Schedule 80 PVC Technical
.
Schedule 80 Fittings
Coupling - Reducer
Socket x Socket
Part Number Size L M M1 N
829-167 1-1/4X3/4 2-19/32 2- 3/32 1- 5/8 11/32 .16
829-168 1-1/4X1 2-11/16 2- 1/8 1- 3/4 5/16 .16
829-209 1-1/2X1/2 2-27/32 2-11/32 1- 3/16 19/32 .18
829-210 1-1/2X3/4 2- 7/8 2- 3/8 1-13/32 17/32 .20
829-211 1-1/2X1 2- 7/8 2-11/32 1-15/16 3/8 .25
829-212 1-1/2X1-1/4 2-13/16 2-13/32 2- 1/8 5/32 .21
829-247 2X1/2 3- 3/32 2- 7/8 1- 5/32 11/16 .29
829-248 2X3/4 3- 7/32 2- 7/8 1-13/32 23/32 .30
829-249 2X1 3-1/2 3 1-23/32 27/32 .36
829-250 2X1-1/4 3-11/32 2- 7/8 2- 3/32 19/32 .30
829-251 2X1-1/2 3- 7/32 2-27/32 2-11/32 1/4 .29
829-291 2-1/2X1-1/2 3- 3/4 3- 1/2 2- 3/8 19/32 .50
829-292 2-1/2X2 3-21/32 3-15/32 2-27/32 13/32 .48
1
829-335
1
829-336
1
829-337
829-338 3X2 4 4- 5/32 2-7/8 19/32 .74
829-339 3X2-1/2 4-1/8 4- 5/32 3- 15/32 1/2 .75
829-416
829-417
829-419
*
1
1
1
829-339F
829-420 4X2 5- 1/2 5- 9/32 2- 7/8 1-25/32 1.44
829-421 4X2-1/2 4- 9/16 5- 3/16 3- 1/2 17/32 1.27
829-422 4X3 4-19/32 5- 1/4 4- 3/16 15/32 1.25
829-528
829-529
829-530
*
*
*
*
*
1
1
1
*
829-460F
829-487F
829-488F
829-490F
829-491F
829-530F
829-532 6X4 6- 5/8 7- 5/8 5- 5/16 1- 7/16 3.27
829-534F
829-533F
829-579F
829-580F
829-582F
829-583F
*
*
*
*
*
*
829-585 8X6 8 9- 3/4 7- 1/2 1 6.16
3X1 4- 7/16 4- 1/8 2- 7/8 1- 7/16 .98
3X1-1/4 4- 7/32 4- 5/32 2-29/32 1- 1/16 .93
3X1-1/2 3-1/2 4- 3/16 2- 3/8 7/32 .69
3X2-1/2 6 4- 1/16 3- 7/16 1- 3/4 .90
4X3/4 5-23/32 5- 9/32 2-29/32 2-13/32 1.66
4X1 5-15/16 5- 9/32 2-29/32 2-17/32 1.68
4X1-1/2 5-23/32 5- 9/32 2-29/32 2- 1/16 1.59
4-1/2X4 6-15/16 5- 5/8 5- 3/16 2- 3/16 2.13
5X2-1/2 8-1/16 6- 1/4 5- 3/16 3-5/16 3.55
5X3 8-1/16 6- 1/4 5- 3/16 3-3/16 3.21
5X4 7- 3/4 6- 1/4 5- 3/16 2- 1/2 2.24
5X4-1/2 6-7/8 6-5/16 5-11/16 1-3/8 2.53
6X2 7- 1/16 7- 1/2 5 2- 9/16 4.28
6X2-1/2 6-31/32 7-19/32 5- 9/32 2- 3/16 4.29
6X3 7- 1/8 7- 9/16 5- 9/32 2- 1/4 4.09
6X3 9- 3/16 7- 5/16 5- 3/16 4-1/16 3.85
6X4-1/2 7-7/8 7-3/8 5-11/16 2-1/8 3.41
6X5 8-15/16 7- 3/8 6- 5/16 2-11/16 3.74
8X2-1/2 14-15/16 9- 1/2 5- 3/16 8-15/16 8.32
8X3 14-15/16 9- 1/2 5- 3/16 8-13/16 7.95
8X4 14- 5/8 9- 1/2 5- 3/16 8- 1/8 7.15
8X5 14-11/16 9- 1/2 6- 5/16 7- 7/16 7.77
(Continued)
Approx. Wt.
(Lbs.)
Made in the U.S.A
Suitable for Oil-Free air handling to 25 psi, not for distribution of compressed air or gas
See Spears® Product Sourcebook for product offerings
