WNFQ-258ACN(BT)
Standard
IEEE802.11ac/a/b/g/n, Bluetooth V4.1,V4.0 LE, V3.0+HS, V2.1+EDR
Chipset solution
QCA6174A-5
Radio stream [Note1]
2T2R (Support WiFi/BT co-existence)
Antenna Type / con.
IPEX MHF4 connector
Bus Interface
WiFi: PCI Express
BT: USB
Form Factor
M.2 2230
Data Rate
WiFi:
802.11b: 11, 5.5, 2, 1 Mbps;
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n: MCS 0 to 15 for HT20MHz
MCS 0 to 15 for HT40MHz
802.11ac: MCS 0 to 9 for VHT20MHz
MCS 0 to 9 for VHT40MHz
MCS 0 to 9 for VHT80MHz
BT:
1 Mbps, 2Mbps and Up to 3Mbps EDR
Spreading /Modulation
Techniques
WiFi:
802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11g: OFDM (BPSK,QPSK,16-QAM,64-QAM)
802.11n: OFDM (BPSK,QPSK,16-QAM,64-QAM)
802.11ac: OFDM (BPSK,QPSK,16-QAM,64-QAM, 256-QAM)
BT:
Header: GFSK
Payload 2M: 4-DQPSK
Payload 3M: 8-DPSK
Frequency Range [Note2]
WiFi:
11b/g/n: 2.412GHz ~ 2.484GHz
11ac/a/n: 5.15GHz ~ 5.85GHz
BT:
2.402GHz ~ 2.480 GHz
Transmit Output Power
(Tolerance: +/-2dBm)
5180
WiFi:
802.11a: 11dBm@54Mbps
802.11b: 19dBm@11Mbps
802.11g: 16dBm@54Mbps
802.11gn HT20: 16dBm@MCS7
802.11gn HT40: 15dBm@MCS7
802.11an HT20: 9dBm@MCS7
802.11an HT40: 9dBm@MCS7
802.11ac VHT80: 7dBm@MCS9
BT: (Class 2 Device)
0 ≤ Output Power ≤ +4 dBm
Receiver Sensitivity
WiFi:
802.11b: ≤-81dBm@11Mbps
802.11g: ≤-66dBm@54Mbps
802.11a: ≤-66dBm@54Mbps
802.11gn HT20: ≤-65dBm@MCS7
802.11gn HT40: ≤-61dBm@MCS7
802.11an HT20: ≤-65dBm@MCS7
802.11an HT40: ≤-61dBm@MCS7
802.11ac VHT80: ≤-56dBm@MCS9
BT:
< 0.1% BER at -70dBm
Operating Voltage
DC 3.3V
Power Consumption
TX Mode: 405 mA
RX Mode: 200 mA
Temperature Range
-10°~+70°C (Operating), -40°~+85°C (Storing) [Note3]
Humidity (non-condensing)
5~90%(Operating), 5~90 % (Storing) [Note3]
Security
WEP / WPA / WPA2,802.1X
OS supported
Win7/Win8.1/Win10
Note:
1. For Radio stream with diversity or MIMO design, all RF connectors on the module must be fitting
antennas in order to guarantee the module performance.
2. The frequency range is subject to local regulations.
3. The storing condition is only for product functionality, no included for parts appearance.
NCC 警語
(1)
本產品符合低功率電波輻射性電機管理辦法
第十二條
※經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅
自變更頻率、加大功率或變更原設計之特性及功能。
第十四條
※低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象
時，應立即停用，並改善至無干擾時方得繼續使用。
-前項合法通信，指依電信法規定作業之無線電通信。
-低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干
擾。
(2)
應避免影響附近雷達系統之操作。
高增益指向性天線只得應用於固定式點對點系統。
(3)
此模組若安裝於其他平台時，該平台標籤需標明：
此平台內建無線模組
FCC Label Compliance Statement:
(1)
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
(2)
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
(3)
Caution :
(i) the device for operation in the band 5150-5250 MHz is only for indoor
use to reduce the potential for harmful interference to co-channel mobile
satellite systems;
(ii) high-power radars are allocated as primary users (i.e. priority users)
of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars
could cause interference and/or damage to LE-LAN devices.
(iii) for devices with detachable antenna(s), the maximum antenna gain
permitted for devices in the band 5725-5850 MHz shall be such that the
equipment still complies with the e.i.r.p. limits specified for point-to-point
and non-point-to-point operation as appropriate.
(4)
End Product Labeling:
This transmitter module is authorized only for use in device where the
antenna may be installed such that 20 cm may be maintained between the
antenna and users. The final end product must be labeled in a visible area
with the following: “Contains FCC ID: RYK-WNFQ258ACNBT ”. The
grantee's FCC ID can be used only when all FCC compliance
requirements are met.
(5)
Radiation Exposure Statement
This device is intended only for OEM integrators under the following
conditions:
1) The antenna must be installed such that 20 cm is maintained between
the antenna and users, and
2) The transmitter module may not be co-located with any other
transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be
required. However, the OEM integrator is still responsible for testing their
end-product for any additional compliance requirements required with
this module installed
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain
laptop configurations or co-location with another transmitter), then the
FCC authorization is no longer considered valid and the FCC ID can not
be used on the final product. In these circumstances, the OEM integrator
will be responsible for re-evaluating the end product (including the
transmitter) and obtaining a separate FCC authorization.
(6)
Radiation Exposure Statement:
1) Any changes or modifications not expressly approved by the grantee of
this device could void the user's authority to operate the equipment.
2) The product comply with the FCC portable RF exposure limit set forth
for an uncontrolled environment and are safe for intended operation as
described in this manual. The further RF exposure reduction can be
achieved if the product can be kept as far as possible from the user body
or set the device to lower output power if such function is available.
(7)
End Product Labeling
This transmitter module is authorized only for use in device where the
antenna may be installed such that 20 cm may be maintained between the
antenna and users. The final end product must be labeled in a visible area
with the following: “Contains FCC ID: RYK-WNFQ258ACNBT”. The
grantee's FCC ID can be used only when all FCC compliance
requirements are met.
(8)
Manual Information To the End User:
The OEM integrator has to be aware not to provide information to the
end user regarding how to install or remove this RF module in the user’s
manual of the end product which integrates this module.
The end user manual shall include all required regulatory
information/warning as show in this manual
IC Compliance Statement:
(1)
This device complies with RSS-247 of the Industry Canada Rules. Operation is subject
to the following two conditions :
(1) This device may not cause interference, and (2) This device must accept any
interference, including interference that may cause undesired operation of the device.
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
(1)
Cet appareil radio est conforme au CNR-247 d’Industrie Canada.
L’utilisation de ce dispositif est autorisée seulement aux deux conditions
suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
(2)
Caution :
(i) the device for operation in the band 5150-5250 MHz is only for indoor
use to reduce the potential for harmful interference to co-channel mobile
satellite systems;
(ii) high-power radars are allocated as primary users (i.e. priority users) of
the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
(iii) for devices with detachable antenna(s), the maximum antenna gain
permitted for devices in the band 5725-5850 MHz shall be such that the
equipment still complies with the e.i.r.p. limits specified for point-to-point
and non-point-to-point operation as appropriate.
(2)
Avertissement:
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés
uniquement pour une utilisation à l’intérieur afin de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les
mêmes canaux;
(ii) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de
radars de haute puissance sont désignés utilisateurs principaux (c.-à-d.,
qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz
et que ces radars pourraient causer du brouillage et/ou des dommages aux
dispositifs LAN-EL.
(iii) pour les dispositifs dotés d'antenne (s) détachable (s), le gain maximal
d'antenne autorisé pour les appareils de la bande 5725-5850 MHz doit être
tel que l'équipement soit toujours conforme aux normes e.i.r.p. Limites
spécifiées pour les opérations point à point et non point-à-point selon le cas
(3)
This radio transmitter (IC:6158A-258ACNBT) has been approved by
Industry Canada to operate with the antenna types listed below with the
maximum permissible gain indicated. Antenna types not included in this
list, having a gain greater than the maximum gain indicated for that type,
are strictly prohibited for use with this device.
Antenna Name
Antenna Type
Peak Gain(dBi)
2.4G
5G
Wanshin R3410110203
Dipole
2 dbi
2dbi
GEC6200
Dipole
3 dbi
5 dbi
(3)
Le présent émetteur radio (IC: 6158A-258ACNBT) aété approuvé par
Industrie Canada pour fonctionner avec les types d'antenne énumérés
ci-dessous et ayant un gain admissible maximal et l'impédance requise
pour chaque type
d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain
est supérieur au gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
(4)
Compliance with IC requirement RSS-247 data transmission is always
initiated by software, which is then passed down through the MAC,
through
the digital and analog baseband, and finally to the RF transceiver. Several
special packets are initiated by the MAC. These are the only ways the
digital baseband portion will turn on the RF transmitter, which it then
turns off at the end of the packet. Therefore, the transmitter will be on only
while one of the aforementioned packets are being transmitted.
(4)
est conforme au CNR-247 la transmission de données est toujours initiée
par le logiciel, qui est ensuite transmis à travers la MAC, à travers la bande
de base numérique et analogique et, enfin, à l'émetteur-récepteur RF.
Plusieurs paquets spéciaux sont initiées par le MAC. Ce sont les seuls
moyens de la partie bande de base numérique se met en marche l'émetteur
RF, ce qui lui puis s'éteint à la fin du paquet. Par conséquent, l'émetteur
sera sur que lorsque l'un des paquets ci-dessus sont transmises.
(5)
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. The antenna should be installed and operated
with minimum distance of 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with
any
other antenna or transmitter.
(5)
Cet appareil est conforme aux limites d'exposition aux rayonnements de la
IC pour un environnement non contrôlé. L'antenne doit être installé de
façon à garder une distance minimale de 20 centimètres entre la source de
rayonnements et votre corps.
L'émetteur ne doit pas être colocalisé ni fonctionner conjointement avec à
autre antenne ou autre émetteur.
(1)
This device is intended only for OEM integrators under the following
conditions:
(1) The antenna must be installed such that 20 cm is maintained between
the antenna and users, and
(2) The transmitter module may not be co-located with any other
transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be
required. However, the OEM integrator is still responsible for testing their
end-product for any additional compliance requirements required with this
module installed.
(1)
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les
conditions suivantes:
(1)L'antenne doit être installée de telle sorte qu'une distance de 20 cm est
respectée entre l'antenne et les utilisateurs, et
(2)Le module émetteur peut ne pas être coïmplanté avec un autre émetteur
ou antenne.
Tant que les 2 conditions ci-dessus sont remplies, des essais
supplémentaires sur l'émetteur ne seront pas nécessaires. Toutefois,
l'intégrateur OEM est toujours responsable des essais sur son produit final
pour toutes exigences de conformité supplémentaires requis pour ce
module installé.
(2)
End Product Labeling:
This transmitter module is authorized only for use in device where the
antenna may be installed such that 20 cm may be maintained between the
antenna and users. The final end product must be labeled in a visible area
with the following: “Contains IC:6158A-258ACNBT”.
(2)
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un
dispositif où l'antenne peut être installée de telle sorte qu'une distance de
20cm peut être maintenue entre l'antenne et les utilisateurs. Le produit
final doit être étiqueté dans un endroit visible avec l'inscription suivante:
"Contient des IC:6158A-258ACNBT ".
(3)
Manual Information To the End User:
The OEM integrator has to be aware not to provide information to the end
user regarding how to install or remove this RF module in the user’s
manual of the end product which integrates this module.
The end user manual shall include all required regulatory
information/warning as show in this manual.
(3)
Manuel d'information à l'utilisateur final:
L'intégrateur OEM doit être conscient de ne pas fournir des informations à
l'utilisateur final quant à la façon d'installer ou de supprimer ce module
RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations
réglementaires requises et avertissements comme indiqué dans ce manuel.
Loading...
