Page 1
CPTZ28D5W
22X Indoor PTZ
Please read this manual thoroughly before use and keep it handy for future reference.
Page 2
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO
NOT INSERT ANY METALLIC OBJECTS THROUGH THE
VENTILATION GRILLS OR OTHER OPENINGS ON THE
EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
II
Page 3
FCC COMPLIANCE STATEMENT
FCC INFORMATION: This equipment has been tested and found
to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
CAUTION: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority
to operate the equipment.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be
required to take adequate measures.
CE COMPLIANCE STATEMENT
III
Page 4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been moisture, does not
operate normally, or has been dropped.
15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE
BY QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE
RISK OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING
OTHER THAN THAT CONTAINED IN THE OPERATING
INSTRUCTIONS UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or
Certified/Listed Class 2 power source only.
IV
Page 5
Table of Contents
Chapter 1 — Introduction........................................................................................................... 1
1.1 Features ............................................................................................................................................. 1
Chapter 2 — Installation and Configuration ......................................................................... 2
2.1 Package Contents............................................................................................................................ 2
2.2 Installation ......................................................................................................................................... 3
2.3 Basic Configuration of Dome Camera System ........................................................................ 5
2.4 Setting Dome Camera Termination ............................................................................................. 6
2.5 Setting Dome Camera Address (ID) ............................................................................................ 6
2.6 Setting Dome Camera Protocol ................................................................................................. 13
2.7 Connections .................................................................................................................................... 14
2.8 Getting Started ............................................................................................................................... 15
Chapter 3 — Program and Operation ................................................................................... 16
3.1 Dome Camera Selection .............................................................................................................. 16
3.2 Accessing the On-Screen Menu Utility .................................................................................... 16
3.3 How to control the On-Screen Menu Utility ............................................................................ 16
3.4 Auto Scan (Shortcut: SCAN) ...................................................................................................... 17
3.5 Preset (Shortcut: PRST) .............................................................................................................. 19
3.6 Shortcut of Preset Program ........................................................................................................ 21
3.7 Tour (Shortcut: TOUR) ................................................................................................................. 21
3.8 Pattern (Shortcut: PTRN) ............................................................................................................. 23
3.9 Alarm ................................................................................................................................................. 24
3.10 Area Title ........................................................................................................................................ 25
3.11 Privacy Zone ................................................................................................................................. 26
3.10 Camera Menu ................................................................................................................................ 27
3.11 Dome Setup ................................................................................................................................... 29
3.14 Function Run ................................................................................................................................ 35
3.15 Factory Setup ............................................................................................................................... 36
Appendix A — Specifications ................................................................................................. 37
Appendix B — Troubleshooting............................................................................................. 40
Appendix C — Short Cut Key ................................................................................................. 41
V
Page 6
Chapter 1 — Introduction
1.1 Features
The dome camera and the keyboard controller make up the building blocks for any
surveillance/security system. Using multiple keyboard controllers and multiple dome cameras, no
place is too large for monitoring. Extensible and flexible architecture facilitates remote control
functions for a variety of external switching devices such as multiplexers and DVRs.
Built-in optical power zoom camera with True Night Shot function
240 Preset positions with the individual Camera AE setup
8 Tours consist of Presets, Patterns, Auto Scans and other Tours can be programmed with
over 300 functions and preset locations. While moving, each Preset scan can be watched in
smooth Vector Scan mode.
16 Auto Scans with the normal, the vector, and the random mode and the endless Auto-Pan
with 13 speed steps
8 Patterns (up to 200 second) and 8 Privacy Zones
16 Area Titles
2 Alarm inputs / 1 Alarm output (5VTTL)
Variable speed from 0.1 /sec to 380 /sec
Three Variable speed (SLOW, NORMAL, TURBO)
Turbo speed is 380 /sec with Ctrl key pressed.
Pan/Tilt speed is inversely proportional to the zoom ratio with the option.
Maximum speed is 380 /sec when Preset command.
Auto Calibration from 0.1 to 6 (Tilt range is 0 to 90 )
Programmable user preferences (alarm, preset, title, etc.)
90 Auto Flip
Up to 255 selectable camera addresses
Multi-language Menu Display, Password Confirmation
Function Run menu using DVR without function key (Pattern, Scan, …)
Built-in RS-485/422 receiver driver
12VDC for Dome
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source only.
1
Page 7
Chapter 2 — Installation and Configuration
2.1 Package Contents
The dome camera is designed with a compact, small size, flush/surface dome camera housing.
The housing is constructed of aluminum, steel and plastic. The housing is designed to be
mounted on a wall or a ceiling.
* Dome Camera 1
* Instruction Manual (This Document) 1
* Template sheet 1
* Accessory kit 1
1) Plastic anchors (4)
2) Screws (Tapping, 6x35) (4)
3) O-Rings (4)
4) Safety lanyard (1)
5) Screw (Machine, NPC 2.6x6) (1)
6) Screw (Machine, PC 2.6x6) (1)
7) Screws (Machine, PC 4x8) (3)
8) PT Plug (1)
* Accessory connector 1
1) 8-Pin Terminal Block + BNC Cable (1)
2) 4-Pin Terminal Block (1)
2
Page 8
2.2 Installation
The mounting surface must be capable of supporting the weight of the dome camera,
2.4 lb (1.1 kg).
(1) Flush Type
1) Make screw holes for camera on the ceiling with Template Sheet.
2) Disassemble the camera into its 3 parts: Surface Case, Camera Set and Top Case.
3) Secure the Camera Set to the ceiling using Anchors (3x) and Screws (3x).
4) Assemble the Top Case to the Camera Set. Turn the Top case counter-clockwise to
complete installation.
3
Page 9
(2) Surface Type
1) Make screw holes for camera on the ceiling with Template Sheet.
2) Disassemble the camera into its 3 parts: Surface Case, Camera Set and Top Case.
3) Secure the Surface Case to the ceiling using Anchor (4x) and Screws (4x).
4) Assemble the Camera Set into the Surface Case with Screws and Safety Lanyard.
5) Assemble the Top Case to the Camera Set. Turn the Top case counter-clockwise to
complete installation.
4
Page 10
2.3 Basic Configuration of Dome Camera System
Figure 1 – Basic Installation Diagram
The dome camera must be installed by qualified service personnel in accordance with all local
and federal electrical and building codes.
5
Page 11
S2
D1
D2
Terminated
ON
ON
Not terminated
OFF
OFF
Figure 2 – Layout of DIP Switches
2.4 Setting Dome Camera Termination
The device which is connected at end of line, whether it is a dome camera or keyboard controller,
must have the cable for communication terminated by setting the appropriate DIP switch.
Without proper termination, there is potential for control signal errors. Total length of the cable for
communication should not exceed 4000ft (1.2km).
S2
Figure 3 – Setting Dome Camera Termination
2.5 Setting Dome Camera Address (ID)
To prevent damage, each dome camera must have a unique address (ID).
When installing multiple dome cameras using a multiplexer, it is suggested that the dome camera
address match the multiplexer port number.
The factory default setting is 1.
Refer to Figure 4.1 ~ 4.6 for setting the dome camera address (ID).
6
Page 12
DOME ID
D1
(1)
D2
(2)
D3
(4)
D4
(8)
D5
(16)
D6
(32)
D7
(64)
D8
(128)
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
9
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
10
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
11
ON
ON
OFF
ON
OFF
OFF
OFF
OFF
12
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
13
ON
OFF
ON
ON
OFF
OFF
OFF
OFF
14
OFF
ON
ON
ON
OFF
OFF
OFF
OFF
15
ON
ON
ON
ON
OFF
OFF
OFF
OFF
16
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
17
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
18
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
19
ON
ON
OFF
OFF
ON
OFF
OFF
OFF
20
OFF
OFF
ON
OFF
ON
OFF
OFF
OFF
21
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
22
OFF
ON
ON
OFF
ON
OFF
OFF
OFF
23
ON
ON
ON
OFF
ON
OFF
OFF
OFF
24
OFF
OFF
OFF
ON
ON
OFF
OFF
OFF
25
ON
OFF
OFF
ON
ON
OFF
OFF
OFF
26
OFF
ON
OFF
ON
ON
OFF
OFF
OFF
27
ON
ON
OFF
ON
ON
OFF
OFF
OFF
28
OFF
OFF
ON
ON
ON
OFF
OFF
OFF
29
ON
OFF
ON
ON
ON
OFF
OFF
OFF
30
OFF
ON
ON
ON
ON
OFF
OFF
OFF
31
ON
ON
ON
ON
ON
OFF
OFF
OFF
32
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
33
ON
OFF
OFF
OFF
OFF
ON
OFF
OFF
34
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
35
ON
ON
OFF
OFF
OFF
ON
OFF
OFF
Example: Port 1 = Dome 1, Port 2 = Dome 2 … Port 16 = Dome 16. If more than 16 dome
cameras are installed using two or more multiplexers, ID of the dome camera should be ID of
MUX x No. of camera IN. (e.g. multiplexer ID= n, Camera IN= m then ID of Dome =16x(n-1)+m )
S1
Figure 4.1 – Setting Dome Camera Address (ID)
7
Page 13
DOME ID
D1
(1)
D2
(2)
D3
(4)
D4
(8)
D5
(16)
D6
(32)
D7
(64)
D8
(128)
36
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
37
ON
OFF
ON
OFF
OFF
ON
OFF
OFF
38
OFF
ON
ON
OFF
OFF
ON
OFF
OFF
39
ON
ON
ON
OFF
OFF
ON
OFF
OFF
40
OFF
OFF
OFF
ON
OFF
ON
OFF
OFF
41
ON
OFF
OFF
ON
OFF
ON
OFF
OFF
42
OFF
ON
OFF
ON
OFF
ON
OFF
OFF
43
ON
ON
OFF
ON
OFF
ON
OFF
OFF
44
OFF
OFF
ON
ON
OFF
ON
OFF
OFF
45
ON
OFF
ON
ON
OFF
ON
OFF
OFF
46
OFF
ON
ON
ON
OFF
ON
OFF
OFF
47
ON
ON
ON
ON
OFF
ON
OFF
OFF
48
OFF
OFF
OFF
OFF
ON
ON
OFF
OFF
49
ON
OFF
OFF
OFF
ON
ON
OFF
OFF
50
OFF
ON
OFF
OFF
ON
ON
OFF
OFF
51
ON
ON
OFF
OFF
ON
ON
OFF
OFF
52
OFF
OFF
ON
OFF
ON
ON
OFF
OFF
53
ON
OFF
ON
OFF
ON
ON
OFF
OFF
54
OFF
ON
ON
OFF
ON
ON
OFF
OFF
55
ON
ON
ON
OFF
ON
ON
OFF
OFF
56
OFF
OFF
OFF
ON
ON
ON
OFF
OFF
57
ON
OFF
OFF
ON
ON
ON
OFF
OFF
58
OFF
ON
OFF
ON
ON
ON
OFF
OFF
59
ON
ON
OFF
ON
ON
ON
OFF
OFF
60
OFF
OFF
ON
ON
ON
ON
OFF
OFF
61
ON
OFF
ON
ON
ON
ON
OFF
OFF
62
OFF
ON
ON
ON
ON
ON
OFF
OFF
63
ON
ON
ON
ON
ON
ON
OFF
OFF
64
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
65
ON
OFF
OFF
OFF
OFF
OFF
ON
OFF
66
OFF
ON
OFF
OFF
OFF
OFF
ON
OFF
67
ON
ON
OFF
OFF
OFF
OFF
ON
OFF
68
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
69
ON
OFF
ON
OFF
OFF
OFF
ON
OFF
70
OFF
ON
ON
OFF
OFF
OFF
ON
OFF
71
ON
ON
ON
OFF
OFF
OFF
ON
OFF
72
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
73
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
74
OFF
ON
OFF
ON
OFF
OFF
ON
OFF
75
ON
ON
OFF
ON
OFF
OFF
ON
OFF
76
OFF
OFF
ON
ON
OFF
OFF
ON
OFF
77
ON
OFF
ON
ON
OFF
OFF
ON
OFF
78
OFF
ON
ON
ON
OFF
OFF
ON
OFF
79
ON
ON
ON
ON
OFF
OFF
ON
OFF
80
OFF
OFF
OFF
OFF
ON
OFF
ON
OFF
Figure 4.2 – Setting Dome Camera Address (ID)
8
Page 14
DOME ID
D1
(1)
D2
(2)
D3
(4)
D4
(8)
D5
(16)
D6
(32)
D7
(64)
D8
(128)
81
ON
OFF
OFF
OFF
ON
OFF
ON
OFF
82
OFF
ON
OFF
OFF
ON
OFF
ON
OFF
83
ON
ON
OFF
OFF
ON
OFF
ON
OFF
84
OFF
OFF
ON
OFF
ON
OFF
ON
OFF
85
ON
OFF
ON
OFF
ON
OFF
ON
OFF
86
OFF
ON
ON
OFF
ON
OFF
ON
OFF
87
ON
ON
ON
OFF
ON
OFF
ON
OFF
88
OFF
OFF
OFF
ON
ON
OFF
ON
OFF
89
ON
OFF
OFF
ON
ON
OFF
ON
OFF
90
OFF
ON
OFF
ON
ON
OFF
ON
OFF
91
ON
ON
OFF
ON
ON
OFF
ON
OFF
92
OFF
OFF
ON
ON
ON
OFF
ON
OFF
93
ON
OFF
ON
ON
ON
OFF
ON
OFF
94
OFF
ON
ON
ON
ON
OFF
ON
OFF
95
ON
ON
ON
ON
ON
OFF
ON
OFF
96
OFF
OFF
OFF
OFF
OFF
ON
ON
OFF
97
ON
OFF
OFF
OFF
OFF
ON
ON
OFF
98
OFF
ON
OFF
OFF
OFF
ON
ON
OFF
99
ON
ON
OFF
OFF
OFF
ON
ON
OFF
100
OFF
OFF
ON
OFF
OFF
ON
ON
OFF
101
ON
OFF
ON
OFF
OFF
ON
ON
OFF
102
OFF
ON
ON
OFF
OFF
ON
ON
OFF
103
ON
ON
ON
OFF
OFF
ON
ON
OFF
104
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
105
ON
OFF
OFF
ON
OFF
ON
ON
OFF
106
OFF
ON
OFF
ON
OFF
ON
ON
OFF
107
ON
ON
OFF
ON
OFF
ON
ON
OFF
108
OFF
OFF
ON
ON
OFF
ON
ON
OFF
109
ON
OFF
ON
ON
OFF
ON
ON
OFF
110
OFF
ON
ON
ON
OFF
ON
ON
OFF
111
ON
ON
ON
ON
OFF
ON
ON
OFF
112
OFF
OFF
OFF
OFF
ON
ON
ON
OFF
113
ON
OFF
OFF
OFF
ON
ON
ON
OFF
114
OFF
ON
OFF
OFF
ON
ON
ON
OFF
115
ON
ON
OFF
OFF
ON
ON
ON
OFF
116
OFF
OFF
ON
OFF
ON
ON
ON
OFF
117
ON
OFF
ON
OFF
ON
ON
ON
OFF
118
OFF
ON
ON
OFF
ON
ON
ON
OFF
119
ON
ON
ON
OFF
ON
ON
ON
OFF
120
OFF
OFF
OFF
ON
ON
ON
ON
OFF
121
ON
OFF
OFF
ON
ON
ON
ON
OFF
122
OFF
ON
OFF
ON
ON
ON
ON
OFF
123
ON
ON
OFF
ON
ON
ON
ON
OFF
124
OFF
OFF
ON
ON
ON
ON
ON
OFF
125
ON
OFF
ON
ON
ON
ON
ON
OFF
Figure 4.3 – Setting Dome Camera Address (ID)
9
Page 15
DOME ID
D1
(1)
D2
(2)
D3
(4)
D4
(8)
D5
(16)
D6
(32)
D7
(64)
D8
(128)
126
OFF
ON
ON
ON
ON
ON
ON
OFF
127
ON
ON
ON
ON
ON
ON
ON
OFF
128
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
129
ON
OFF
OFF
OFF
OFF
OFF
OFF
ON
130
OFF
ON
OFF
OFF
OFF
OFF
OFF
ON
131
ON
ON
OFF
OFF
OFF
OFF
OFF
ON
132
OFF
OFF
ON
OFF
OFF
OFF
OFF
ON
133
ON
OFF
ON
OFF
OFF
OFF
OFF
ON
134
OFF
ON
ON
OFF
OFF
OFF
OFF
ON
135
ON
ON
ON
OFF
OFF
OFF
OFF
ON
136
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
137
ON
OFF
OFF
ON
OFF
OFF
OFF
ON
138
OFF
ON
OFF
ON
OFF
OFF
OFF
ON
139
ON
ON
OFF
ON
OFF
OFF
OFF
ON
140
OFF
OFF
ON
ON
OFF
OFF
OFF
ON
141
ON
OFF
ON
ON
OFF
OFF
OFF
ON
142
OFF
ON
ON
ON
OFF
OFF
OFF
ON
143
ON
ON
ON
ON
OFF
OFF
OFF
ON
144
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
145
ON
OFF
OFF
OFF
ON
OFF
OFF
ON
146
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
147
ON
ON
OFF
OFF
ON
OFF
OFF
ON
148
OFF
OFF
ON
OFF
ON
OFF
OFF
ON
149
ON
OFF
ON
OFF
ON
OFF
OFF
ON
150
OFF
ON
ON
OFF
ON
OFF
OFF
ON
151
ON
ON
ON
OFF
ON
OFF
OFF
ON
152
OFF
OFF
OFF
ON
ON
OFF
OFF
ON
153
ON
OFF
OFF
ON
ON
OFF
OFF
ON
154
OFF
ON
OFF
ON
ON
OFF
OFF
ON
155
ON
ON
OFF
ON
ON
OFF
OFF
ON
156
OFF
OFF
ON
ON
ON
OFF
OFF
ON
157
ON
OFF
ON
ON
ON
OFF
OFF
ON
158
OFF
ON
ON
ON
ON
OFF
OFF
ON
159
ON
ON
ON
ON
ON
OFF
OFF
ON
160
OFF
OFF
OFF
OFF
OFF
ON
OFF
ON
161
ON
OFF
OFF
OFF
OFF
ON
OFF
ON
162
OFF
ON
OFF
OFF
OFF
ON
OFF
ON
163
ON
ON
OFF
OFF
OFF
ON
OFF
ON
164
OFF
OFF
ON
OFF
OFF
ON
OFF
ON
165
ON
OFF
ON
OFF
OFF
ON
OFF
ON
166
OFF
ON
ON
OFF
OFF
ON
OFF
ON
167
ON
ON
ON
OFF
OFF
ON
OFF
ON
168
OFF
OFF
OFF
ON
OFF
ON
OFF
ON
169
ON
OFF
OFF
ON
OFF
ON
OFF
ON
170
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Figure 4.4 – Setting Dome Camera Address (ID)
10
Page 16
DOME ID
D1
(1)
D2
(2)
D3
(4)
D4
(8)
D5
(16)
D6
(32)
D7
(64)
D8
(128)
171
ON
ON
OFF
ON
OFF
ON
OFF
ON
172
OFF
OFF
ON
ON
OFF
ON
OFF
ON
173
ON
OFF
ON
ON
OFF
ON
OFF
ON
174
OFF
ON
ON
ON
OFF
ON
OFF
ON
175
ON
ON
ON
ON
OFF
ON
OFF
ON
176
OFF
OFF
OFF
OFF
ON
ON
OFF
ON
177
ON
OFF
OFF
OFF
ON
ON
OFF
ON
178
OFF
ON
OFF
OFF
ON
ON
OFF
ON
179
ON
ON
OFF
OFF
ON
ON
OFF
ON
180
OFF
OFF
ON
OFF
ON
ON
OFF
ON
181
ON
OFF
ON
OFF
ON
ON
OFF
ON
182
OFF
ON
ON
OFF
ON
ON
OFF
ON
183
ON
ON
ON
OFF
ON
ON
OFF
ON
184
OFF
OFF
OFF
ON
ON
ON
OFF
ON
185
ON
OFF
OFF
ON
ON
ON
OFF
ON
186
OFF
ON
OFF
ON
ON
ON
OFF
ON
187
ON
ON
OFF
ON
ON
ON
OFF
ON
188
OFF
OFF
ON
ON
ON
ON
OFF
ON
189
ON
OFF
ON
ON
ON
ON
OFF
ON
190
OFF
ON
ON
ON
ON
ON
OFF
ON
191
ON
ON
ON
ON
ON
ON
OFF
ON
192
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
193
ON
OFF
OFF
OFF
OFF
OFF
ON
ON
194
OFF
ON
OFF
OFF
OFF
OFF
ON
ON
195
ON
ON
OFF
OFF
OFF
OFF
ON
ON
196
OFF
OFF
ON
OFF
OFF
OFF
ON
ON
197
ON
OFF
ON
OFF
OFF
OFF
ON
ON
198
OFF
ON
ON
OFF
OFF
OFF
ON
ON
199
ON
ON
ON
OFF
OFF
OFF
ON
ON
200
OFF
OFF
OFF
ON
OFF
OFF
ON
ON
201
ON
OFF
OFF
ON
OFF
OFF
ON
ON
202
OFF
ON
OFF
ON
OFF
OFF
ON
ON
203
ON
ON
OFF
ON
OFF
OFF
ON
ON
204
OFF
OFF
ON
ON
OFF
OFF
ON
ON
205
ON
OFF
ON
ON
OFF
OFF
ON
ON
206
OFF
ON
ON
ON
OFF
OFF
ON
ON
207
ON
ON
ON
ON
OFF
OFF
ON
ON
208
OFF
OFF
OFF
OFF
ON
OFF
ON
ON
209
ON
OFF
OFF
OFF
ON
OFF
ON
ON
210
OFF
ON
OFF
OFF
ON
OFF
ON
ON
211
ON
ON
OFF
OFF
ON
OFF
ON
ON
212
OFF
OFF
ON
OFF
ON
OFF
ON
ON
213
ON
OFF
ON
OFF
ON
OFF
ON
ON
214
OFF
ON
ON
OFF
ON
OFF
ON
ON
215
ON
ON
ON
OFF
ON
OFF
ON
ON
Figure 4.5 – Setting Dome Camera Address (ID)
11
Page 17
DOME ID
D1
(1)
D2
(2)
D3
(4)
D4
(8)
D5
(16)
D6
(32)
D7
(64)
D8
(128)
216
OFF
OFF
OFF
ON
ON
OFF
ON
ON
217
ON
OFF
OFF
ON
ON
OFF
ON
ON
218
OFF
ON
OFF
ON
ON
OFF
ON
ON
219
ON
ON
OFF
ON
ON
OFF
ON
ON
220
OFF
OFF
ON
ON
ON
OFF
ON
ON
221
ON
OFF
ON
ON
ON
OFF
ON
ON
222
OFF
ON
ON
ON
ON
OFF
ON
ON
223
ON
ON
ON
ON
ON
OFF
ON
ON
224
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
225
ON
OFF
OFF
OFF
OFF
ON
ON
ON
226
OFF
ON
OFF
OFF
OFF
ON
ON
ON
227
ON
ON
OFF
OFF
OFF
ON
ON
ON
228
OFF
OFF
ON
OFF
OFF
ON
ON
ON
229
ON
OFF
ON
OFF
OFF
ON
ON
ON
230
OFF
ON
ON
OFF
OFF
ON
ON
ON
231
ON
ON
ON
OFF
OFF
ON
ON
ON
232
OFF
OFF
OFF
ON
OFF
ON
ON
ON
233
ON
OFF
OFF
ON
OFF
ON
ON
ON
234
OFF
ON
OFF
ON
OFF
ON
ON
ON
235
ON
ON
OFF
ON
OFF
ON
ON
ON
236
OFF
OFF
ON
ON
OFF
ON
ON
ON
237
ON
OFF
ON
ON
OFF
ON
ON
ON
238
OFF
ON
ON
ON
OFF
ON
ON
ON
239
ON
ON
ON
ON
OFF
ON
ON
ON
240
OFF
OFF
OFF
OFF
ON
ON
ON
ON
241
ON
OFF
OFF
OFF
ON
ON
ON
ON
242
OFF
ON
OFF
OFF
ON
ON
ON
ON
243
ON
ON
OFF
OFF
ON
ON
ON
ON
244
OFF
OFF
ON
OFF
ON
ON
ON
ON
245
ON
OFF
ON
OFF
ON
ON
ON
ON
246
OFF
ON
ON
OFF
ON
ON
ON
ON
247
ON
ON
ON
OFF
ON
ON
ON
ON
248
OFF
OFF
OFF
ON
ON
ON
ON
ON
249
ON
OFF
OFF
ON
ON
ON
ON
ON
250
OFF
ON
OFF
ON
ON
ON
ON
ON
251
ON
ON
OFF
ON
ON
ON
ON
ON
252
OFF
OFF
ON
ON
ON
ON
ON
ON
253
ON
OFF
ON
ON
ON
ON
ON
ON
254
OFF
ON
ON
ON
ON
ON
ON
ON
255
ON
ON
ON
ON
ON
ON
ON
ON
Figure 4.6 – Setting Dome Camera Address (ID)
12
Page 18
2.6 Setting Dome Camera Protocol
S2
PROTOCOL
D4
D5
D6
OFF
OFF
OFF
F2, F2E, Pelco-P, Pelco-D : default
OFF
OFF
ON
F2, F2E
OFF
ON
OFF
Sensormatic
OFF
ON
ON
Pelco-P, Pelco-D
S2
BAUD RATE
D7
D8
OFF
OFF
2400 bps
OFF
ON
4800 bps
ON
OFF
9600 bps : default
ON
ON
19200 bps
S2-D3
RS-485/422
OFF
RS-485
ON
RS-422
If a dome camera is to be installed with the keyboard controller, select the default protocol.
Consult service personnel if a dome camera is installed with device other than a keyboard
controller.
S2
You can set RS-485/422 with DIP switch.
Select RS-485/422 with D3 in S2.
You can set Protocol with DIP switch D4, D5 and D6 in S2.
You can set Baud Rate with DIP switch D7 and D8 in S2.
Figure 5 – RS-485/422, Protocol, Baud rate Selection Switches
13
Page 19
2.7 Connections
• Connecting to the RS-485/422
The dome camera can be controlled remotely by an external device or control system,
such as a control keyboard, using RS-485 half-duplex, RS-422 full-duplex or simplex serial
communications signals. Connect marked TX+, TX- to TX+, TX- of the RS-485 control system.
If control system is RS-422, connect RX+, RX- and TX+, TX- of the dome camera to
RX+, RX- and TX+, TX- of the control device respectively.
• Connecting Video Output connector
Connect the video output (BNC) connector to the monitor or video input.
• Connecting Alarms
A1,A2 (Alarm Input 1,2)
You can use external devices to signal the dome camera to react on events. Mechanical or
electrical switches can be wired to the A1,A2 (Alarm Input 1,2) and G (Ground) connectors.
See Chapter 3 — Program and Operation for configuring alarm input.
G (Ground)
NOTE: All the connectors marked G or GND are common.
Connect the ground side of the alarm input and/or alarm output to the G (Ground) connector.
AO (5VTTL Alarm Output)
The dome camera can activate external devices such as buzzers or lights. Connect the device
to the AO (Alarm Output) and G (Ground) connectors.
See Chapter 3 — Program and Operation for configuring alarm output.
• Connecting the Power
Connect power of 12VDC 650mA for the dome camera.
When using a 12VDC adapter, connect the positive(+) pole to the ‘+’ position and
the negative(-) pole to the ‘-’ position.
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source only.
14
Page 20
2.8 Getting Started
(AREA TITLE) (AF AE)
(FUNC TITLE )
(CTRL KEY TO MOVE)
SAVE AND EXIT(ESC TO CANCEL)
(ALARM MESSAGE) (DOME ID…)
(ANGLE…)
ABC AF AE
001
EMPTY DATA
ALARM:1 DOMEID:001
W→360.0 090.0
INFORMATION
DISPLAY
ALARM DISPLAY
CAMERA TITLE
CAMERA ID
VIEW DIRECTION
PAN & TILT ANGLE
STATUS of
FOCUS and AE
AREA TITLE
FUNCTION TITLE
Once installed apply power to the dome camera. The dome camera will start a configuration
sequence.
OSD Position
The dome can move the OSD position in the OSD position setup.
OSD Position Setup
15
Page 21
Chapter 3 — Program and Operation
DOME MENU
AUTO SCAN
PRESET
TOUR
PATTERN
ALARM
AREA TITLE
PRIVACY ZONE
CAMERA
DOME SETUP
FUNCTION RUN
EXIT(ESC TO EXIT)
Function
Button
Call the On-screen menu utility.
MENU
Navigate through the menu items.
Joystick up or down
Go into the sub-menu items.
Joystick left or right or IRIS Open
Change value.
Enter the editing title mode.
Joystick left or right or
Zoom handle twist or Tele , Wide
Change value of angle.
CTRL + Joystick
Enter the changing angle mode.
IRIS Open
Exit the changing angle mode.
IRIS Close
Escape (EXIT)
ESC
3.1 Dome Camera Selection
Before you program or operate a dome camera, you must select the dome camera by pressing
No. + CAM keys.
Example: Pressing 1 , 0 + CAM keys sequentially will select dome camera 10. The selected
dome camera ID will be displayed on the LCD monitor of the keyboard controller.
3.2 Accessing the On-Screen Menu Utility
You can call up the On-screen menu utility on your monitor by pressing the MENU key on the
keyboard controller, the following On-screen menu utility will appear:
3.3 How to control the On-Screen Menu Utility
16
Page 22
3.4 Auto Scan (Shortcut: SCAN)
AUTO SCAN SETUP
NUMBER : 01
TITLE : A01
MODE : NORMAL
SPEED : 5 STEP
START ANGLE : ----- ----END ANGLE : ----- ----SCAN DIR : CCW
SWAP : OFF
DWELL : 03 SEC
SAVE AND EXIT(ESC TO CANCEL)
TITLE EDIT MENU
A01
*
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z 0 1 2 3
4 5 6 7 8 9 ( )
ALL DELETE
EXIT(ESC TO EXIT)
The Auto Scan supports up to 17 programmed angles at user-programmable speeds.
Follow these steps to program Auto Scan:
NUMBER : 01 ~ 08, 10 ~ 17, 09: AUTO-PAN mode
TITLE : up to 12 characters.
MODE : NORMAL, VECTOR, RANDOM (AUTO-PAN mode: NORMAL, RANDOM only).
NORMAL : Move from start point to end point in panning only.
VECTOR : Move from start point to end point including tilt and zoom simultaneously and
linearly.
RANDOM : Move randomly between the start point and the end point.
SPEED : 1 ~ 13 step, the lower number means the slower speed.
SCAN DIR : Set the Scan direction, CCW(Counter Clock Wise), CW(Clock Wise).
SWAP : Swap the start point for the end point.
DWELL : Set the dwell time at the both end, 01 ~ 99 seconds.
1. Press the SCAN key to enter the Auto Scan menu directly. Or press the MENU key to display
the main menu on the monitor. Scroll to Auto Scan and push the Joystick to the right.
2. Select “NUMBER” and set the desired number by pushing the Joystick to the left or right.
3. Select “TITLE” and twist the Joystick to enter the title edit mode.
4. Twist the Joystick to change the alphanumeric characters and move the next position by
pushing the Joystick to the left or right. Or move down to the character table and press the
CTRL or IRIS Open key at the desired character then the cursor position moves to the next
position automatically. Push the Joystick to the left or right at the “ALL DELETE” field to
delete all characters. Push the Joystick to the left or right at the “EXIT” field to finish title edit
menu.
5. Select “MODE” and “SPEED”.
17
Page 23
6. Select “START ANGLE”. Hold down the CTRL key while selecting the start position using the
AUTO SCAN AREA SETUP
(CTRL KEY)
NUMBER01
START : ----- ----END : ----- ----EXIT(ESC TO EXIT)
Joystick. Current panning position will be displayed. Release the CTRL key to complete the
selection of the start position. Or press the IRIS Open key then the “CTRL” displays. Move the
desired position and the zoom position. Press the IRIS Close key then the “CTRL” disappears.
To adjust at the 0.1 degree interval, twist the Joystick at the pan field and the tilt field. To
adjust at the one zoom interval, twist the Joystick at the zoom field.
7. Select “END ANGLE”. Hold down the CTRL key while moving the Joystick to select the end
position. The end position angle should be larger than start position. Release the CTRL key to
complete the selection of the end position. Or press the IRIS Open key then the “CTRL”
displays. Move the desired position and the zoom position. Press the IRIS Close key then the
“CTRL” disappears. To adjust at the 0.1 degree interval, twist the Joystick at the pan field and
the tilt field. To adjust at the one zoom interval, twist the Joystick at the zoom field.
8. Set “SCAN DIR” to CCW or CW.
9. Select “SWAP”, Set to ON to exchange the start angle and the end angle.
10. Set “DWELL TIME”.
11. Select “SAVE AND EXIT” and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
NOTE: Pressing the HOME key delete stored data at the angle field.
To set the position using the Preset position:
a. Before entering the Auto Scan menu, select a Preset position as a starting point for Auto Scan.
Example: 2 + PRST keys and do step 1 to 5. In step 6, just press the Ctrl key at the start angle
position, the current position will be displayed as a start position.
b. Save and Exit from the menu.
c. In normal mode, call a Preset to be the end point of Scan. Press 3 + PRST keys then press
the SCAN key to enter the Auto Scan menu. Move the cursor position to END ANGLE. Just
press the CTRL key at the end angle position. Save and exit from the menu.
Press the SCAN key on the angle field to display with the small OSD. Then the screen will show
as below.
The setting procedure is the same as above.
NOTE: 09: AUTO-PAN mode (endless panning)
18
Page 24
3.5 Preset (Shortcut: PRST)
PRESET SETUP
NUMBER : 001
TITLE : --CAMERA SET
DWELL : -- SEC
12345678901234567890
00 █**----------------02 -------------------04 --------------------
06 -------------------NEXT PAGE
SAVE AND EXIT(ESC TO CANCEL)
PRESET CAMERA SETUP
FOCUS : AUTO
MOTION : OFF
MOTION SETUP
AE SETUP
SAVE AND EXIT(ESC TO CANCEL)
If you need to view specific places routinely, you should program Presets. A Preset is a
programmed video scene with automatic pan, tilt, zoom, focus, motion and AE settings. Once
programmed, placing the number position and pressing the PRST key on your controller calls up
that Preset automatically. In addition, Presets may be assigned to alarm action or as the “home”
position for the dome camera. As many as 240 Presets, whose positions are saved in the dome’s
firmware, may be programmed.
There are three pages of Preset menu. Each page has 80 Presets. Pages can be scrolled by
pushing the Joystick to the left or right on the first or last No. of Preset.
- : blank Preset position
* : position has the Preset
█ : current cursor position
Follow steps below to store the Preset positions:
1. Press the PRST key to enter the Preset menu directly. Or press the MENU key to display the
main menu on the monitor. Scroll to Preset and push the Joystick to the right.
2. Select the blank Preset position to be stored by pushing the Joystick up, down, right, or left.
3. After selecting a blank position, press and hold the CTRL key. Use the Joystick to control the
direction of the camera and lens.
4. After aiming the camera (view direction and lens control), release the CTRL key. The cursor
will be on the “TITLE” after saving data then twist the Joystick or press the Tele or Wide key
to edit the Preset title. Follow the procedure of the Auto Scan above to edit titles.
5. Select “CAMERA SET” and push the Joystick to the left or right. Then the Preset camera
setup displays.
Set FOCUS : AUTO, MANUAL, ONE PUSH
Set MOTION : OFF, ON
19
Page 25
Select “MOTION SETUP” and pushing the Joystick to the left or right. Then the MOTION
MOTION SETUP
SENSITIVITY : 06
POSITION : ALL
DELAY : 00 SEC
OUTPUT : OFF
HOLD TIME : 03 SEC
EXIT(ESC TO EXIT)
PRESET AREA SETUP
(CTRL KEY)
NUMBER 001
PAN TILT
000.0 000.0
EXIT(ESC TO EXIT)
setup displays.
Set SENSITIVITY : 01 ~ 10
Set POSITION : ALL, CENTER
Set DELAY : 00 ~ 05 SEC
Set OUTPUT : OFF, ON
Set HOLD TIME : 03 ~ 99 SEC
Select “AE SETUP” and push the Joystick to the left or right. Then the AE setup displays.
Refer to the AE SETUP in the camera setup.
6. Set “DWELL TIME”. (03 ~ 99 seconds)
7. To select the next page of Presets, scroll the page by pushing the Joystick to the left on the
first and last columns of the menu.
8. Repeat step 2 through 7 for each additional Preset position.
9. Select “SAVE AND EXIT” and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
NOTE: Press the HOME key at programmed Preset position(*) to delete a programmed
Preset view.
The position, which is marked with the *, already has the Preset view assigned. Press the PRST
key on the * to review the stored Preset. The camera will show the stored Preset scene.
Hold down the CTRL key while selecting the desired scene using the Joystick. Current position
will be displayed. Release the CTRL key to complete. Or Press the IRIS Open key then the
“CTRL” displays. Move the desired position and the zoom position. Press the IRIS Close key
then the “CTRL” disappears. Select “EXIT” and push the Joystick to the right.
20
Page 26
TOUR SETUP
NUMBER : 01
TITLE : T01
SCAN TYPE : NORMAL
SPEED : 5 STEP
DWELL : -- SEC
003 A04 --- --- --- --- ---
--- --- --- --- --- --- ---
--- --- P01 --- --- --- ---
--- T02 --- --- --- --- ---
--- --- --- --- --- --- ---
--- --- --- --- --- --- ---
SAVE AND EXIT(ESC TO CANCEL)
3.6 Shortcut of Preset Program
After selecting the desired scene, press No. (1 to 240), and press the CTRL and PRST keys
subsequently. The current view will be stored to the selected Preset number if the Preset number
is empty. If selected Preset number is not empty, “OVER WRITE” message will be displayed on
the monitor and select the “OK” and push the Joystick to the right to overwrite.
Example: 1 , 0 , 1 + CTRL + PRST keys will store current view as Preset no. 101. In this case,
focus will be programmed as Auto, dwell time will be set to 3 second, and the current
AE mode will be programmed.
3.7 Tour (Shortcut: TOUR)
There are 8 programmable Tours. Each Tour consists of up to 42 Preset positions, Patterns,
Scans or other Tours (second-level). Using second-level Tours, there can be over 300 functions
in a single Tour.
Follow the steps below to program the Tours:
1. Press the MENU key to display the main menu on the monitor. Scroll to Tour and push the
Joystick to the right to enter the Tour menu. Or just press the TOUR key on the keyboard.
2. Select “NUMBER” and set the desired number by pushing the Joystick to the left or right.
3. Choose a blank position to be programmed by pushing the Joystick up, down, right, or left.
4. To add a stored Preset, twist the Joystick then the stored Preset number displays.
5. To place functions other than Preset, press the TOUR, PTRN, or SCAN keys for Tour, Pattern
or Auto Scan respectively.
--- : blank position
SCAN TYPE : NORMAL, VECTOR
DWELL : 03 ~ 99 SEC
003 : Preset (1 ~ 240)
A04 : Auto Scan (1 ~ 8, 10 ~ 17)
P01 : Pattern (1 ~ 8)
T02 : Tour (1 ~ 8)
21
Page 27
6. You can also overwrite the programmed number and remove a stored number from the Tour,
press the HOME key on the stored number, a blank position mark (---) will be displayed.
7. Repeat step 2 through 6 for each desired position. Each title will be displayed on top of the line.
8. To edit the “TITLE”, follow the procedure of the Auto Scan above to edit titles.
9. Select “SAVE AND EXIT” and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
You can expand the Tour sequence by calling other programmed Tours.
NOTE: The speed applies in the vector mode only.
NOTE: In the Tour mode, in conjunction with Preset and Auto Scan, you can make the
camera travel from a Preset position to another Preset position at a specific speed.
Example: Preset 001>002>003>004>005>006, Auto Scan 01 starts at Preset 002, ends at
Preset 003, Auto Scan 02 starts at Preset 005, ends at Preset 006; Tour 001, 002,
A01, 004, A02.
1 2 2~3 4 5~6, repeat
where : Quick move, ~ : Programmed speed
To change the dwell time of the Preset in the Tour:
Use the Joystick to move the cursor to a stored Preset position.
By pressing the PRST key, the camera will move to the stored Preset view and the cursor moves
to the dwell time field.
After changing the dwell time, press the PRST key and the cursor moves to the Preset number.
To assign the functions other than Preset in the Tour when the function key is not
existed:
Use the Joystick to move the cursor to a stored Preset position.
Pressing the CTRL or IRIS Open key will change the Preset number to other function
(Auto Scan, Pattern, Tour or Preset) with the first programmed number.
To change the number, twist the Joystick or press the Tele or Wide key.
22
Page 28
PATTERN SETUP
(CTRL KEY)
NO TITLE SEC PERCENT
01 : P01 000 00.0%
02 : P02 000 00.0%
03 : P03 000 00.0%
04 : P04 000 00.0%
05 : P04 000 00.0%
06 : P04 000 00.0%
07 : P04 000 00.0%
08 : P04 000 00.0%
TOTAL 000 00.0%
SAVE AND EXIT(ESC TO CANCEL)
PATTERN AREA SETUP
(CTRL KEY)
NUMBER 01
000 00.0%
000 00.0%
EXIT(ESC TO EXIT)
3.8 Pattern (Shortcut: PTRN)
The Pattern feature records user control of the selected dome camera. Up to 8 Patterns can be
stored and played back by pressing No. + PTRN keys subsequently.
Follow steps below to program the Pattern:
1. Press the MENU key to display the main menu on the monitor. Scroll to Pattern and push the
Joystick to the right to enter the Pattern menu. Or just press the PTRN key on the keyboard.
2. Select the desired Pattern to be programmed by pushing the Joystick up or down. If the
Pattern is not 000, a Pattern has already been recorded. Patterns can be overwritten.
3. Press and hold down the CTRL key while controlling the camera direction and zoom with the
Joystick. The dome will be automatically recorded until you release the CTRL key. Or press
the IRIS Open key then the “CTRL” displays. Move the position and the zoom position.
Press the IRIS Close key then the “CTRL” disappears.
4. To edit the “TITLE”, follow the procedure of the Auto Scan above to edit titles.
5. Select “SAVE AND EXIT” and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
NOTE: Press the HOME key at any programmed position to delete the Pattern.
NOTE: If Pattern recording time reaches 200 seconds, it will automatically stop for a
moment.
Press the PTRN key on the title field to display with the small OSD. Then the screen will show as
below.
23
Page 29
ALARM SETUP
NO PRI FUN IN OUT HLD LATCH
01 1 001 NO ON 03 OFF
02 1 --- OFF OFF 03 OFF
DWELL : 03
ALARM OUT SETUP
SAVE AND EXIT(ESC TO CANCEL)
ALARM OUT SETUP
OUT : ALARM
EXIT(ESC TO EXIT)
The setting procedure is the same as above.
3.9 Alarm
NO : alarm input number
PRI(Priority) : The lower number has higher priority. (0 ~ 2)
FUN(Function) : Stored function number to be called by alarm.
IN : NO/NC – normally open/closed, OFF – ignore
OUT : ON – 5VTTL output, OFF – no output
HLD(Hold) : Alarm will be held for programmed time. (03 to 99 seconds)
LATCH : ON – Alarm message will remain on the screen even though alarm input
is deactivated.
OFF – Alarm message will disappear from the screen after programmed
hold time when alarm input is deactivated.
DWELL : means the dwell time during multiple alarms, 03 to 99 seconds.
ALARM: alarm output is operated during an alarm operation or by the short key of our
keyboard.
1 ~ 5 MIN(minute): alarm output is operated during this setting time only by the function run
of the dome menu or the short key of our keyboard.
NOTE: This 1 ~ 5 MIN setting is not operated by an alarm.
24
Page 30
AREA TITLE SETUP
NUMBER : 01
TITLE : ABC
START ANGLE : 124.3 30.7
END ANGLE : 359.5 45.4
SWAP : OFF
SAVE AND EXIT(ESC TO CANCEL)
3.10 Area Title
Enter a specific name on programmed angle between START and END. For the screen below,
when the camera points at an angle between 124.3 (PAN), 30.7 (TILT) to 359.5 (PAN), 45.4
(TILT), ABC will be displayed on the screen.
NUMBER : 01 ~ 16
TITLE : up to 12 characters.
SWAP : Swap the start point for the end point.
1. Select “NUMBER” and set the desired number by pushing the Joystick to the left or right.
2. To edit the “TITLE”, follow the procedure of the Auto Scan above to edit titles.
3. Select “START ANGLE”. Hold down the CTRL key while selecting the start position using the
Joystick. Current panning position will be displayed. Release the CTRL key to complete the
selection of the start position. Or press the IRIS Open key then the “CTRL” displays. Move the
desired position. Press the IRIS Close key then the “CTRL” disappears. To adjust at the 0.1
degree interval, twist the Joystick at the pan field and the tilt field.
4. Select “END ANGLE”. Hold down the CTRL key while moving the Joystick to select the end
position. Release the CTRL key to complete the selection of the end position. Or press the
IRIS Open key then the “CTRL” displays. Move the desired position. Press the IRIS Close key
then the “CTRL” disappears. To adjust at the 0.1 degree interval, twist the Joystick at the pan
field and the tilt field.
5. Select “SWAP”. Set to ON to exchange the start angle and the end angle.
6. Select “SAVE AND EXIT” and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
25
Page 31
PRIVACY ZONE SETUP
(CTRL KEY)
NO TITLE METHOD
01 ABC ON BLOCK
02 DEF ON V.OFF
03 OFF ---04 OFF ---05 OFF ---06 OFF ---07 OFF ---08 OFF ----
SAVE AND EXIT(ESC TO CANCEL)
PRIVACY AREA MENU
(CTRL KEY)
CONTROL
NUMBER 001
354.8 344.8
3.11 Privacy Zone
Hide up to 8 unwanted scenes in a camera.
1. Place the cursor at the title field.
2. Hold down the CTRL key displays the privacy area menu while selecting the position using the
Joystick. Current position will be displayed. Release the CTRL key to complete the selection
of the position.
Or press the IRIS Open key then the privacy area menu displays. Move the desired position.
Press the IRIS Close key then the “CTRL” disappears and returns to the previous menu.
3. Place the cursor at the “TITLE” field. Twist the Joystick to enter the title edit mode. Follow the
procedure of the Auto Scan above to edit titles.
4. To turn the stored zone On or Off, twist the Joystick or press the Tele or Wide key.
5. Set the “METHOD”, “BLOCK” or “V.OFF(video off)”.
6. Select “SAVE AND EXIT” and push the Joystick to the right or press the IRIS Open key.
Press the ESC or IRIS Close key to exit the program without saving.
NOTE: Press the HOME key to delete programmed Privacy Zone at the title field.
26
Page 32
CAMERA SETUP
FOCUS CONTROL
WB CONTROL
AE CONTROL
SHARPNESS : 05
RESOLUTION : LOW
SAVE AND EXIT(ESC TO CANCEL)
FOCUS SETUP
MODE : AUTO
FOCUS LIMIT : 1.0M
SAVE AND EXIT(ESC TO CANCEL)
WB SETUP
MODE : AWB
R GAIN : --B GAIN : --SAVE AND EXIT(ESC TO CANCEL)
3.10 Camera Menu
SHARPNESS The higher the value, the more edges in the picture will be
enhanced. (0 ~ 15)
RESOLUTION Select resolution mode (LOW / MID / HIGH)
• FOCUS CONTROL
MODE AUTO / MANUAL / ONE PUSH / CONSTANT MANUAL
FOCUS LIMIT This distance is approximate value and the focus operate from the setting
CAUTION: Avoid continuous, 24-hour use of the auto focus. This will shorten the
lifespan of the lens.
• WB (White Balance) CONTROL
MODE AWB / WAWB / INDOOR / OUTDOOR / MANUAL
AWB Computes the white balance value output using color information
WAWB Wide range auto white balance mode (1800 to 10500 °K)
INDOOR Indoor white balance mode
OUTDOOR Outdoor white balance mode
MANUAL Manual mode, you can change R and B Gain manually.
RGAIN 0 ~ 255
Use manual mode in normal use.
value.
from the entire screen automatically. (2500 to 9500 °K)
27
Page 33
BGAIN 0 ~ 255
AE SETUP
MODE : MANUAL
GAIN : MIN
BRIGHT : 024
SHUTTER : 1/60
FLICKERLESS : --BACK LIGHT : OFF
ATR : --DNR : --NIGHT SHOT : AUTO
SAVE AND EXIT(ESC TO CANCEL)
RGAIN / BGAIN modes are controllable only in MANUAL Mode.
• AE CONTROL
MODE AE1 / AE2 / SHUTTER PRIO / MANUAL
AE1 Auto exposure mode1 (Use to normal surroundings: indoor)
AE2 Auto exposure mode2 (Use to high brightness surroundings: outdoor)
SHUTTER PRIO Variable Shutter speed, Auto Gain
MANUAL Variable Shutter speed, Gain
GAIN MIN / LOW / MID / HIGH
BRIGHT 10 ~ 50
SHUTTER 1/60(50), 1/100(120), 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000,
1/100000
FLICKERLESS OFF / ON
BACK LIGHT OFF / BLC / HLC
ATR OFF / ON
DNR OFF / 1 ~ 7
NIGHT SHOT AUTO / ON / OFF / GLOBAL
NOTE: Values in ( ) are for PAL Camera.
NOTE: When BACKLIGHT set BLC or HLC, focus issues may occur in certain lighting
conditions.
The NIGHT SHOT option removes the IR cutoff filter of the camera and makes the camera
sensitive to near infrared.
AUTO Camera goes in to B&W mode at low light.
GLOBAL Controlled by the keyboard
(NOTE: GLOBAL function operates F2E protocol only)
The operator can enable NIGHT SHOT for all dome cameras at the same time.
If the NIGHT SHOT mode is set to GLOBAL, “999” + ENTER will turn Off the NIGHT
SHOT mode and “888” + ENTER will turn On the NIGHT SHOT mode.
ON B/W mode
OFF Color mode
NOTE: AUTO in NIGHT SHOT function is not applied in “MANUAL” mode of AE Control.
28
Page 34
3.11 Dome Setup
CONFIGURATION MENU
LANGUAGE : ENGLISH
HOME FUNCTION SETUP
OSD DISPLAY
VIEW ANGLE SETUP
INITIALIZE DATA
ORIGIN OFFSET
DOME RESET
SYSTEM MENU
SYSTEM INFORMATION
SAVE AND EXIT(ESC TO CANCEL)
HOME FUNCTION SETUP
HOME FUNCTION : NONE
FUNCTION NUMBER : --WAITING TIME : 120 SEC
FUNCTION ENABLE : OFF
SAVE AND EXIT(ESC TO CANCEL)
• LANGUAGE SETUP
LANGUAGE : Select the desired language.
• HOME FUNCTION SETUP
HOME FUNCTION : None / Tour / Pattern / Auto Scan / Preset
FUNCTION NUMBER : - - -
WAITING TIME : 10 ~ 240 seconds
FUNCTION ENABLE : ON / OFF
The Home function can be set so that the camera automatically goes to Tour, Pattern,
Auto Scan or Preset after the keyboard controller has been idle for a specified amount of time.
For example, if the controller is idle for 120 seconds, the camera goes to Preset 1.
Follow these steps to program the Home position:
1. Select “HOME FUNCTION” by pushing the Joystick to the left or right to scroll through the
None, Tour, Pattern, Auto Scan or Preset functions.
2. Select “FUNCTION NUMBER” and push the Joystick to the left or right. The recorded
function number will scroll.
3. Select “WAITING TIME” and push the Joystick to the left or right to select from 10 to 240
seconds.
4. Select “FUNCTION ENABLE” and turn to ON or OFF by pushing the Joystick to the left or
right.
29
Page 35
• OSD DISPLAY
OSD DISPLAY SETUP
CAMERA TITLE : DOMEID
VIEW DIRECTION : OFF
DOME OSD : ON
AREA TITLE : OFF
PRESET TITLE : CONSTANT
FOCUS EXPOSURE : ON
OSD POSITION SETUP
SAVE AND EXIT(ESC TO CANCEL)
(AREA TITLE) (AF AE)
(FUNC TITLE )
(CTRL KEY TO MOVE)
SAVE AND EXIT(ESC TO CANCEL)
(ALARM MESSAGE) DOMEID:XXX
XXX.X XXX.X
CAMERA TITLE : up to 6 characters
VIEW DIRECTION : ON / OFF
“ON” sets current direction as N(North) and the coordinate angle to 000. “OFF” hides the
directional title. Every 90 degrees of clockwise rotation will change the title to E(East),
S(South) or W(West). If using the ON/OFF option frequently, it is recommended to set
“North” as a Preset. Recall the “North” Preset before enabling the directional title.
DOME OSD : ON / OFF
All display or title will disappear when DOME OSD DISPLAY is set to OFF.
AREA TITLE : ON / OFF
If this option is enabled, the area title displays when the camera moves.
NOTE: The DOME OSD DISPLAY must be enabled.
PRESET TITLE : CONSTANT / OFF / 3, 30, 60, 120, 180 seconds
Set the Preset title display time.
FOCUS EXPOSURE : ON / OFF
ON: FOCUS and EXPOSURE displays. (AF AE)
OSD POSITION SETUP
Select the OSD option with the Joystick up and down, press the CTRL key and adjust the
position by the Joystick.
30
Page 36
• VIEW ANGLE SETUP
VIEW ANGLE SETUP
PANNING RANGE
FLIP : AUTO
TILT LIMIT : OFF
SAVE AND EXIT(ESC TO CANCEL)
PANNING RANGE SETUP
(CTRL KEY)
RIGHT LIMIT : 000.0
LEFT LIMIT : 000.0
ENABLE : OFF
SWAP : OFF
AUTO PAN : ON
SAVE AND EXIT(ESC TO CANCEL)
FLIP: OFF, AUTO
OFF: The dome camera moves until 90 vertically.
AUTO: When the camera reaches the floor directly above the moving object, it will stop. At
that time, release the Joystick instantly and pull it down again to run the auto-flip function.
When you use the panning range, it is recommended to use the flip mode to AUTO.
TILT LIMIT:
This option is designed to limit the view angle as there is some obstruction in zooming out
on specific areas of the tilt angle.
ON: When this option is enabled, the range of the tilt angle will be limited to 10 degree.
This can prevent obstruction or bad focusing problems caused by the horizontal line of the
semi sphere in the bubble.
OFF: When this option is disabled, the range of the tilt angle is not limited.
When you zoom out within the range of the tilt angle, you will see the horizontal line of the
semi sphere in the bubble. Focus issues may occur in certain lighting conditions.
PANNING RANGE
When the dome camera is installed near a wall, panning range can be limited by user.
1. Place the dome camera under 90 degree vertically.
2. Set “RIGHT LIMIT” by pushing the Joystick to the right.
3. Set “LEFT LIMIT” by pushing the Joystick to the left.
4. Set “ENABLE” to ON to use.
To exchange the right and the left limit, set “SWAP” to ON.
To apply limits on the auto pan (endless panning), set “AUTO PAN” to ON.
NOTE: When the flip mode is 90 , 100 , 110 or 120 and you moves over 90 vertically,
the panning range operates in opposite side.
31
Page 37
• INITIALIZE DATA
INITIALIZE DATA
FACTORY DEFAULT
ERASE PROGRAMMED DATA
PRESET FOCUS DEFAULT
EXIT(ESC TO EXIT)
FACTORY DEFAULT
ARE YOU SURE ?
CANCEL
OK
ERASE PROGRAMMED DATA
AUTO SCAN : ON
PRESET : ON
TOUR : ON
PATTERN : ON
ALARM : ON
AREA TITLE : ON
PRIVACY ZONE : ON
CAMERA : ON
DOME SETUP : ON
ERASE
SAVE AND EXIT(ESC TO CANCEL)
PRESET FOCUS DEFAULT
FOCUS : AUTO
SAVE AND EXIT(ESC TO CANCEL)
FACTORY DEFAULT
Select “FACTORY DEFAULT” to initialize the data.
ERASE PROGRAMMED DATA
Erase all stored data from the Flash-ROM of the selected dome camera. You will be asked
to enter ON or OFF. If you desire to erase all data then select “ERASE” run, otherwise press
the ESC key to exit without erasing. The erased data includes all stored data (Auto Scan,
Preset, Tour and Pattern, …) except origin offset.
The offset value is still valid after all data is erased. The offset value can be zero with default
set of Offset origin menu.
PRESET FOCUS DEFAULT
This menu set the default mode of the focus when you save the Preset.
FOCUS : AUTO / MANUAL / ONE PUSH
32
Page 38
• ORIGIN OFFSET
OFFSET SETUP
(CTRL KEY)
PAN OFFSET : 000.0
TILT OFFSET : 000.0
ENABLE : OFF
SAVE AND EXIT(ESC TO CANCEL)
DOME RESET
ARE YOU SURE ?
CANCEL
OK
SYSTEM MENU
MOTOR SETUP
PASSWORD EDIT
ORIGIN CHECK
WHITE DEFECT COMPENSATION
CALIBRATION : ON
PASSWORD ENABLE : OFF
MENU TIME OUT : OFF
BLINK CURSOR : ON
DOME ANSWER : ON
SAVE AND EXIT(ESC TO CANCEL)
This feature is useful to align a new dome camera exactly the same as the previously installed
dome camera.
Dome camera’s origin set and all data initialize option do not override offset values. Only the
default set option in this menu will set the offset value to zero. This can be used to avoid
ceiling obstructions.
• DOME RESET
This feature is used to re-calibrate the orientation of a selected dome camera. Origin offset
value is not affected by this function. (Offset is still valid after origin set)
• SYSTEM MENU
CALIBRATION : ON(Auto origin check) / OFF
PASSWORD ENABLE : ON(requires the password to enter menu) / OFF
MENU TIME OUT : ON(5mintues) / OFF(always menu display)
BLINK CURSOR : ON / OFF(no blinking cursor)
DOME ANSWER : ON / OFF(no acknowledge command from the dome)
This option is helpful to escape the collision of the command using some DVR.
33
Page 39
MOTOR SETUP
MOTOR SETUP
PROPOTIONAL P/T : ON
P/T MODE : NORMAL
SAVE AND EXIT(ESC TO CANCEL)
PASSWORD EDIT SETUP
(CTRL KEY)
INPUT PASSWORD
PASSWORD :
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z 0 1 2 3
4 5 6 7 8 9 ( )
SAVE AND EXIT(ESC TO CANCEL)
ORIGIN CHECK
ARE YOU SURE ?
CANCEL
OK
Motor Setup menu provides the pan and tilt speed of a camera. User can set the desired
speed with pushing the Joystick to the left or right. During operation, pressing 153 + ON
keys will change the speed to the SLOW mode and pressing 153 + OFF keys will change
the speed to the Normal mode.
Press and hold the CTRL key and moving the Joystick will operate with the TURBO speed
mode.
PROPOTIONAL P/T : ON / OFF
P/T MODE : SLOW / NORMAL / TURBO
SLOW MAXIMUM SPEED : 40 /second
NORMAL MAXIMUM SPEED : 90 /second
TURBO MAXIMUM SPEED : 380 /second
PASSWORD EDIT
You can change the password with 6-digit character in this menu.
The default password is 555555.
When the password enable is on, the input password window displays to enter the menu.
At this time, move the cursor to the desired character with the Joystick and press the CTRL
or IRIS Open key.
ORIGIN CHECK
If you find the dome in the wrong position during operation, execute this origin check and the
dome camera will return to the right position after the origin check operation.
Pressing 151 + ON keys will execute the origin check.
34
Page 40
WHITE DEFECT COMPENSATION
WHITE DEFECT COMPENSATION
ARE YOU SURE ?
CANCEL
OK
SYSTEM INFORMATION
CAMERA TYPE : xxxxx-Vx.xxxx
H/W VERSION : Vx.xx-xxxx
ROM VERSION : Vx.xxxxx
PROTOCOL : xxxx
BAUDRATE : 9600
EXIT(ESC TO EXIT)
FUNCTION RUN SETUP
(CTRL KEY)
PRESET : --PATTERN : --TOUR : --SCAN : --HOME
AUTO PAN
ALARM OUT : --EXIT(ESC TO EXIT)
White defect of CCD sensor will be compensated.
• SYSTEM INFORMATION
The system information provides essential information about the dome camera if service is
required. This screen displays the camera type and ROM version. The information on this
screen cannot be modified.
3.14 Function Run
This Function Run menu allows you to execute the function when you use a keyboard or a DVR
without the function keys (Preset, Pattern, Tour and Scan).
1. Select the desired Function by pushing the Joystick up or down.
2. Select the number by twist the Joystick in PRESET, PATTERN, TOUR and SCAN.
3. Press the CTRL or IRIS Open key to execute.
NOTE: To execute the function, you should save the function (PRESET, PATTERN, TOUR
and SCAN) first.
35
Page 41
- HOME
ALARM OUT SETUP
OUT : 1 MIN
EXIT(ESC TO EXIT)
FACTORY SETUP
TOUR DWELL TIME : 03 SEC
ANSWER DELAY : 03 SEC
SAVE AND EXIT(ESC TO CANCEL)
Select “HOME” and press the CTRL key. The dome camera goes to the default position that it
returns to after an assigned period of inactivity passes. The default position may be a Preset,
Tour, Pattern or no action.
- AUTO PAN
You can execute the endless auto pan to turn in one direction continuously by selecting Auto
Pan.
- ALARM OUT
This function can operate only when the alarm out setup has the time in the alarm menu.
Ex)
You press the CTRL or IRIS Open key then that alarm out operates during the setting time
only.
3.15 Factory Setup
Pressing 250 + PRST keys pops up this menu.
TOUR DWELL TIME means the dwell time between Tours.
ANSWER DELAY means the response time of the dome and you don’t need to change in normal
condition.
36
Page 42
Appendix A — Specifications
MODEL
CPTZ28D5W
MODULE
CCD Type
1/4" Type EXview HAD CCD II
Optical Zoom
22X
Max Resolution
700 TVL
Focal Length
f = 3.9mm ~ 85.8mm
Angle of View
3.9mm – 49.5° (H)
85.8mm – 2.4° (H)
F-Number
F1.6 ~ F3.7
Min. Illumination
- Normal
0.5 Lux
ICR on (Day & Night)
YES
Motion Detection (in PRESET)
YES
DOME
Tilt Angle
0° ~ 90° (Auto Flip)
Auto Calibration
0.1° ~ 6°
Panning Angle
360 continuous rotation
Alarm
2 inputs (NO/NC), 1 output (5VTTL)
Auto Scan
1 auto pan & 16 auto scans capability
Preset
240 presets with individual camera AE setup
Pattern
8 patterns (recording up to 200 sec.)
Tour
8 tours (consist of 42 functions / 1 tour)
Max Speed
380°/sec.
Area Title
Can be divided 16 areas with 12 characters per title
Privacy Zone
8 privacy zone masks (2 methods selectable : Block / Video off)
Electrical
Power Source
12VDC ± 10%
Power Consumption
8W (650mA)
Control
RS-485/422, baud rate: 2400 ~ 19.2k bps (default: 9600 bps)
ID (Camera Address)
1 ~ 255
Mechanical
Dimension
See dimension
Weight
Approx. 1.1 kg for dome
Environment
Operating Temperature
0 C to 40 C (32 F to 104 F)
Operating Humidity
0 to 90%RH (non-condensing)
Storage Temperature
-20 C to 60 C (-4 F to 140 F)
22X INDOOR MOUNT DOME CAMERA
* Specifications are subject to change without notice *
37
Page 43
Figure 6.1 – Dimension (Flush Case)
38
Page 44
Figure 6.2 – Dimension (Surface Case)
39
Page 45
Appendix B — Troubleshooting
Problem
Possible Solution
No video.
Verify that power is connected to all pieces of
equipment in the system.
Verify that the power switches are in the ON position.
Check the video connections.
Poor video quality.
Check that the BNC connectors are inserted properly.
Check the voltage level of the dome camera.
Cable for video is shielded.
Dome cameras lose their positions.
Reset the cameras using the Dome configuration
menus.
Check that the dome cameras are inserted properly in
the base.
Check the voltage level of the dome camera.
Camera number does not match the
multiplexer number.
Check the camera ID and insert the BNC cable into
the proper input of the multiplexer.
If problems occur, verify the installation of the camera with the instructions in this manual and
with other operating equipment. Isolate the problem to the specific piece of equipment in the
system and refer to the equipment manual for further information.
40
Page 46
Appendix C — Short Cut Key
Short Cut Key
Function
PRST
Pop up Preset setup menu
TOUR
Pop up Tour setup menu
PTRN
Pop up Pattern setup menu
SCAN
Pop up Auto Scan setup menu
No.+ CTRL+ PRST
Store the current view at the selected number
Short Cut Key
Function
Short Cut Key
Function
7 + ON
Change FOCUS to AUTO
7 + OFF
Change FOCUS to manual
8 + ON
Change AE to AE1
8 + OFF
Change AE to manual
9 + ON
Change Night Shot to AUTO
10 + ON
Night Shot on
10 + OFF
Night Shot off
11 + ON
BLC on
11 + OFF
BLC off
13 + ON
Dome OSD on
13 + OFF
Dome OSD off
14 + ON
Dome Area Title Display on
14 + OFF
Dome Area Title Display off
15 + ON
View Direction on
15 + OFF
View Direction off
151 + ON
Origin Check
152 + ON
Place the camera in the 0° area horizontally.
153 + ON
Go to the slow speed mode
153 + OFF
Go to the normal speed mode
154 + ON
Display System Information
155 + ON
Flip the camera in the 180° area horizontally.
250 +
PRST
Factory setup menu (Tour dwell time, Answer delay)
888 + ENTER
Night Shot on (in the global mode only)
999 + ENTER
Night Shot off (in the global mode only)
41
Page 47
Page 48
CPTZ28D5W 22X Pan Tilt Zoom Camera
Page 49
Loading...
