SPEAKMAN
SE-237
LIFESAVER® EMERGENCY SHOWER
DESCRIPTION
The SE-237 Lifesaver® Emergency Shower
features a concealed ceiling mounted impeller
action chrome-plated shower head with a horizontal
supply. The unit is activated with a 1" stay-open
ball valve operated by a wall mounted lever.
SPECIFICATIONS
Showerhead:10"ushmounted,
polished chrome plated
Flow Control: Internal 20 gpm regulator
Valve: 1" NPT female brass, chrome-plated,
stay-open valve
Cabinet: 18 gauge (0.048 thick) Type 304 stainless steel
Activator: Wall mounted stainless steel lever
with black plastic rotating handle
Performance: 20 gpm @ 20 psi
Compliance: ANSI Z358.1
Universal Emergency Sign Included
®
AVAILABLE MODELS
❑ SE-237 Suitable for 6" walls
❑ SE-237-SR Suitable for 4" walls
❑ SE-237-SM Surface mounted, no cabinet minimum
wall thickness is 4"
OPTIONS
❑ FLW Flow switch
❑ SSBV Stainless steel ball valve
❑ SSH Stainless steel showerhead
Job Name ______________________________
Location _______________________________
Architect/Engineer ______________________
Sales Representative ______________________
Wholesaler _____________________________
Date ____________ Model # ______________
P.O. Box 191, Wilmington, DE 19899-0191 USA
1-800-537-2107 Fax: 1-800-977-2747
www.speakmancompany.com
Revision Date
NOV. 2007
