CAUTION:
SAFETY WARNING:
Never let children climb on product or play with product.
Do not sit or stand on product.
Do not fasten a TV that is heavier than the recommended load rating to the mount.
Using suitable concrete wall or wood stud wall.
Improper installation may cause property damage and/or personal injury, so the
installation must be done by two qualified contractors. The manufacture is not liable for
damage or injury caused by incorrect mounting, assembly or use.
Improper handling can result in cuts and lacerations.
Pictures for reference only, subject to our available products.
Keep this instruction for future reference.
CAUTION
weight capacity 33lbs."
weight. Pls don't over tighten screws in order to avoid any injury.
This mount is intended for use with weights not exceeding "maximum
:
The wall itself has to be capable of supporting 4X standard
Use with products
heavier than the maximum weights indicated may result in collapse of the mount
and its accessories causing possible injury.
Part list
:
A-Wall plate unit 1pc
Hardware list:
--Lag bolt
3pcs
a--M4X12 bolt
4pcs
g--2.5mm spacer
4pcs
--Anchor
3pcs
b--M5X12 bolt
4pcs
h--M4/M6 spacer
4pcs
--8mm Open-
End Wrench 1pc
c--M6X12 bolt
4pcs
i--M4/M5
washer 4pcs
d--M4X30 bolt
4pcs
j--M6 washer
4pcs
e--M5X30 bolt
4pcs
f--M6X30 bolt
4pcs
①
Step 1
bit
：
Disassemble Wall Plate Unit into Two Pieces.
A
Wall plate A1
Figure 1
Step 2
Pls remove the plaster board on the surface of concrete
：
mount on the concrete wall.Hold wall plate
against wall at desired position on
(A1)
TV plate A2
wall
when assembling
concrete wall, then using a pencil mark 3 hole locations . Then drill holes according pencil
marks using 3/8" size drill bit to a depth of 2.36" . Then you will need to use wall anchors
. Insert wall anchors
anchors into wall. Then fix wall plate
The concrete wall minimum thickness no less than 5.5 inches, and
:
CAUTION
into holes, you may need to use hammer to lightly tap wall
(A1)
to the wall with screws
. (Figure 2)
surface covering can't more than 3/8 inches.
If you mount TV mount into wood studs ,pre-drill the mark 3 holes using 5/32" drill
to a depth of 2.36", fix wall plate
The wood stud min size is 2x4 inches, and surface covering can't more
CAUTION
:
to the wall with screws
(A1)
. (Figure 3)
than 5/8 inches. Drill hole on the wooden pillars middle line.
CAUTION:
Don't use it on the concrete block.
Wood Single Stud
5/32"
A1
3/8"
Concrete wall
A1
Stud
finder
Figure 2 (keep the wall plate level) Figure 3 (keep the wall plate level)
②
Step 3:
spacer to fix the holes of TV rear.
If the back of TV is not flat, or the bolts used to assemble TV are too long, or there is
interfere between TV bracket and cable inlets, we highly recommend you to use spacers .
Attach TV plate (A2) to the back of TV, choose corresponding bolt, washer and
CAUTION
Hang the pre-assembled TV unit on the wall plate. Fasten TV plateby bolts
Step 4:
with a screwdriver.
CAUTION
:
Using incorrect bolts may damage your TV.
A2
:
This step must require 2 or more professional to finish.
Figure 4
a/b/c
i/j
i/j
d/e/f
g/h
1 2
TV
Figure 5
③
Step 5:
Make sure the TV unit is horizontal, you can adjust the TV plate (360 degrees)
to level the TV by loosening the nut with open-end wrench , and tighten the
nut after adjustment. (
figure 6
Adjust the tilting angle (from +15° to -15°) with open-end wrench :
Hold the bottom of TV and adjust the TV to your desired position, tighten the nut with
open-end wrench .
(
figure 6
)
)
±
9
0
°
3
6
0
°
+
1
5
°
-
1
5
°
Product dimensions:
190mm
345mm
Figure 6
190mm
55mm
196.5mm
100mm
75mm
50mm
+15°
100mm
-15°
66mm
+90°/-90°
PAY EXTRA CARE AND ATTENTION WHEN YOU FASTEN TWO TV MOUNTS
TO THE BACK PANEL OF TV IN STEP3 . MAKE SURE THE APPROPRIATE
MOUNT HARDWARE IS BEING USED PROPERLY .
1. Select correct Mounting Hardware according to the screw hole size of your TV,
discard any remaining screws or spacers.
2. Carefully lay your TV on its face on a non-abrasivesurface, making sure to lay
padding underneath it so as not to damage the screen .
3. Place left TV mount and right mount in the approriate position, making sure
CENTERED on the back of the TV and LEVEL with on another .
4.This product only install on the perpendicular wall,not install on the ceiling.
