SPEAKMAN
®
400 Anchor Mill Rd., New Castle, DE 19720, USA
800-537-2107 | Fax: 800-977-2747
www.speakmancompany.com
S-2272-E2
S-2280
S-2285
CCo m m e r i a l
Showerheads
GENERAL SPECIFICATION
❑ S-2272-E2
Water conserving pressure compensating Autoflo® device reduces flow to a
maximum of 2.0 gpm/7.6 lpm. Polished chrome plated.
❑ S-2292
1-3/4” brass shank. Spray adjusting T-handle. Brass ball swivel joint. Flow
control device reduces flow to 2.5 gpm/9.46 lpm maximum, to meet existing
ASME A112.18.1/CSA B125.1 Standard. Polished chrome plated.
OPTIONS
SUFFIX DESCRIPTION
❑ BP Blister pack packaging (S-2292 only)
Brass Showerheads
GENERAL SPECIFICATION
Water conserving pressure compensating Autoflo® device reduces flow to a maximum of 2.5 gpm/9.46 lpm, to meet existing ANSI A112.18.1/CSA B125.1 Standard.
Vandal-resistant standard. 1/2” NPT inlet.
❑ S-2280
Anystream wall mounted showerhead. Rigid brass ball. Spray adjusting T-handle
2-1/2” face. 4 Lexan® deposit resisting plungers with 32 spray channels. Drilled for,
but less mounting bolts.
S-2288
S-2292
S-2460
❑ S-2288
Watersaver showerhead. Brass shank. Brass adjustable spray face. Brass ball swivel
joint.
❑ S-2285
Watersaver showerhead. Rigid brass head. Adjustable spray. Drilled for, but less
mounting bolts.
❑ S-2460
Solid brass wall mounted showerhead. 2” face. 60 spray channels at three different
angles to allow a full coverage shower. Drilled for, but less mounting bolts.
OPTIONS
SUFFIX DESCRIPTION
❑ AP Anchor plate assembly with mounting screws
(not S-2288)
❑ BJ Ball joint (S-2280 & S-2285 only)
❑ BPT 1/2” British pipe thread inlet (S-2288 only)
❑ 2 S-2252 Anystream showerhead (S-2280 only)
This space for Architect/Engineer approval.
Anystream and Autoflo — Registered T.M. Speakman Company
Anystream — Registered T.M. Speakman Company
© Copyright, Speakman Company, 2011
© Copyright, Speakman Company, 2011
