WRTR-300 Wireless
802.11g MIMO AP Router
8x greater coverage than ever before!
SparkLAN WRTR-300 11g MIMO AP router features MIMO (Multiple-Input Multiple-Output) technology, which
utilizes multip le antennas to tra nsfer mult iple wirele ss signals simultaneou sly and re duce the num ber of de ad
spots. So it doesn’t only significantly enhance the throughput, but also to extend the coverage with 8x greater
coverage than conventional gears while 100% backward compatible with 802.11b/g gears. Ideal for larger
homes or offices that have a wider area to cover,
downloading, video streaming, file sharing, and gaming. Users can experience the improvement in their
wireless network range.
high-speed internet connection. With the SparkLAN WRTR-300 wireless Router as the central network
connection point, your PC are able to share a broadband Internet connection and networked peripherals such
as hard drives, network storage, and printers.
Keep your wireless network safe
To maximize your network security and privacy, SparkLAN WRTR-300 incorporates 64/128 bit WEP
Encryption, Wi-Fi Protected Access (WPA) with AES and TKIP, Lay er 2 iso latio n, w hich c an f ilte r exte rnal user
and prevent illegal attacking. Network Address Translation (NAT) doubles your firewall and safeguards your
network from internet hacker. VPN pass-through provides secure internet connections to your office. As a
result, there is no need to worry about unauthorized users.
The 4-port 10/100Base-T Ethernet switch can address your demand for sharing
SparkLAN offers a breakthrough solution for music
Benefits
z Farther coverage range than ever
z High speed data transmission
z Advanced security: Layer 2 isolation,
64/128bit WEP, WPA with AES and TKIP, MAC
address filtering
z Support NAT to protect user against hackers
z Easy-to-install
Features
z MIMO technology
z Support WDS (bride)
z 4-port 10/100 Ethernet switch for
broadband internet connection
z Support VPN pass-through
z Web-based management
广州市天河区建中路66号 佳都商务大厦东塔601室 电话：020-28817998 传真：020-28817998
www.sparklan.cn
www.sparklan.cn
SPECIFICATIONS
Hardware Features
Connectivity WAN:1x 10/100Base-T switch port
LAN: 4x10/100Base-T Ethernet switch port
LED Indicators Power, WAN, ACT/Link, LAN1, LAN2, LAN3, LA N4
Antenna 2dBi Reverse SMA antenna
Radio Characteristics
Standard IEEE802.11b/g
IEEE802.3, 802.3u
Frequency
Bands
Modulation
Transmitted
Power
Receive
Sensitivity
Data Rates 802.11b: 11, 5.5, 2, 1Mbps
Power
Consumption
802.11b/g :ISM-Band 2.412~ 2.4835GHz
802.11a/g: OFDM
802.11b: CCK,DQPSK, DBPSK
802.11g: 13~15dBm
802.11b: 16~18dBm
802.11g 54Mbps @ -75dBm
802.11g : 54, 48, 36, 24, 18, 12, 9, 6 Mbps
TX:320mA@5V RX:350mA@5V
Software Features
Protocol
Support
Basic
Management z Web-based management
Security z 64/128 WEP
z TCP/IP, IPX, NetBEUI
z DHCP client/server
z NAT, PPPoE Client
z Dynamic DNS
z WPA with TKIP and AES
z WPA RADIUS
z Layer 2 isolation
z VPN pass-through
z MAC address filtering
Environmental Specifications
Temperature
Humidity Operating Humidity: 10%~85%,(non-condensing)
Operating: 0ºC to 40ºC (32ºF to 150ºF)
Storage: 0ºC to 70ºC (-40ºF to 185ºF)
Operating Humidity: 10%~85%,(non-condensing)
Power S upply
Input Input: AC 110V/220V/230V/240V
Output DC 12V, 0.5A
Certification
FCC, CE
Warranty
1 Y ear
Package Contents
WRTR-300 Wireless Pre-n MIMO AP Router
CD-ROM (QIG, User Manuel) Multi-language Quick Installation Guide
DC Power Adapter RJ45 Cat.5 UTP cable
RELATED PRODUCTS
WPCR-300 Wireless MIMO-G
CardBus Adapter
WPIR-300 Wireless MIMO-G
PCI Adapter
SparkLAN Communications Inc., All Rights Reserved. This document is for planning purposes only, and is not intended to modify
or supplement any specifications or warranties relating to products of SparkLAN Communications. SparkLAN may make
changes to specifications and descriptions at any time without prior notice.
