Speco N8WNU3TB, N8WNU16TB, N8WNUM8TB, N8WNUM6TB, N8WNUM4TB Specsheet
...
4K Plug & Play Network Wall Mount Video
Recorder with Built-In PoE
N8WNU
8 Channel NVR with 8 Built-In PoE+ Ports
N16WNU
16 Channel NVR with 16 Built-In PoE+ Ports
N8WNUM
8 Channel NVR with 8 Built-In PoE+ Ports with Built-In Monitor
N16WNUM
16 Channel NVR with 16 Built-In PoE+ Ports with Built-In Monitor
STORAGE
2
TB - 40TB
Key Features Additional Features
A
R
E
Y
W
Y
A
T
R
N
R
A
EZ Wizards - For ease of use and setup
Camera: quickly discover and install all Speco IP cameras
Setup: for quick setup of general settings
Network: network setup and port forwarding
Record: quickly setup recording resolutions and recording type
Search: quickly search for events from thumbnails
Copy: quickly copy what you are playing onto a USB flash drive
•Supports up to 4K (3840x2160) resolution for live view,
recording, and playback
•Video out: 1 HDMI, 1 VGA, 1 Main, Spot
•Plug & play feature for Speco IP cameras with isolated traffic
on the PoE ports
•Find and install IP cameras on the local network without needing
•Remote monitoring / recording / playback / configuration / software upgrades
and PTZ control via internet
•Mass alert notification via Twitter
•HTTPS - support for third party SSL certificates
•Switch between low and high quality stream during simultaneous continuous + motion +
sensor recording modes for storage optimization
•Easy firmware upgrade by USB port or network
•Network software supports Static IP, DHCP and DDNS
•Network accessible via SpecoTech Multi-Client Software, SecureGuard® VMS, Internet
Explorer Web-Viewer and Speco Player Mobile Viewer
•PC and MAC® compatible
•IR remote control & mouse included
•5 year limited warranty
•UL Listed
to locate the cameras manually
•Supports H.265 and H.264 streams
•Programmable recording on motion detection, sensor, schedule,
continuous and manual modes
• Smart (Museum) Search – Quickly search for a specific video event
without the need for motion setup
•Networkable with free US-Based Speco DDNS service
•Up to 40TB storage from 4 internal SATA ports
•RAID 1/5/10 support, RAID maximum capacity 16TB
•eSATA port for additional storage
•External DAS supported, up to 40TB
•2-way audio communication
•Digital Deterrent® for triggering audio message via an event
•Built-in S.M.A.R.T technology (Self-Monitoring, Analysis and Reporting Technology for HDD)
1
For supported IP camera models. 2Limited Warranty/Hard drives excluded. Check www.specotech.com for more details. iPhone is a trademark of Apple Inc., registered in the U.S. and other countries. Android
is a trademark of Google Inc.The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries. Speco Technologies is constantly developing and improving products.We reserve the right to modify product design and specifications without notice and without incurring any obligation. Spec Rev.
5/24/19
800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com
Technical Specications:
WNU 4K Plug & Play Network Wall Mount Video Recorder with Built-In PoE
Model NU
Input
Video
Output
Audio
Alarm Input/Output 4/1
Serial RS-485 1
Max Bitrate per Channel 4K @ 8Mbps
Recording
Playback
Backup
Storage
User I/F Input Method IR Remote Controller, Mouse, Keyboard Controller (Option)
Network
Features
Network
Access
Power Power Supply Voltage 100~240V AC
Temperature
Humidity Operation 20% ~ 80% (Non-condensing)
Weight Unit Weight (Gross Weight) 9.0 lbs (13.6 lbs) 4.1Kgs (6.2Kgs)
Dimensions Unit Dimensions (W x H x D) 16” (W) x 19” (H) x 3.5” (D)
Other Country of Origin Korea
Please note that specifications and unit exterior design are subject to change without notification. Rev. 5/24/19
Max Frame Rate per Channel Any Resolution @ 30fps
HDD
USB
Sub-stream for Network Max. 640x360 @ 30fps / Channel
DLS (Day Light Saving) Yes
NTP (Network Time Protocol) Once, Time, and Periodic
System Event Notification Health, Restart, Shutdown, Panic, Alarm, Motion, HDD, Fan
Remote Setup and Upgrade Simple Web Setup and Upgrade
Max. IP Channels 8 16
Camera H.265/H.264 Auto Detection (Max. 4K)
Main Monitor HDMI (Max. 4K) and VGA (Max. Full HD)
Sub Monitor CVBS or SPOT (Selectable)
Input/Output 8/1 16/1
Audio Codec G.711
2-Way Audio Local Audio - Network Client, Local Audio - IP Camera
Compression H.265/H.264 (Auto Detection)
Recording Mode Continuous / Motion / Sensor / Schedule / Manual
Pre-Recording Max. 20 seconds
Post Recording Max. 60 seconds
Search Quick, Date/Time, Archive, Log
Multi-Decoding 1, 4, 8 1, 4, 9, 16
Playback Speed x0.25, x0.5, x2, x4, x8, x16, x32, & x64
Media USB flash drive, External HDD, Network
Format BMP, AVI, EXE (Player + Data), NSF (Proprietary Format)
Huge Backup Yes (Max. 24 hours)
Capacity of 1 HDD Up to 10TB
Internal HDDs 4
RAID RAID 1/5/10, RAID Maximum Capacity 16TB
e-SATA 1
Extension External DAS (Max. 40TB, RAID)
Front 2
Rear 1
Network Interface 1Gbps + 8 PoE 1Gbps + 16 PoE
Dynamic DNS Yes (Free Speco US-based DDNS)
Digital Zoom Free Size on Live & Playback mode
S.M.A.R.T. Temperature, Power on Time, Bad Sector and Health
Multi-Language Support
3G/4G Mobile iPad / iPhone / Android
Web Viewer Windows (IE Ver.11)
PC Client SecureGuard® VMS and SpecoTech Multi Client (Live Search, Backup, PTZ, Remote Setup)
Operation 41oF ~ 104oF (5oC ~ 40oC)
Storage 14oF ~ 122oF (-10oC ~ 50oC)
800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com
