either 2’ x 4’ or 2’ x 2’ suspended ceiling tiles. This assembly can all be installed

from beneath the ceiling tile.

Overall front face diameter shall not exceed 9.43”; overall depth from the bottom of the ceiling shall not exceed 6.12”.

Grilles shall be press-t, manufactured from 24-gauge perforated steel mesh and nished in white epoxy. Round grill

shall be 8.05” diameter.

The loudspeaker shall be off-white and shall be the Speco Technologies SP5MAT.

The loudspeaker shall be black and shall be the Speco Technologies SP5MATB.

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specications without notice and without incurring any obligation. Spec Rev. 2/5/15

800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com

SP5MAT / SP5MATB Product Dimensions

red terminal

black terminal

6.12”

0.65”

70V

25V

speco technologies

8.05”

0.25

0.5

7.5

1.0

5.0

2.5

9.43”

0.44”

0.79”

7.26”

7.48”

0.28”

Ratio vs Angle

dBR

-5

120

-10

-15

-20

-25

150

-30

-35

-40

-45

-180

180

-50

-45

-40

-35

-30

-25

-150

-20

-15

-10

-5

-120

Curve Freq BW Q DI

441.94 305 1.2 0.7

625.00 225 1.6 2.0

883.88 360 1.0 0.0

1.25K 116 3.1 4.9

1.77K 113 3.2 5.0

2.50K 156 2.3 3.6

3.54K 95 3.8 5.8

5.00K 65 5.5 7.4

7.07K 65 5.5 7.4

0 Deg

10.00K 105 3.4 5.3

14.14K 69 5.2 7.2

20.00K 40 9.0 9.5

28.28K 40 9.0 9.5

40.00K 40 9.0 9.5

-30

-60

-90

38: PolarConv F= 441.9417 39: PolarConv F= 625.0000 40: PolarConv F= 883.8835

41: PolarConv F= 1.2500K 42: PolarConv F= 1.7678K 43: PolarConv F= 2.5000K

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specications without notice and without incurring any obligation. Spec Rev. 2/5/15

800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com

44: PolarConv F= 3.5355K 45: PolarConv F= 5.0000K 46: PolarConv F= 7.0711K

47: PolarConv F= 10.0000K 48: PolarConv F= 14.1421K 49: PolarConv F= 20.0000K

50: PolarConv F= 28.2843K 51: PolarConv F= 40.0000K
