Page 1
NSF 372
SPEAKMAN
®
S-3552
Single Lever Faucet
S-3562-LD
SPECIFICATION
MODELS:
❑ S-3552: 4 in. lead free centerset single lever faucet with
1-1/4 in. pop-up drain.
❑ S-3562-LD: 4 in. lead free centerset single lever faucet.
No drain assembly.
FEATURES:
• Lead free NSF compliant
• 4 in. centerset single lever faucet.
• All metal shell and belly plate.
• Ceramic cartridge.
• Water conserving aerator reduces flow to 1.5 gpm/
5.7 L/pm.
• Copper tube inlets with 1/2 in. NPSM compression
threads.
COMPLIANCE:
• Meets ASME A112.18.1/CSA B125.1, NSF 61,
NSF 372 and WaterSense standards
AVAILABLE FINISHES:
• Polished Chrome (standard)
OPTIONS:
ADD SUFFIX TO MODEL #
• 0.5 gpm ow control, vandal-resistant ❑ -BO
• 1.5 gpm laminar ow control outlet ❑ -LF
• 1.5 aerated ow control, vandal-resistant ❑ -VR
WARRANTY:
• 1 year limited
SEE REVERSE FOR ROUGH-IN DIMENSIONS
THIS SPACE FOR ARCHITECT/ENGINEER APPROVAL.
400 ANCHOR MILL ROAD | NEW CASTLE, DE 19720
P: 800-537-2107 | F: 800-977-2747
WWW.SPEAKMANCOMPANY.COM
REVISION DATE: JULY 2014
NSF 372
Management Systems
Registered to ISO 9001
417
Page 2
NSF 372
6-7/16"
®
SPEAKMAN
Single Lever Faucet S-3552, S-3562-LD
S-3552
6-1/4"
(158mm)
6"
(152mm)
10°
(164mm)
SPECIFICATION
Pop-Up Drain
3-1/4"
(83mm)
S-3562-LD
4-1/2"
(114mm)
HOLD DOWN
HARDWARE
NOT SHOWN
NUTS NOT SHOWN
1" MAX
(25mm)
3-5/8"
(92mm)
4-3/4"
(121mm)
S-3552
S-3562-LD
418
THIS SPACE FOR ARCHITECT/ENGINEER APPROVAL.
NOTE: 1. All dimensions are in inches (millimeters) unless otherwise specified and
are subject to change without notice. 2. Inlet is 3/8” compression with male threads.
3. Position faucet as close to the edge of the sink as possible
NSF 372
400 ANCHOR MILL ROAD | NEW CASTLE, DE 19720
P: 800-537-2107 | F: 800-977-2747
WWW.SPEAKMANCOMPANY.COM
Management Systems
Registered to ISO 9001
REVISION DATE: JULY 2014
