WX-6615
Wireless 11g
High Speed AP Router
Under the IEEE 802.11g technology, WX-6615 is a wireless high speed router from SparkLAN. Operating in 2.4GHz, 802.11g is
backward compatible with 802.11b. Thanks to the Orthogonal Frequency Division Multiplexing (ODFM) modulation technology,
802.11g surpasses 802.11b's Complementary Code Keying (CCK) and speed up data transmission up to 54Mbps. WX-6615 also
enables high data rate multi-media application, f or e xample, DVD stream transmission and broadband bandwidth control / management
and results in a higher performance of high speed Wireless LAN network. WX-6615, Wireless Access Point, allows user to connect
802.11g and/or 802.11b devices to the network. There is a built-in 4-ports full duplex 10/100 Switch to connect user's wired Ethernet
devices. It also allows user network to share a high speed cable or DSL Internet connection. Security wise, WX-6615 employs WEP
Encryption, MAC address filtering, and also supports VPN pass-through. Its NAT technology is used to protect against Internet
intruders. It can also be used as a DHCP Server. With WX-6615 at home or office, you can enjoy a more efficient, flexible and
secured network experience.
PRODUCT HIGHLIGHTS
Draft 802.11g compatible with 802.11b standard
Operating in 2.4 GHz with data rate up to 54Mbps
UP to 128-bit WEP Encryption
Website Blocking, IP & MAC address filtering
enhancement
Includes NAT technology and DHCP supports
Offers Cable/xDSL Internet sharing with a high-speed
integrated 4-port 10/100 Mbps switch
Supports Web-based management for easy configuration
and maintenance
FEATURES & BENEFITS
Easy to install
Enhanced Internet Security Management
NAT private-network protection with VPN pass-through
Can be assigned as DHCP server for existing network
Supports for multiple and concurrent IPsec, L2TP and
PPTP sessions
Eliminates need for an additional hub or switch.
Easy Indoor Wireless Network Set Up
Notebook
WL-311F/WL-611
PCMCIA Card
Desktop PC
WL-360F/WL-660
PCI Adopter
Printer/PS2/Xbox
WL-299C
Ethernet Adapter
Desktop PC
WL-382F
USB Adapter
WX-6615
AP Router
Internet
WX-6615
Wireless 11g High Speed AP Router
WL-660
11g PCI Adapter
WL-611
11g WLAN CardBus
AX-114K
14 dBi Patch Antenna
E-100
PoE Splitter
SPECIFICATIONS RELATED PRODUCTS
INTERFACE
Wireless
Ethernet LAN
Ethernet WAN
LED Indicators
Antenna
Standard
Reset Button
RADIO CHARACTERISTICS
ENVIRONMENTAL SPECIFICATIONS
POWER SUPPLY
CERTIFICATION
WARRANTY
PACKAGE CONTENTS
Standard
Frequency Bands
Dimension
Weight
Temperature
Humidity
Input
FCC class B; CE Mark
1 Year
Output
Modulation Tech
Media Access Protocol
Transmit Power
Receive Sensitivity
Data Rates
Operating Range
Number of Channels
IEEE 802.11g
LED x7: Power, Wireless, WAN, LAN4, LAN3, LAN2, LAN1
One 10Base-T RJ-45 socket
Four 10/100Base-T Ethernet switch port (auto sensing)
Dual 2dBi Gain Dipole Antenna
IEEE 802.3, 802.3u, 802.11b and 802.11g draft
Reset to default setting (hold the reset button after 6 sec)
IEEE 802.11b and IEEE 802.11g draft
195x160x27mm (LxWxH)
700g
Input : AC 100~240V, 0.35A, 50Hz~60Hz
Output : DC 4.7V~5.3V, 1.5A
95% Non-condensing
2.412~ 2.497GHz ISM Band
802.11b : 11Mbps & 5.5Mbps CCK; 2Mbps : DQPSK; 1Mbps : BPSK
802.11g : OFDM
CSMA/CA with ACK
11 Mbps 10-5 BER @ -80dBm; 54 Mbps 10-5 BER @ -65dBm
802.11b: 11Mbps, 5.5Mbps, 2Mbps, 1Mbps, auto fallback
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11b: 11Mbps Up to 300m (Outdoor), 35-60m (Indoor)
802.11g: 54Mbps up to 50m (Outdoor), 20m (Indoor)
* The performance various depend on environment.
SOFTWARE FEATURES
Protocol Support
Management
Support
Firmware Support
Security
TCP/IP, IPX/SPX, NetBEUI, DHCP, NAT, PPPoE Client
Configuration Web-based management with HTTP
Web Browser firmware upgrade
DHCP Client Server; Roaming in the same sub-network,
Default Settings Restore
Basic Rate Setting, Regulation Domain Setting, Port forwarding
DMZ, VPN pass-through (Support PPTP, L2TP and IPsec )
ESSID, SSID Broadcast Enable/Disable
64bit/128bit WEP, IP/MAC Address filtering, WPA (To be released)
One Wireless AP Router
One RJ45 Cat.5 UTP cable
One DC Power Adapter
One CD-ROM with User Guide
One Power Cord
One Quick Installation Guide
15 dBm 1@ Nominal Temp Range (Maximum)
-10 C to 50 C(Operating)
USA and Canada - 11
France - 4
Europe - 13
Japan - 14
