Instructions for Models:
SA-1204
SA-1205
SA-1206
SA-1207
What You Need To Know:
Tools:
Required:
*Phillips Screwdriver *Small Flat Tip
Screwdriver
*Drill with 1/4” bit *Pencil
Important Notes:
Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur.
Instruction images shown are for reference only
and apply to all models numbers shown.
Safety Tips:
This item is NOT designed for use as a grab bar.
Do not mount in locations where product is likely
to be used as a grab bar.
Maintenance:
Clean with a soft, damp cloth only. Do not use
scrub pads, detergents or cleansers as they may
harm the protective finish of your bath accessories.
Drill 1/4” holes in marked locations. If mounting
�
directly into stud or wood wall, secure Mounting
Bracket to wall using Mounting Screws without
drilling holes.
Need Help?
For additional assistance or service call:
SPEAKMAN Company
400 Anchor Mill Road
New Castle, DE 19720
PHONE: 800-537-2107
EMAIL: [email protected]
WEB: www.speakmancompany.com
Helpful:
*Tape Measure *Level
Loosen set screw at base of each post and
�
remove brackets (if necessary). Determine
mounting location of component and lightly
trace outline on wall with a pencil.
Center Mounting Bracket within traced outline.
�
Mark the 2 mounting locations with a pencil.
Insert Plastic Anchors into drilled holes and press
�
in until flush with wall. Secure Mounting Brackets
to wall with Mounting Screws using Phillips
Screwdriver.
Locate post over Mounting Bracket and tighten
�
Set Screw with Small Flat Tip Screwdriver.
Repeat steps 1 thru 5 for remaining items.
92-SA-120X-R2
Page 2
24”
[609.6mm]
26.1”
[663 mm]
Towel Ring Post
18”Towel Bar(24”Towel Bar)
Plastic Anchor
Mounting Bracket
Mounting Screw
Hex Wrench
Holding Screw
Towel Bar Post
Robe Hook Post
Mounting Bracket
Mounting Screw
Hex Wrench
Holding Screw
Plastic Anchor
Mounting Screw
Hex Wrench
Plastic Anchor
Mounting Bracket
2.1”
[53.2mm]
1.57”
[40.4mm]
1.97”
[50.1mm]
2.1”
[53.2mm]
0.79”
[20mm]
6.27”
[159.2mm]
0.79”
[20mm]
3.1”
[78.8mm]
0.99”
[25.3mm]
0.99”
[25.3mm]
3.1”
[78.8mm]
3.1”
[78.8mm]
0.99”
[25.3mm]
Tissue Holder Post
Mounting Bracket
Mounting Screw
Hex Wrench
Holding Screw
Plastic Anchor
Holding Screw
7.5”
[190.5mm]
[190.5mm]
2.1”
[53.2mm]
6.7”
[170mm]
1.57”
[40.4mm]
3.79”
[96.2mm]
0.99”
[25.3mm]
3.4”
[86.77mm]
