Schedule 80 CPVC Technical
.
Schedule 80 CPVC Fittings
Plug
Spigot
Part Number Size L
849-015C 1-1/2 1-11/16 .14
849-020C 2 1- 7/8 .22
849-025CF
849-030CF
849-040CF
849-060CF
849-080CF
849-100CF
4
Plug fabricated using Cap and pipe spigot.
* Fabricated
849-120CF
4*
4*
4*
4*
4*
4*
4*
Plug
Mipt
(Continued)
Approx. Wt.
(Lbs.)
2-1/2 5- 3/8 1.12
3 5-7/8 1.55
4 6-15/16 2.66
6 9-5/8 6.75
8 12-3/16 13.50
10 12-1/4 17.99
12 14- 1/8 28.85
Part Number Size L
850-002C 1/4 23/32 .01
850-003C 3/8 3/4 .01
850-005C 1/2 27/32 .01
850-007C 3/4 7/8 .02
850-010C 1 1- 1/16 .05
850-012C 1-1/4 1-5/16 .07
850-015C 1-1/2 1-3/8 .10
850-020C 2 1- 3/8 .16
850-025C 2-1/2 1-13/16 .29
850-030C 3 1- 7/8 .45
850-040C 42-1/8.81
850-060C 6 2- 3/32 1.79
850-060CF
4*
850-080C 8 2-13/32 3.53
850-080CF
850-100CF
4
Plug fabricated using Cap and threaded pipe.
* Fabricated
Made in the U.S.A
850-120CF
4*
4*
4*
6 7-1/2 5.50
8 9-11/16 12.18
10 8- 7/16 13.76
12 10-5/8 24.34
Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas
