Introduction
Thank you for purchasing the Contractor Elite series of indoor/outdoor speakers
Tools / Item Needed
4. Speaker wire
4. Speaker wire
from Speco Technologies. We take pride in providing you with high quality products.
Our loudspeaker will bring you years of pleasure for your acoustic entertainment.
This instruction booklet covers the necessary information for a smooth installation.
Contractor Elite is an advanced indoor/outdoor loudspeaker system that allows you
to enjoy your favorite music in either remote locations around residential or
commercial spaces.
1. Pencil
2. Measuring tape
3. Screw driver
5. Wire stripper
Product Parts
a. Mounting Bracket
b. Cable gland
c. Rubber feed through
d. Terminal cover
e. Bracket knob
f. Cabinet
g. Grille
Dimensions：
SPCE6 series
W 7.9” (201mm)
D 8.3” (210mm)
H 12.6” (320 mm)
(with Mounting Brackets)
SPCE5 series
W 7.5” (190mm)
D 6.75” (171mm)
H 11.25” (286 mm)
(with Mounting Brackets)
a
b
e
d
f g
c
e
Page 3
Installation
. Tightly insert terminal
to binding post (Red:
(outdoors)
or
rubber
cover into the cabinet
or
1. Vertical mounting
4. Use Cable gland
feed through (indoors)
on terminal cover for
speaker wire.
Installation Tips
Utilize the holes in the brackets
2. Horizontal mounting 3. Adjust tap selector
(if applicable)
5. Connect speaker wire
+, Black:-)
Suggested Clearance
6
groove
More bass output
R 9”
5.3”
Less bass output
Page 4
Limited Warranty
you specific legal rights. You may have other rights which vary from state to state.
We warrant this product to be free from any manufacturing or material
defects for 5 years from the purchase date.
This warranty will not extend to any products which have been subjected to
misuse, neglect, accident, or improper installation, used in violation of instructions
furnished by us; or to units which have been repaired or altered outside of the
factory. This limited warranty does not apply to broken cases, batteries, or other
physically damaged parts.
Upon request by the customer, the company will, at the customer's expense,
repackage merchandise in new cartons, replace missing accessories, and return in
resalable condition. Unless requested, the company will replace and return all
merchandise in the packaging in which it was received. This warranty is in lieu of
all expressed warranties, expressed or implied, and of all obligations or liability on
our part, and we neither assume nor authorize any representative or other person
to assume for us any obligation or liability. In no event shall we be liable for
incidental or consequential damages arising from the use of the product, or for any
delay in the use of this product do to causes beyond our control. Some states do
not allow limitations of how long an implied warranty lasts and/or do not allow the
exclusion or limitation of consequential damages. The above limitations on implied
warranty and consequential damages may not apply to you. This warranty gives
Requirements and Warranty Coverage
This warranty may not be valid if the product was purchased through an
unauthorized dealer. This warranty only applies to the individual that made the
original purchase, and it cannot be applied to other purchases. The purchaser must
be prepared to provide proof of purchase (receipt). This warranty will not be valid if
the identifying number or serial number has been removed, defaced, or altered.
This warranty does not cover the following:
• Accidental damage
• Damage caused by abuse or misuse
• Damage caused by attempted repairs/modifications by anyone other than an
authorized dealer
• Damage caused by improper installation
• Normal wear, maintenance, and environmental issues
• Damage caused by voltage inputs in excess of the rated maximum of the unit
• Damage inflicted during the return shipment
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any
obligation.
Speco Technologies . 200 New Highway . Amityville . NY . 11701 . www.specotech.com
Rev. 04/20/18
