Speco PBM30 User Manual

INSTRUCTION

PUBLIC ADDRESS AMPLIFIER

MANUAL

PBM-15 PBM-30

RISK OF ELECTRIC SHOCK, DO NOT OPEN!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT OPEN COVER. NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

PRECAUTIONS

1.Unpacking

15 WATT RMS

30 WATT RMS

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE UNITS NOT SPECIFICALLY DESIGNED FOR OUTDOOR USE TO RAIN OR MOISTURE.

WARNING: REMOVAL OF THE COVER SHOULD ONLY BE PERFORMED BY QUALIFIED SERVICE PERSONNEL - NOT USER SERVICEABLE. THE UNIT SHOULD ALWAYS BE UNPLUGGED BEFORE REMOVING THE COVER, AND REMAIN UNPLUGGED WHILE THE COVER IS REMOVED.

After removing the amplifier from the carton, inspect for any exterior damage to the unit. If damage is noted, notify the carrier at once so that a claim can be

justified. Save all packing material. This is important when the claim is

processed.

2.Ventilation

To offset heat generated by the unit, it is necessary to provide ample ventilation around the unit. Avoid blocking or impeding the ventilation holes on the unit. To

prevent unnecessary problems, install the unit on a place free from any

vibrations, direct sunlight, humidity or dust circulation.

3.Avoid spilling liquids or allowing materials to enter the

If the unit gets wet or any foreign material enters the cabinet, immediately

disconnect the A.C. line cord and consult your dealer or qualified technician.

200 NEW HIGHWAY, AMITYVILLE, NY11701 PHONE : 1-800-645-5516, 631-957-8700 IN METRO NY

http://www.specotech.com

cabinet

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider that the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where the exit from the apparatus.

11. Only use the attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

16. Warning – To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

17. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

18. Caution – Use of any controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

Controls and Connections

FRONT PANEL

1 2 3 4 5

REAR PANEL

1 2

FRONT PANEL

1) MIC-1 Volume control 4) TREBLE Control

3 4

11 10

9 8 7

2) MIC-2/AUX Volume control 5) POWER on/off switch with indicator

3) BASS Control

REAR PANEL

1) AC accessory outlet (Unswitched) 8) MIC-1 input terminals(Balanced)

2) AC fuse holder 9) MIC-2 input terminals(Balanced)

3) MOH output level control* 10) Manual muting terminals

4) MIC-2/AUX input selector switch 11) MOH output terminals*

5) AUX input RCA jacks 12) Speaker outputs

6) TEL/PAGING output level control** 13) Ground

7) TEL/PAGING input terminals(Balanced)** 14) AC power cord

*MOH = Music on hold

**TEL/PAGING= Connection input terminals for

general or emergency paging.

**TEL/PAGING is not to be connected directly to a

telephone circuit or TNV circuit.
