SPEAKMAN
Combination Shower with Eye/Face Wash System
FEATURES:
• 8 in. Cycolac® yellow plastic showerhead
• Internal 20 gpm restrictor ow control
• 1 in. NPT female brass, chrome-plated, full ow stay-open ball valve
• Powder coated yellow, aluminum triangular pull rod activator
• 1¼ in. IPS galvanized steel piping stanchion with brass ttings
• 1¼ in. NPT female inlet
• 20 gpm @ 30 psi
EYE/FACE WASH: SE-575
• (2) yellow plastic spray outlets with ip-top dust caps
• ½ in. NPT female brass, chrome-plated, full ow stay-open ball
valve
• Stainless steel push handle activator
• ½ in. NPT male inlet
• 4.5 gpm @ 30 psi
• Universal Emergency Sign Included
SE-675
SPECIFICATION
COMPLIANCE:
• Certied to ANSI/ISEA Z358.1
FINISHES:
• Galvanized Steel (standard)
OPTIONS:
ADD SUFFIX TO MODEL #
• Anti-freeze protection valve ❑ -FPV
• Hand & foot operation ❑ -HFO
• Hand-held spray ❑ -HS
• Self-closing shower valve with chain & ring ❑ -SCSV
• Stainless steel pull rod ❑ -SPR
• Anti-scald protection valve ❑ -SPV
• 1 in. IPS stainless steel ball valve ❑ -SSBV1
• 1/2 in. IPS stainless steel ball valve ❑ -SSBV2
• Stainless steel showerhead ❑ -SSH
WARRANTY:
• 3 year limited
SEE REVERSE FOR ROUGH-IN DIMENSIONS
THIS SPACE FOR ARCHITECT/ENGINEER APPROVAL.
400 ANCHOR MILL ROAD | NEW CASTLE, DE 19720
P: 800-537-2107 | F: 800-977-2747
WWW.SPEAKMANCOMPANY.COM
REVISION DATE: JANUARY 2015
Management Systems
Registered to ISO 9001
659
Page 2
®
SPEAKMAN
Combination Shower with Eye/Face Wash System SE-675
SPECIFICATION
660
THIS SPACE FOR ARCHITECT/ENGINEER APPROVAL.
NOTE: 1. All dimensions are in inches (millimeters) unless otherwise specified and are subject to
change without notice.
400 ANCHOR MILL ROAD | NEW CASTLE, DE 19720
P: 800-537-2107 | F: 800-977-2747
WWW.SPEAKMANCOMPANY.COM
REVISION DATE: JANUARY 2015
Management Systems
Registered to ISO 9001
